Bauhn ATVS55-1016 Instruction Manual

55” 4k ultra high definition led lcd smart tv
Hide thumbs
Table of Contents

Advertisement

Quick Links

55" 4K Ultra High Definition
LED LCD Smart TV
Model Number: ATVS55-1016
INSTRUCTION MANUAL
www.tempo.org
1300 886 649
Model: ATVS55-1016 Product Code: 55930 11/2016
AUS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATVS55-1016 and is the answer not in the manual?

Questions and answers

Related Manuals for Bauhn ATVS55-1016

Summary of Contents for Bauhn ATVS55-1016

  • Page 1 55” 4K Ultra High Definition LED LCD Smart TV Model Number: ATVS55-1016 INSTRUCTION MANUAL www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 2 Welcome Congratulations on choosing to buy a BAUHN product. All products ® brought to you by BAUHN are manufactured to the highest standards ® of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty.

  • Page 3: Remote Control

    : Load/unload a disc (DVD) : Pause and start live TV; Start or pause FreeviewPlus catchup videos and USB media playback. : Record program in DTV mode. : Stop playing. : In HbbTV mode, www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 4 Australian channel providers. However, one teletext option, “closed captions”, is still working on most Australian television channels. This service allows you to activate subtitles while watching normal television programs that provide it. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 5 • To enter the numbers and characters shown on the keys in yellow, press the ‘Alt’ button first, followed by the chosen letter button. • As an alternative to the remote control keyboard, you can use the on screen keyboard. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 6 • If the remote control does not work when operated near the TV, replace the batteries. NOTE: • Remove the batteries if the remote control is not going to be used for a long time. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 7: Warranty Details

    You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 8: Table Of Contents

    General Safety Instructions Installation Controls and Connections Getting Started Basic Operations Electronic Program Guide (EPG) Recording Smart Hub Media Mode Menus FAQs Specifications Repair and Refurbished Goods or Parts Notice www.tempo.org viii 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 9: General Safety Instructions

    • To prevent damage which may result in fire or an electric shock hazard, do not expose this appliance to rain or moisture. • Do not change or modify the appliance in any way. • Only use the attachments/accessories specified by the manufacturer. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 10 • Ventilation: Install the unit at an adequate distance from the wall to ensure sufficient ventilation. If the temperature inside the unit rises, it may result in fire. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 11 • Smoke or odour: If you notice any unusual odours or smoke around www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 12 TV, when the TV has been exposed to rain or moisture, does not operate normally, or has been dropped. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 13: Installation

    TV Stand. M6 x 20mm, 2pcs • To avoid any damage to this TV, we recommend you ask someone to Fig 3 help with installation and/or removal of the stand. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 14 NOTE: The screws in the package are for securing the TV stand only. If you are wall-mounting the TV, please consult a professional installer for further instructions on bracket support and wall support. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 15: Controls And Connections

    6. VOL + / - : Increase/decrease the volume level or move left/right. 7. STANDBY: Turn the TV On/Off. NOTE: See next page for a detailed description of all the sockets on the back panel. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 16 TV and any HDMI devices, such as a DVD player, gaming console or A/V receiver. HDMI INPUT with ARC: Allows Audio to transmit from your TV back to an ARC-supported external audio device. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 17 Therefore, the result of up-scalling and displaying HD broadcast signals on a Ultra HD TV can be soft images, which don’t have the detail or smoothness you see when watching the same content on an HD TV. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 18 Connect the Mini AV cable (supplied) to the AV IN 2 socket. Then connect the other end to your external device. NOTE: Mini AV cable’s L/R audio connections are shared between Y/Pb/Pr as well. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 19 USB Connection Insert a USB memory device into the USB port for PVR recording, time-shifting and playback of video/music/photo multimedia files. USB Device (not included) www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 20 • For sound, first connect the Mini AV cable (supplied) to the AV IN 2 socket. Then connect the white and red jacks on the other end to your external device. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 21 (not included) Coaxial (S/PDIF) Connection Use a coaxial cable to connect the unit with an amplifier or other audio decoding device for coaxial audio signal output. (Coaxial cable is not included.) www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 22 Controls and Connections (Cont.) Optical connection Use Optical cable to connect the unit with amplifier or other audio decoding devices for digital audio signal output. (Optical cable is not included) www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 23: Getting Started

