Tools and Materials
Tools Needed:
• Power Drill
• Open End Wrenches —
• Adjustable Wrench
•
3
/
" Drill Bit
8
• Hacksaw or Heavy Duty Bolt Cutters
• Small Flat Bladed Screwdriver
• Large Phillips Screwdriver
• Tape Measure
• Level
• Wire Strippers
• C-Clamps — small, medium, and large
• Center Punch
• Hammer (for center punch)
• Extra person will be helpful
Materials You May Need for the Installation:
These items are NOT included with the gate opener kit. Some of these items can be purchased or special ordered through
participating retailers. Please see
•
12 VDC automotive/lawn tractor or deep cycle marine battery is required to power the opener.
•
Low voltage wire [RB509] will be needed to run from the transformer to the opener control board; length depends upon the
distance between the transformer power supply and the control box.
•
If your gate is more than 1000' away from an AC power source you will need to use at least one 10 watt Solar Panel [FM123]
to charge the 12 Volt battery.
•
PVC conduit for protecting in ground wiring.
•
Push-To-Open Brackets [FM148] are required if gates open out from property.
•
Materials to reinforce thin walled tube or panel gates.
•
Depending on the type of gate, a horizontal cross member or mounting plate may be needed to mount the front of the opener
and gate bracket to the gate.
•
Some installations may require muffler clamps for the gate bracket, to prevent drilling into thin wall tube gates.
•
(2)16 AWG crimp on fork lugs.
•
Surge protection for transformer.
•
Weather proof outlet and cover is required if transformer is plugged into outside outlet.
•
Some types of installations require U-Bolts for closed position stop plate.
•
A low profile ground stop is required for dual gates when using the Mighty Mule gate lock.
5
MM272 Installation Instructions
1
/
" and
9
/
"
2
16
page 26
or
www.mightymule.com
(page 2
& 26)
(page
(page 3
& 7)
(page
15)
(page
16)
NOT ALL TOOLS ARE SHOWN
(page 13
& 20)
6)
(page 3
(page
7)
(page
(page
2)
& 20)
(page
16)
11)
(page
11)
(page
7)
