Technical Specifications
_____________________________________
•
Low friction screw drive (linear actuator) rated for -5 °F to +160 °F (-20 °C to +71 °C).
•
Powered by a 12 V motor with integral case hardened steel gear reducer. Motor speed reduced to 260 rpm. Generates
520 inch lb. of torque at 12 V.
•
Maximum opening arc of 110°. Approximate opening time (90°): 18 seconds, depending on weight of gate.
_____________________________________
•
The system is powered by a 12 Vdc automotive, lawn tractor or marine battery (required but not included).
•
Battery charge is 120Vac to 16Vac output through the control board] or by optional Solar Panels; the panel should
generate minimum of 10 Watts (600 mA). A diode on the control board prevents battery discharge. IMPORTANT:
Never use both transformer and solar panel— this will damage the battery and control board.
•
One (1) blade-style fuse is rated for 15A.
NOTE: The transformer should not be directly connected to any battery. Do not replace fuses with
higher ampere rated fuses; doing so will void your warranty and may damage your control board.
_____________________________________
•
Microprocessor-based control board is set for dual leaf, pull-to-open gate installations. Jumper can be removed to
accommodate an optional kit for push-to-open gates.
•
Control board has temperature compensated circuits.
•
Auto-memorization of digital transmitter code.
•
Opener length with push-pull tube fully retracted is 26
•
Adjustable auto-close timer (OFF to 3–120 seconds), and Dual Sense Technology™ stall force).
•
Power terminal block accommodates a transformer or solar panels.
•
Accessory terminal block fully compatible with all Mighty Mule access controls.
•
Control board allows connection of edge sensors and photoelectric sensors.
•
Audio entrapment alarm sounds if unit encounters an obstruction twice while opening or closing.
_____________________________________
•
Maximum gate size: 300 lbs., 12' long.
NOTE: BALL BEARING HINGES SHOULD BE USED ON ALL GATES WEIGHING OVER 250 LB.
1
MM272 Installation Instructions
MIGHTY MULE MM272 DUAL GATE OPENER
OPERATIONAL CAPACITY
_____________________________________
DRIVE
_____________________________________
POWER
_____________________________________
CONTROL
3
/
", mounting point to mounting point. Maximum stroke is 13".
8