    Step One: OSD Language: Use the / buttons to select your OSD language and then press the OK button to go to the next step. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 24 Environment: Use the / buttons to select the environment of your new TV and then press the OK button to go to the next step. Press the MENU button to go to the previous step. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 25 Tuner: Use the / buttons to select the type of scan (DTV+ATV, ATV, DTV ) and then press the OK button to go to the next step. Press the MENU button to go to the previous step. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 26 Press the MENU button to go back to previous steps. Press the OK button to begin scanning for TV stations. To exit channel tuning, press the EXIT button. When auto searching is complete, your TV will show the first channel found. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 27: Basic Operations

    • Press the S-MODE button on the remote control repeatedly to select the sound mode directly (available options: Standard, Music, Movie, Sports, User). Information Display • Press the INFO button to display information about the current program. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 28 TV and Radio mode. Subtitles • Press the SUBTITLE button on the remote control to enter the subtitle menu. NOTE: The program you are watching must support subtitles. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 29: Electronic Program Guide (Epg)

    • Press the button to schedule a recording for the selected RECORD program. • Press the INFO button to display full program information. • Press EXIT to exit the EPG menu. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 30: Recording

    • Use the / buttons to select a recorded file and press OK to start playback in full screen mode. Scheduled Recording (in DTV mode only) See the instructions under EPG on the previous page. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 31 Yes to exit time-shift mode and return to live TV signal, or select No to dismiss the dialogue box. NOTE: The USB storage device will not retain recorded data after exiting the time-shift function. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 32 • Ensure any USB devices connected to the TV do not use/exceed 500mA power rating. • If an “Unsupported File” message is displayed, the file format or codec is unsupported or corrupted. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 33: Smart Hub

    • YouTube • ATV • Facebook • AV1 • AV2 • Twitter • AccuWeather • YPbPr • TerraTV (in Spanish) • HDMI 1/2/3 • USB (MEDIA) • Miracast • DLNA www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 34 If the mobile device prompts for a password, enter 0000. • Your mobile device will connect to the TV and will display the device screen on the TV. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 35 • Then select from either Movie, Music or Photo and press OK to enter it. You will only see supported media files under each category. • Select the files you want to play and press the PLAY button. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 36 To turn off FreeviewPlus, go to Smart Hub > Channels and set the HbbTV setting to OFF. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 37: Media Mode

    OK to select a function such as Previous, • Use the Next, Rotate and Enlarge from the on-screen tool bar. • Press the STOP or EXIT buttons to exit playback & go back to file list page. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 38 When Playing Music Files: buttons, then press OK to select your desired function. The • Use the functions available are: Previous, Next, Rewind, Fast Forward, Pause, Stop, S.Mode, Repeat, Playlist and Info. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 39 • Press the button to play the next file. NOTE: To play your multimedia files, make sure you have selected the correct icon in the main media playback menu. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 40: Menus

