JBL Performance IS5 Technical Manual

Technical Manual
IS5
Performance
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Grille, Gray
• Low-Frequency Transducer
DC Resistance
• High-Frequency Transducer
DC Resistance
• Crossover Network
PACKAGING
10
Harman Consumer Group, Inc., 250 Crossways Park Drive, Woodbury, New York 11797
™ Series
8 Ohms
60 Watts*
45Hz – 20kHz (–10dB)
87dB (2.83V @ 1 meter)
3,000Hz
590-0275
5-1/4" (133mm) Titanium-
laminate cone w/rubber
surround (590-0276)
5.6 Ohms, ±10%
1" (25mm) Titanium-laminate
dome, w/swivel mount
(590-0278)
7.5 Ohms, ±10%
590-0277
Legend on Page 2
9
12
11 11
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Plate Size (W x H)
• Mounting Cutout
Size (W x H)
• Mounting Depth
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.
* The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
WIRING DIAGRAM
590-0277
IS5 SCHEMATIC
L1
1.6mH
3.9 ohms
10 watts
C2
6uF
100V
0.5mH
6.0V Input 40Hz to 20kHz
5.0V Input 40Hz to 4kHz
2.83V Input 2kHz to 20kHz
7-1/2" x 10" (191mm x 254mm)
6-1/8" x 8-11/16"
(156mm x 221mm)
3-3/4" (95mm)
8 lb/3.6kg (sold in pairs)
590-0278
590-0276
GRN
.250
C1
14uF
100V
BLK
.205
R1
YEL
.110
R2
L2
5.1 ohms
10 watts
BLK
.110
1/07
