Install Post Bracket Assembly and Gate Bracket

Step 1
3 1
Insert the / " x 1 / " bolt through the center hole of the post brackets and post
8 4
pivot bracket. Secure with a
overtighten the nut (the post pivot bracket will have to be adjusted later).
Step 2
Attach post bracket assembly to the rear mount of the opener with a clevis pin.
Secure the clevis pin with a hairpin clip.
Step 3
Attach gate bracket to the front mount of the opener with a clevis pin. Secure the
clevis pin with a hairpin clip.
Post Bracket Assembly
Step 4
With the gate in the fully open position and the opener arm fully retracted,
adjust the post bracket assembly and gate bracket until the opener is level. While
holding the opener level, use C-clamps to temporarily secure the post bracket
assembly and gate bracket to the post and gate.
3 3
/ " washer, / " lock washer and
8 8
Clevis Pin
Rear Mount
Hairpin Clip
Post Bracket Assembly
Fence Post
3
/ " nut. DO NOT
8
Gate in Open Position
Opener Arm Fully Retracted
Level Opener
3 / " x 1 1 / " Bolt
8 4
Post Pivot Bracket
Post Bracket
3 / " Washer
8
3 / " Lock Washer
8
3
/ " Nut
8
Front Mount
Gate Bracket
Hairpin Clip
Gate Bracket