    • Press the / buttons to adjust the value. • Press the MENU button to return to the previous menu page. • Press the EXIT button to exit the menu page. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 41 Set the timer in Minutes for when you Timer would like the TV to power off. > 20min > 30min > 60min > 90min > 120min > 180min > 240min www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 42 Off > 1hour > 2hour > TV will go into Standby if there is no Auto 3hour operation. Sleep Daylight On/Off Option to turn daylight saving time On Saving or Off. Time Lock www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 43 Export all hotel lock settings to a USB drive. Import settings Import all hotel lock settings from a USB drive. Lock Turn on/off the functionalities of the Keypad keypad on rear panel. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 44 DTV mode and must be supported by viewing program). Secondary Select the primary subtitle Subtitle language (only available Language in DTV mode and must be supported by viewing program). www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 45 Menus (Cont.) Hearing On/Off Impaired HDMI CEC HDMI CEC / Auto / Off Restore to Reset user menu to factory Default defaults Shipping Retore to factory shipped Condition state www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 46 RJ45 Ethernet cable before starting the setup process. Press the buttons and select “Wired” network type. Then press highlight “Wired”, next press OK and the bellow screen will appear. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 47 Press the EXIT button to exit the menu. If the connection is unsuccessful, the ‘Wired network is not connected’ message will appear. Check the accuracy of information you have entered and try again. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 48 For ‘Wi-Fi Network Connection’, make sure to place your Wi-Fi router close to the TV. Press the buttons and select ‘Wi-Fi’ network type. Then press highlight ‘Wi-Fi’. Press OK and below screen will appear. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 49 To view detailed information, press the YELLOW button. After selecting the WAP, press OK. If the WAP has a security password, enter the password using the on-screen keypad, and then press CONNECT. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 50 If the connection is successful, the ‘Connected to Internet!’ message will appear. Press OK to exit. If the connection is unsuccessful, click the security password of your WAP and its security protocol settings and try again. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 51 MAC Address ---- MAC address of the TV. • Press to save the settings. Enter the WAP password correctly using the on-screen keypad and press connect. Press OK to exit. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 52 Recorded List: Shows the list of recorded programs (you can also use the • INDEX key on the remote to access this page). • Record: Schedule a program to be recorded. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 53 Schedule List: Shows the list of programs scheduled to be recorded. • PVR File System Select Disk If you have multiple partitions on your disk, select the partition you wish to use. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 54 • Format Start Press OK and confirm to format your USB drive. • Speed Check Press OK to check the speed of the USB drive. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 55 Tuning, ATV Channel Tuning, TV Guide, Program Edit, Signal Information and Software Update (USB). Auto Tuning Press OK to enter. Then select your Country, Tuner Type, Logical Channel Number (LCN default is on) and press OK to start scanning. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 56 Menus (Cont.) DTV Channel Tuning Press OK to enter. Press the buttons to select the channel. Press OK to start scanning. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 57 • Press the FAV button to add a channel to your Favourites List; press the button again to remove from the Favourites List. HbbTV • Turn ON/OFF HbbTV. NOTE: If you do not wish to view FreeviewPlus interactive applications, turn HbbTV. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 58 This item is used to display signal details such as Channel Number, Frequency, Quality and Strength. Software Update (USB) • This item is used to update software through a USB memory device. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 59 Off > Low > Middle > High Picture noise reduction Reduction settings. Motion Flow Off > Low > Middle > High Picture motion flow control Control settings. Backlight 0-100 Change the intensity of the backlight. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 60 Select the digital audio output type. Audio Displays the audio codec Language information for the current program. Audio Delay 0-100 Delay the audio output from the TV to match the video www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 61: Faqs

    Disconnect the power plug and then reconnect the main unit and/or it. (The unit may not be operating properly due to the remote control) is lightning, static electricity or some other factors.) effective. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 62 Flash memory-based devices and hard disks (Music/Movie players with HDD) on the market; however, it may not be compatible with certain devices, in particular external self-powered hard disks. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 63: Specifications

    With stand: 1241 × 270 × 764 mm (w x d x h) Dimensions Without stand: 1241 × 84 × 723 mm (w x d x h) Net (With stand): 15.1 kg Weight Gross: 19.3 kg Version Number: Date: 22/08/2016 www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...

  • Page 64: Repair And Refurbished Goods Or Parts Notice

    Tempo (Aust) Pty Ltd ABN 70 106 100 252 PO BOX 6056 Frenchs Forest, Sydney, Australia NSW 2086 Tempo Help Desk: 1300 886 649 (Aust) (Operating Hours: Mon-Fri 08:30AM to 06:00PM EST) Email: info@tempo.org www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 65 This page has been left blank intentionally. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 66 This page has been left blank intentionally. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 67 This page has been left blank intentionally. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
  • Page 68 If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 886 649 before returning it to the store for a refund. www.tempo.org 1300 886 649 Model: ATVS55-1016 Product Code: 55930 11/2016...
