Summary of Contents for Emulex LP11002 HBA
- Page 1 LP11002 HBA Installation Manual...
- Page 2 Emulex Corporation for its use; or for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Emulex Corporation.
-
Page 3: Table Of Contents
Table of Contents Introduction ..............................1 Major Features ..........................1 Compatibility ........................... 2 Prerequisites ........................... 2 Setting the Jumpers ............................. 3 Installing the Host Bus Adapter ........................4 Attaching Media ............................5 Applying Power ............................6 Viewing the LEDs ...........................6 POST Conditions and Results ......................6 References .............................. -
Page 4: Introduction
LP11002 host bus adapter (HBA) is a dual-channel, 4-gigabit per second (Gb/s), Fibre ® Channel (FC) PCI-X 2.0 HBA. The core technology of this HBA is Emulex’s seventh generation FC controller. The controller incorporates a multi-function native PCI-X 2.0 core that is compliant to the Peripheral Component Interconnect (PCI) and PCI-X local bus specifications. -
Page 5: Compatibility
• I/O multiplexing down to the FC frame level • Data buffers capable of supporting 16 buffer-to-buffer (BB) credits for short-wave applications • Link management and recovery handled by the firmware • On-board diagnostic capability accessible via optional connection • Parts and construction compliant to the European Union Directive of Restriction of Hazardous Substances (RoHS) Compatibility... -
Page 6: Setting The Jumpers
Setting the Jumpers Caution: Emulex LightPulse® HBAs contain electronic components that can be damaged by static electricity through an electrostatic discharge (ESD) event. To prevent ESD damage, maintain constant contact with any grounded metal surface. A grounding wrist strap is useful for this purpose. Handle the card carefully at all times and preferably by the edges. -
Page 7: Installing The Host Bus Adapter
FC connectivity. Since this adapter has two ports, there are two IEEE addresses. The IEEE address is used when configuring your system. The serial number is used when communicating with Emulex. All numbers are clearly marked on the board. We recommend that you record these numbers before installation. -
Page 8: Attaching Media
Attaching Media Note: The HBA will not allow normal data transmission on an optical link unless it is connected to another similar or compatible laser product (that is, multimode to multimode.) Use multimode fiber optic cable, with short-wave lasers, that adheres to the following specifications: Table 3: Media Specifications Fiber Optic Cable Maximum Length... -
Page 9: Applying Power
Applying Power To apply power: 1. Verify that the HBA is securely installed in the computer. 2. Verify that the correct media is attached. 3. Plug in and turn on the computer. 4. Observe LEDs for Power On Self Test (POST) results. Viewing the LEDs Green and yellow LEDs can be seen through openings in the HBA's mounting bracket. -
Page 10: References
References Specifications Table 5: LP11002 Specifications Parameter Range Media Interface The controller interfaces to the physical media through an FC-0 Media Interface (FC-PI compliant transceiver), and then connects through dual optical fiber LC connectors. Physical Dimensions Low-profile MD2 form factor, 6.600 inches by 2.536 inches, and accommodates both the full-height and low-profile bracket. -
Page 11: Fcc And Regulatory Notices
The reader is cautioned that changes or modifications made to the equipment not expressly approved by Emulex could void the user's authority to operate this equipment. The above statement applies to products marketed in the USA. -
Page 12: Declaration Of Conformity
WARNING: This is a class A product. In a domestic environment, this product may cause radio interference requiring the user to take adequate measures. Note: Changes or modifications not expressly approved by Emulex Corporation could void the user's authority to operate this equipment. - Page 13 LP11002 Hardware Installation Manual Page 10...
-
Page 14: Laser Safety Notice
In turn, the host adapter can be inserted into any host system's appropriate PCI/PCI-X expansion slot. In the United States, all optical small form factor transceivers sold by Emulex are certified as Class 1 laser products that conform to the requirements contained in the Department of Health and Human Services (DHHS) regulation 21 CFR subchapter J. - Page 15 Short wavelength and long wavelength small form factor transceivers embedded in Emulex host adapter are non-OFC. For non- OFC links, a compatible laser device must be non-OFC and certified as a Class 1 laser product.
- Page 16 Copies of the certificate of conformity for any small form factor transceiver sold by Emulex can be obtained upon request from Emulex Corporation, Costa Mesa. LP11002 Hardware Installation Manual Page 13...
