Lattice Semiconductor Crosslink-NX Quick Start

QuickSTART
This document provides a brief introduction to the Crosslink-NX Voice and Vision
Machine Learning Board. The board is pre-programmed to demonstrate the Human
Counting Demo.
JTAG Header (J1)
Config USB (J2)
LoRes Camera
Connector (U24)
Parallel Config
Header (J9)
HiRes Camera
Connector (CN1)
Power Indicator
LEDs
1
Check Kit Contents
The Crosslink-NX Voice and Vision Machine Learning Board kit contains the following
items:
CrossLink-NX Voice and Vision Machine Learning Board
„
HM360 camera sensor (1 sensor, mounted on board)
„
USB Cable for Programming via PC (USB-A to Micro-B)
„
USB Cable for video output (Micro-B to USB-A)
„
Limited license with unique serial number for Lattice Radiant development software
„
(optional to use)
Quick Start Guide
„
2 Preparing the Hardware and Running the Demonstration
Follow the steps below to prepare the hardware and start the demonstration, which is
pre-programmed on the board.
Connect USB2 cable from PC to Config USB (J2). This will power the board with a
„
5 V supply.
Connect USB3 cable from Video Out USB3 to PC (J3)
„
No jumpers need to be placed on board
„
Vision Machine Learning Board
PMOD2:3 (J6:7) LIFCL40-MG289 (US)
Input Switches
and Buttons
PMOD0:1 (J4:5)
Crosslink-NX Voice and
CY-USB-3014 (U13)
USB3 Out (J8)
Indicator LEDs
HyperRAM (U8:9)
