Summary of Contents for Bauhn ATV60UHDW-1121
- Page 1 ” MODEL: ATV60UHDW-1121 User Manual AFTER SALES SUPPORT tempo.org/support 1300 002 534 MODEL: ATV60UHDW-1121 PRODUCT CODE: 707794 11/2021...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new BAUHN product. ® Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN are manufactured to the highest standards of performance and safety and, ®... -
Page 3: Table Of Contents
Contents Welcome Advanced Controls USB Mode (TV Setting Menus) Set Up Unpack and Prepare Picture Viewing Photos and Videos What's in the Box Sound Photo Player Important Tips Programmes Video Player Attaching the Stand Connection Playing Music Wall-Mounting the TV General Music Player Connect to Power... -
Page 4: Unpack And Prepare
Unpack and Prepare What's in the Box See the flap of the box Before installing your new TV, check you have everything needed. for how to handle the TV without damaging it! In the box you will find: A. 60" 4K Ultra HD Smart TV B. -
Page 5: Important Tips
Important Tips • Place the TV on a level surface. • Place the TV away from any source that may generate heat or vibrations. • Make sure there is enough space around vents for airflow. • The remote control works up to 5 metres away from the TV. •... -
Page 6: Attaching The Stand
Attaching the Stand • This TV is heavy! We recommend asking someone to help you lift it. • Unplug the TV from the power outlet before installing or removing the stand. • DO NOT place the TV standing upright without its stand attached;... -
Page 7: Wall-Mounting The Tv
Wall-Mounting the TV • Unplug the TV from the power outlet before wall-mounting. • Contact a professional for assistance with wall-mounting the TV. Required 400mm • VESA Mounting Bracket • 4 x M6*10mm screws (or longer as required) The TV comes with holes on the back panel for use with wall-mounting brackets (bracket not included). -
Page 8: Connect To Power
Connect to Power Don't forget to plug in the TV to the power outlet. Leave the power switched off until installation is finished. Make sure the TV is switched off at the power outlet until you have finished connecting your cables. Connect your Antenna Free-to-air TV in HD (High Definition) High Definition (HD) channels... -
Page 9: Controls And Connections
Controls and Connections Get to Know your TV On/Standby light and Remote sensor Buttons on the TV SOURCE 1. SOURCE: Change the input source. MENU 2. MENU: Enter the settings menu. VOL + 3. VOL +: Increase volume level. VOL - 4. -
Page 10: Ports On The Tv
Ports on the TV Plug in a USB stick/drive to PVR record and pause live TV. Play media files stored on your USB storage device (supported file codecs and extensions may vary). Update the TV software via USB. Note: Time-shift function requires a USB-HDD for storage. HDMI Use a high-speed All-digital connection between the TV and any HDMI device. - Page 11 Connect to your broadband modem using an Ethernet cable (not included). Connect an external digital audio device. Use an Optical cable OPTICAL (not included) to connect the unit with an amplifier, soundbar or other audio decoding device for digital audio signal output. (CVBS) You can use this to connect your DVD player.
-
Page 12: Remote Control
Remote Control Setup Insert two AA size batteries according to the polarity markings (+/-) inside the compartment. Make sure the batteries are correctly aligned and properly pushed into AA size place. batteries included Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 13: Using The Remote Control
Remote Hints and Tips Using the Remote Control • Do not drop, step on or otherwise impact the remote control. This To use the remote, point it towards the remote sensor may damage the parts or lead to at the front of the TV. The remote will not operate if its malfunction. -
Page 14: Magic Remote
Magic Remote : Switch the TV to On or Standby : Switch the main set top box to On or Standby Microphone AD / SAP : Press to display NUMBER BUTTONS: Key in a TV channel additional buttons/settings. Press number and hold for audio description : Display channel list : Change to the next/... - Page 15 : Press the UP/DOWN/ LEFT/RIGHT buttons to navigate /GUIDE: Launch TV Guide SCROLL WHEEL/OK BUTTON: Scroll up/down and press to confirm (SOURCE): Select the input selection source and enter the HOME dashboard : Return to previous. Press and hold to exit : Launch the Amazon Prime Video app : Launch the Netflix app...
-
Page 16: Pairing The Remote
Pairing the Remote During the first time setup process, when the screen shown above appears, point the remote control towards the IR sensor of the TV and press the SCROLL WHEEL/OK button to pair the remote. If pairing is unsuccessful, turn the TV off and turn back on and pair again. To unpair the remote, when the TV is on, press and hold the buttons for 5 seconds (until the remote's LED is blinking), and the remote will automatically unpair with the TV. -
Page 17: On-Screen Set Up
On-Screen Set Up Make sure equipment is properly connected (as shown on pages 10-11) before connecting the TV to power. Make sure the TV is plugged in at the power socket and switched on. Press the button to turn on the TV. On/Standby light is WHITE in standby mode. -
Page 18: Lg Thinq App
LG ThinQ App You can use the LG ThinQ app to control key TV functions instead of the remote control. Note: you need an Android device running Android 4.3 or higher to use the app. 1. On your smart phone, search and download the LG ThinQ app from the Play Store/App store (alternatively, scan the QR code below): For Android For iOS... -
Page 19: Advanced Controls (Tv Setting Menus)
Advanced Controls (TV Setting Menus) Menu Navigation Buttons Once you have programmed any settings, the unit will retain them in its memory until you change then, even then SCROLL WHEEL/OK BUTTON to Press the after turning the TV off. display the TV settings menu. See the guide below for all the other buttons you'll need to use to adjust and change your settings. - Page 20 Sound Connection Accessibility • Sound Mode: • TV Name • Audio Description • Balance, Ultra Surround, • Network Connection • Audio Description Equalizer, Reset Settings: Volume • Sound Out • Wired Connection • High Contrast (Ethernet), Wi-Fi Connection • Additional Settings: •...
