- Page 1 LPe1250 HBA Installation Manual Last updated May 5, 2008 Critical Connectivity Solutions...
- Page 2 Information furnished by Emulex is believed to be accurate and reliable. However, no responsibility is assumed by Emulex for its use; or for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent, copyright or related rights of Emulex.
-
Page 3: Table Of Contents
Applying Power... 5 Viewing the LEDs ... 5 POST Conditions and Results ... 5 References ... 7 Specifications ... 7 FCC and Regulatory Notices ... 8 Declaration of Conformity ... 9 Laser Safety Notice ... 11 LPe1250 Hardware Installation Manual Page iii... -
Page 4: Introduction
ARM-1156 core, integrated SERDES (Serialized/Deserializer), and integrated SRAM (static random-access memory). The core technology of this HBA is the ninth generation FC controller by Emulex. The controller incorporates a multifunction native PCIe core that is compliant to the PCIe Base Specification 2.0 and PCI Express Card Electromechanical (CEM) Specification 2.0. -
Page 5: Installing The Host Bus Adapter
Note: The HBA reports a device ID of 0x1AE5. The Emulex LPe1250 HBA uses a removable optical transceiver. If you need to change the bracket for HBA installation, you must first remove this transceiver from its housing (cage). This document explains how to install the HBA and, if necessary, how to remove the transceiver and bracket safely. - Page 6 16. Secure the HBA's mounting bracket to the case with the panel screw or clip. 17. Replace the computer case and tighten case screws. The HBA is now installed in the computer and is ready for media attachment. LPe1250 Hardware Installation Manual Page 3...
-
Page 7: Attaching Media
Figure 4: Connecting Fiber Optic Cable 2. Connect the other end of the cable to the Fibre Channel device. After the media is connected to the HBA, you are ready to apply power to the computer. LPe1250 Hardware Installation Manual Maximum Length Minimum Length .5 meters... -
Page 8: Applying Power
Yellow LED Slow blink Fast blink Flashing 2 fast blinks 3 fast blinks 4 fast blinks LPe1250 Hardware Installation Manual Green LED Wake-up failure (Dead board) POST failure (Dead board) Wake-up failure monitor POST failure POST processing in progress Failure while functioning... - Page 9 Slow blink Slow blink Slow blink Fast blink Slow blink Flashing Slow blink LPe1250 Hardware Installation Manual Green LED Normal - link down or not started Off-line for download Restricted off-line mode (waiting for restart) Restricted off-line mode (test active) State...
-
Page 10: References
References Specifications Table 4. LPe1250 Specifications Parameter Media Interface The controller interfaces to the physical media through an FC-0 Media Interface (FC-PI compliant transceiver), and then connects through dual optical fiber LC connectors. Physical Dimensions Low-profile MD2 form factor, 6.600 inches by 2.713 inches, and accommodates both the full-height and low-profile bracket. -
Page 11: Fcc And Regulatory Notices
The reader is cautioned that changes or modifications made to the equipment not expressly approved by Emulex could void the user's authority to operate this equipment. The above statement applies to products marketed in the USA. -
Page 12: Declaration Of Conformity
WARNING: This is a class A product. In a domestic environment, this product may cause radio interference requiring the user to take adequate measures. Note: Changes or modifications not expressly approved by Emulex Corporation could void the user's authority to operate this equipment. - Page 13 LPe1250 Hardware Installation Manual Page 10...
-
Page 14: Laser Safety Notice
Certification and Classification The LPe1250 host adapter may contain one or more examples of a laser product known as a small form factor transceiver. This transceiver provides the physical connection to the optical cable, and its LC-style connector extends through the mounting bracket. -
Page 15: Product Information
Short wavelength and long wavelength small form factor transceivers embedded in Emulex host adapter are non-OFC. For non- OFC links, a compatible laser device must be non-OFC and certified as a Class 1 laser product. - Page 16 Copies of the certificate of conformity for any small form factor transceiver sold by Emulex can be obtained upon request from Emulex Corporation, Costa Mesa. LPe1250 Hardware Installation Manual Page 13...
