Woxcon SCU42 User Manual

4x2 hdmi 2.0 presentation switcher with matrix outputs
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
SCU42
4x2 HDMI 2.0 Presentation Switcher with
Matrix Outputs
All Rights Reserved
Version: SCU42_2019V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCU42 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Woxcon SCU42

Summary of Contents for Woxcon SCU42

  • Page 1 User Manual SCU42 4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs All Rights Reserved Version: SCU42_2019V1.0...

  • Page 2: Table Of Contents

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs Table of Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Package List ....................... 1 2. Specification ........................ 2 3. Panel Description ......................4 3.1 Front Panel ......................4 3.2 Rear Panel ......................5 4.

  • Page 3: Product Introduction

    HDMI 2.0 support. The product offers SPDIF and 3.5mm output for dual HDMI OUT audio extraction and dual HDMI OUT ARC along with 4K to 1080p down-scaling functionality. The SCU42 features a wide range of control flexibility via Web, RS232, IR and smart EDID management.

  • Page 4: Specification

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs 2. Specification Video Input Video Input (4) HDMI Video Input Connector (4) Type-A female HDMI Video Input Video Up to 4K@60Hz 4:4:4 8bit Resolution Supports Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, Dolby HDMI Audio Format Digital, DTS-X, DTS-HD Master Audio, DTS 5.1, 2 - 8Ch PCM 32- 192KHz 16-24 bits;...
  • Page 5 4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs > 80dB, 20Hz~20KHz bandwidth Crosstalk isolation < -80dB, 10KHz sine at 0dBFS level (or max level before clipping) L-R level deviation < 0.05dB, 1KHz sine at 0dBFS level (or max level before clipping) Output load capability 1Kohm and higher (supports 10x paralleled 10Kohm loads) Noise Level...

  • Page 6: Panel Description

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs 3. Panel Description 3.1 Front Panel ① Power LED: Illuminates solid red when the device is powered on. ② Out A: 1-4: Four HDMI input LEDs, one of which illuminates green to indicate which source is selected.

  • Page 7: Rear Panel

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs 3.2 Rear Panel ① Inputs 1~4: Connects to HDMI sources. ② Outputs (ARC) A~B: Connects to display devices. They supports ARC, and only the output A port supports color space 4:2:2/4:2:0 to 4:4:4 and 4K to 1080p down- scaling function for compatibility with more display devices.

  • Page 8: System Connection

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs 4. System Connection The following diagram illustrates the typical input and output connection of the switcher: Game Console Game Console HDMI: Down-Scaler Audio: DC 12V RS232: TCP/IP: Inputs Outputs (ARC) Audio Out RS232 IR EYE TCP/IP...

  • Page 9: Button Control

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs 5. Button Control 5.1 Manual Switching When the switcher is in manual switching mode, the AUTO button LED goes out. Please follow the below steps to switch input source to output channel. 1) Press Select button at Out A block to select input source for output A, and the corresponding source LED turns green.

  • Page 10: Edid Setting

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs 5.3 EDID Setting The Extended Display Identification Data (EDID) is used by the source device to match its video resolution with the connected display. The 4-pin DIP switch on the front panel can be used to set the EDID to a fixed value to ensure the compatibility in the video resolution.

  • Page 11: Ir Remote Control

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs 1) When the specifications of output A and output B display devices are same, set the EDID to Global Mode. When switch same input to output A and output B, because the supported resolution (4K@60Hz 4:4:4) of two outputs are same, the input source device will not reread the EDID of display device to ensure non-flash screen.

  • Page 12: Web Control

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs 7. Web Control The switcher can be controlled via TCP/IP. The default IP settings are: IP Address: 192.168.0.178 Subnet Mask: 255.255.255.0 Type 192.168.0.178 in the internet browser, it will enter the below log-in webpage: Username: admin Password: admin...
  • Page 13 4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs Type the user name and password, and then click Login to enter the below control tab. Matrix Switch: Select Input 1~4 for output A or output B to build matrix switching. Select AUTO to enable auto switching mode for output A or output B. Audio Out: Select output A de-embedded audio, output B de-embedded audio, output A ARC audio or output B ARC audio for Toslink and 3.5mm jack audio outputs.

  • Page 14: Rs232 Control

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs 8. RS232 Control Connect the RS232 port to control device (e.g. PC) with RS232 cable. The switcher can be controlled by sending RS232 commands. RS232 Commands: The command lists are used to control the switcher. The RS232 control software (e.g. docklight) needs to be installed on the control PC to send RS232 commands.
  • Page 15 4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs Command Example Command Description and Feedback Set the baud rate of switcher to [PARAM]. [PARAM]=1~7. >SetRS232Baudrate 5 [PARAM] Baud Rate 115200 >SetRS232Baudrate 57600 [PARAM] 38400 19200 <RS232Baudrate 9600 9600 4800 2400 >GetRS233Baudrate Get the baud rate of switcher.

  • Page 16: Signal Switching Commands

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs Command Example Command Description and Feedback >GetGateWay Get gateway. <GateWay 192.168.0.1 >SetMacAddr Set the MAC address to <MacAddr XX:XX:XX:XX:XX:XX XX:XX:XX:XX:XX:XX. 1A:23:34:45:56:67 <MacAddr >GetMacAddr Get the MAC address. 1A:23:34:45:56:67 8.2 Signal Switching Commands Command Example Command Description...

  • Page 17: Edid Setting Commands

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs [PARAM] [PARAM]= Passive, Active Passive: The HDCP version of output follows the HDCP of input source. <HdcpOutput Passive Active: The HDCP version of output is up to <HdcpHdmiOutput >GetHdcpOutput Get HDCP output mode. Passive 8.3 EDID Setting Commands Command Example...

  • Page 18: Firmware Upgrade

    4x2 HDMI 2.0 Presentation Switcher with Matrix Outputs 9. Firmware Upgrade Please follow the steps below to upgrade the firmware by the FW port on the front panel: 1) Prepare the latest upgrade file (.bin) and rename it as “FW_MERG.bin”. 2) Connect the switcher to the PC with USB to Micro USB cable, and then power on the switcher.