-
Page 21: Picture
Picture To access picture settings, navigate from > SCROLL WHEEL/OK BUTTON > Picture Picture Mode : Enhanced brightness with lower contrast, colour depth and edges for standing out in Vivid very bright places such as storefronts. (Auto Power Save) : Settings are optimised to reduce power consumption. : Settings are optimised for watching movies. - Page 22 Option Description Adjust the colour balance between red and green. The closer red is to 50, colour will be more Tint 'red' dominant. The closer green is to 50, colour will be more 'green' dominant. Colour Adjust the on-screen colour temperature. Temperature Advanced See table below for more information.
- Page 23 Option Description Adjust the colour and saturation of the picture to make the image more colourful Dynamic Colour and lively. Gamma Adjust mid level brightness of picture. Aspect Ratio Settings • Aspect Ratio: this item is used to adjust the video size. Sizes may differ between input sources. •...
-
Page 24: Sound
Sound > SCROLL WHEEL/OK BUTTON > Sound To access sound settings, navigate from Option Description Sound Mode Standard (User) Cinema Cricket Music Game Clear Voice III Balance Adjust the audio output between the left and right speakers. Ultra Surround Adjust surround sound effect from your TV speakers. Equalizer Adjust selected frequencies. - Page 25 Wired Headphones Connect to your wired headphones to enjoy sound only you can hear. Optical + Internal TV Sound is played through the TV's speakers and connected external audio device simultaneously. Speaker Wired Headphones + Sound is played through the TV's speakers and connected headphones simultaneously. Internal TV Speaker Additional Settings Option...
-
Page 26: Programmes
Programmes To access programme settings, navigate from > SCROLL WHEEL/OK BUTTON > Programmes Programme Tuning Option Description Automatically scans all available free-to-air TV channels. Adjust settings (default settings are set for Auto Tuning Australia), select 'Search' and press OK. Manual Tuning Manually select and scan digital TV channels. - Page 27 Edit favourite programmes Option Description Select one or more programmes in the Preferred Programmes list and Move select the position to move it to. Change Group Change the name of the favourite programmes list. Name Sort by Programme Sort out the favourite programmes list by programme/genre. Subtitle Language Select preferred subtitle language.
-
Page 28: Connection
Connection > SCROLL WHEEL/OK BUTTON > Connection To access connection settings, navigate from TV Name Show current TV name. You can also use the screen keyboard to set to your preferred name (up to 25 characters can be entered). Network Connection Settings See below. - Page 29 Device Connection Settings Option Description Auto Device Automatically allows you to control the devices connected via HDMI with the remote control. Connection Manage devices (i.e. set top box or soundbar) connected to a TV via HDMI with the remote control. SIMPLINK (HDMI CEC) Up to three devices can be connected and simultaneously used.
-
Page 30: General
General > SCROLL WHEEL/OK BUTTON > General To access general settings, navigate from AI Service > AI Recommendation Option Description Voice recognition help and Change settings related to speech recognition feaures, such as turning Voice Response on/off. settings Content Recommendations Receive content recommendations based on TV content viewing pattern. - Page 31 Location Option Description Broadcast Country Select the TVs broadcast country. Service Area Postcode Enter your postcode to set the TVs broadcast location. Setting the country Set country manually. manually must be done Services Country when not connected to a Note: setting the country manually must be done when not network.
- Page 32 Safety Option Description Factory Password: 0000 Master Password: 0313 General Switch Turn on to enable lock function. TV Rating Locks Restrict watching programmes based on rating. Programme Locks Select the programmes to lock. Application Locks Select the applications to lock. Input Locks Select the inputs to lock.
- Page 33 Home Settings Option Description Home Auto Launch Set Home to launch automatically when TV is turned on. Additional Settings Option Description Settings Help Turn settings help on/off. (Turning on will show description text of each setting). Menu Transparency Turn on to make some menus (Live Menu, Search etc.) transparent. Turn screen saver on and when screen has had no activity for an hour, the display screen Screen Saver will show a screen saver.
-
Page 34: Accessibility
Accessibility > SCROLL WHEEL/OK BUTTON > Accessibility To access accessibility settings, navigate from Option Description Audio Description Guide menus and operations with voice for visually impaired viewers. Audio Description Audio Description (AD) provides an additional audio track for visually challenged Volume persons (DTV only, subject to program). -
Page 35: Support
Support > SCROLL WHEEL/OK BUTTON > Support To access support settings, navigate from Option Description Software Update Check for system software updates and update if desired. TV Information View device name, serial number, software version and available storage. Notifications Check notifications about user settings or TV status. Additional Settings See table below. -
Page 36: High Dynamic Range (Hdr)
High Dynamic Range (HDR) About the HDR feature High Dynamic Range (HDR) is a picture feature on your TV that attempts to mimic the way visuals are perceived in real life by the human eye. By using this feature, the TV can reproduce greater dynamic range of luminosity by capturing and then combining several different exposures. -
Page 37: Smart Tv
Smart TV Netflix is a streaming service that offers unlimited Before you start using apps, your TV must be connected viewing of a wide variety of award-winning TV shows, to the internet. movies and documentaries. The speed of your internet connection determines the A paid subscription is required. -
Page 38: Web Browser
View currently Block Split Zoom Exit Search open tabs screen in/out browser Web Browser Refresh Using the web browser, you can surf the Internet on the TV similar to how you would do on a PC. NOTE: Use a wired or wireless keyboard and mouse (not provided) for an easier web browsing experience. -
Page 39: Tv Guide
TV Guide (Free to air TV) TV Guide Functions To access the TV guide, press the GUIDE button on the remote. /GUIDE Function Remote Button To activate the TV Channels use the Switch between TV Guide/ Schedule buttons to select a channel List, Channel List and Program List in the left column, then press the SCROLL WHEEL/OK BUTTON to... -
Page 40: Recording
Recording Important Tips: • Back-up your personal data before plugging in your USB to the TV. We do not assume liability for any loss of data due to misuse or malfunction. • You cannot change channels while in recording mode. •... -
Page 41: Using Instant Recording
Using Instant Recording • Connect a USB HDD or USB stick to the USB port on the TV. When watching the live programme, press the SCROLL WHEEL/OK button. • • Press the button on the bottom of the screen to start recording. •... -
Page 42: Programme Scheduling
Programme Scheduling • Press the button on the remote, and select "Guide" on the TV screen. LIST • Select the programme and to record the programme live, select the "Record" or "Watch" button on the screen. • For programmes yet to air, select the "Scheduled Recording" or "reminder" button on the screen. Note: scheduled recording does not guarantee the exact recording time of the programme. -
Page 43: Usb Mode
USB Mode Set up You can only play Photos in the Photo category, and Insert your USB into a USB port on the TV. Music in the Music category. Make sure you select Press the button to select 'USB' mode. the correct category for the file you wish to play. -
Page 44: Viewing Photos And Videos
Viewing Photos and Videos • Press the button on the remote control to access the HOME page. • Select and choose the storage device with the photos and videos to view. • Select and view your photos and videos. • : Select viewing method and type of content. -
Page 45: Video Player
Video Player • Video player will launch when playing your videos. • : Return to content list. • : Display playlist. • : Control video playback functions. • : Rotate video. • : View 360° video (viewing on VR may distort video). •... -
Page 46: Playing Music
Playing Music • Press the button on the remote control to access the HOME page. • Select and choose the storage device. Select songs and add them to "My Playlist". Play your music. • : Select type of content. • : Delete song. -
Page 47: Troubleshooting
Troubleshooting If you experience problems with your TV, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 002 534. Problem Solution Make sure that the batteries are installed with their poles (+/–) in the correct direction. Remove any obstacles between the remote control and remote control sensor on the TV. - Page 48 Problem Solution Ensure that connection to the device is correct and that all cables are fully inserted. There is no picture/ Remove and reconnect all cables connected to the TV and the external devices. Try new cables if possible. sound or distorted Restart the connected devices by unplugging each device's power cord and then plugging it in again.
- Page 49 Problem Solution When using Wi-Fi, make sure the Wi-Fi password is entered correctly. Turn off the access point. Wait for 2 minutes and then turn them back on. Ensure that there are no obstacles between the TV and the access point. (The Wi-Fi strength can be decreased by appliances, cordless phones, stone walls/fireplaces, etc.) Reduce interference by not using or turning off other wireless devices.
-
Page 50: Specifications
Specifications Active screen size With stand: 1367.4 x 152.4 cm (diagonal) 227.6 x 853 mm Dimensions (W x D x H) Resolution 3840 x 2160 Without stand: 1367.4 x 88.1 x 792.6 mm Refresh rate 60Hz 16.3 kg Aspect ratio 16:9 Weight Gross... -
Page 51: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging The packaging of your product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can National Television and Computer Recycling be a suffocation hazard for babies and young children, please ensure all packaging materials are out of Scheme reach and are safely disposed of. -
Page 52: Warranty Information
Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 53: Repair And Refurbished Goods Or Parts Notice
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. - Page 54 Notes...
- Page 55 Notes...
- Page 56 Online support Visit www.bauhn.com.au for software updates to keep your TV up-to-date, as well as the latest User Manual for information on the updated features. Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.
