48" 4K Ultra High Definition
LED LCD Smart TV
Model Number: ATVS48-0616
INSTRUCTION MANUAL
www.tempo.org
1300 886 649
Model: ATVS48-0616 Product Code: 52200 06/2016
AUS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATVS48-0616 and is the answer not in the manual?

Questions and answers

Related Manuals for Bauhn ATVS48-0616

Summary of Contents for Bauhn ATVS48-0616

  • Page 1 48” 4K Ultra High Definition LED LCD Smart TV Model Number: ATVS48-0616 INSTRUCTION MANUAL www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 2 Welcome Congratulations on choosing to buy a BAUHN product. All products ® brought to you by BAUHN are manufactured to the highest standards ® of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty.

  • Page 3: Remote Control

    : In HbbTV mode, press the colour buttons to access HbbTV applications (FreeviewPlus catchup TV programs). 20 MUTE: Mute the sound. Press again to restore the sound. 21 S-MODE: Switch the sound mode. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 4 Australian channel providers. However, one teletext option, “closed captions”, is still working on most Australian television channels. This service allows you to activate subtitles while watching normal television programs that provide it. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 5 ‘Alt’ button first, followed by the chosen letter button. • The ‘Del’ button on the keyboard performs the backspace function. • As an alternative to the remote control keyboard, you can use the on screen keyboard. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 6 • If the remote control does not work when operated near the TV, replace the batteries. NOTE: • Remove the batteries if the remote control is not going to be used for a long time. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 7: Warranty Details

    You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 8: Table Of Contents

    General Safety Instructions Installation Controls and Connections Getting Started Basic Operations Electronic Program Guide (EPG) Recording Smart Hub Media Mode Menus FAQs Specifications Repair and Refurbished Goods or Parts Notice www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 9: General Safety Instructions

    • To prevent damage which may result in fire or an electric shock hazard, do not expose this appliance to rain or moisture. • Do not change or modify the appliance in any way. • Only use the attachments/accessories specified by the manufacturer. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 10 • Ventilation: Install the unit at an adequate distance from the wall to ensure sufficient ventilation. If the temperature inside the unit rises, it may result in fire. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 11 • Smoke or odour: If you notice any unusual odours or smoke around the unit, immediately disconnect the unit from the outlet and contact the service centre. Failure to do so may result in fire or electric shock. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 12 TV, when the TV has been exposed to rain or moisture, does not operate normally, or has been dropped. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 13: Installation

    Unplug the power plug first when installing or removing the TV Stand. • To avoid any damage to this TV, we recommend you ask someone to help with installation and/or removal of the stand. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 14 NOTE: The screws in the package are for securing the TV stand only. If you are wall-mounting the TV, please consult a professional installer for further instructions on bracket support and wall support. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 15: Controls And Connections

    5. MENU: Enter the settings menu. 6. SOURCE: Select the input source. 7. STANDBY: Turn the TV on/off. NOTE: See next page for a detailed description of all the sockets on the back panel. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 16 9 ANTENNA INPUT: For connection of the external antenna. 10 USB: Connect a USB storage device for PVR recording and multimedia file playback. 11 Y/Pb/Pr INPUT (COMPONENT): Supports both SD (Standard Definition) and HD (High Definition) picture quality. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 17 For the best picture quality, we recommend connecting the TV set to an external antenna. Antenna Outdoor antenna amplifier Indoor antenna amplifier 75Ω antenna plug goes into the antenna Power plug port in the of antenna back of your amplifier www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 18: Hdmi Connection

    HDMI Connection CVBS (VIDEO IN) HDMI Cable (not included) Use a HDMI cable to connect the unit with other devices to receive high-definition multimedia signal. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 19: Usb Connection

    Controls and Connections (Cont.) USB Connection Insert a USB memory device into the USB port for PVR recording, time-shifting and playback of video/music/photo multimedia files. USB Device (not included) www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 20 • For sound, first connect the AV cable (supplied) to the Composite (CVBS) socket. Then connect the white and red jacks on the other end to your external device. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 21: Internet Connection

    Coaxial (S/PDIF) Connection CVBS (VIDEO IN) Use a coaxial cable to connect the unit with an amplifier or other audio decoding device for coaxial audio signal output. (Coaxial cable is not included.) www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 22: Getting Started

    • Press the EXIT button to exit the menu page. Step One: Language: Use the / buttons to select your On-Screen Display (OSD) language and then press the OK button to go to the next step. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 23 • Select ‘Skip’ and press the OK button to skip the network setup process and move to the next step. You can set up the network later on via the user menu. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 24 • Use the / buttons to select ‘Auto Start’ and press the OK button to begin scanning for TV stations. To exit channel tuning, press the EXIT button. When auto searching is complete, your TV will show the first channel found. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 25: Basic Operations

    • Press the S-MODE button on the remote control repeatedly to select the sound mode directly (available options: Standard, Music, Movie, Sports, Personal). Information Display • Press the INFO button to display information about the current program. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 26: Favourites List

    Subtitles • Press the SUBTITLE button on the remote control to enter the subtitle menu and select the available subtitle language. NOTE: The program you are watching must support subtitles. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 27: Electronic Program Guide (Epg)

    RECORD button to schedule the program for recording. • Press the • Press the INFO button to display full program information. • Press EXIT to exit the EPG menu. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 28: Recording

    • Use the / buttons to select a recorded file and press OK to start playback in full screen mode. Scheduled Recording (in DTV mode only) See the instructions under EPG on the previous page. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 29 Forward from the on-screen tool bar. STOP button on the remote control. • To stop time-shift, press the NOTE: The USB storage device will not retain recorded data after exiting the time-shift function. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 30: Important Notes

    • Ensure any USB devices connected to the TV do not use/exceed 500mA power rating. • If an “Unsupported File” message is displayed, the file format or codec is unsupported or corrupted. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 31: Smart Hub

    Media (access Browse the USB content) Internet Smart TV Applications • Web Browser • YouTube • Facebook • Twitter • Picasa • AccuWeather • TerraTV • Media (access USB content) www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 32: Web Browser

    OK to enter the character. • Use GREEN YELLOW buttons to move the curser left and right. RED button to enter. • Press BLUE button to delete (backspace). • Press www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 33 To turn off FreeviewPlus, go to Menu > TV and set the HbbTV setting to OFF. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 34: Media Mode

    OK to select a function such as Previous, Next, Rotate and Enlarge from the on-screen tool bar. STOP or EXIT buttons to exit playback & go back to file list • Press the page. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 35 When Playing Music Files: buttons, then press OK to select your desired function. The • Use the functions available are: Previous, Next, Rewind, Fast Forward, Pause, Stop, S.Mode, Repeat, Playlist and Info. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 36 • Press the button to play the next file. NOTE: To play your multimedia files, make sure you have selected the correct icon in the main media playback menu. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 37: Menus

    • Press the buttons to adjust the value. Press the MENU button to return to the previous menu page. • Press the EXIT button to exit the menu page. • www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 38 Menus (Cont.) Picture To access the Picture menu, press the MENU button, select PICTURE and then press OK www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 39 / Zoom2 / Just Scan* *HDMI mode only Noise Reduction On / Off Adjust picture noise reduction settings. MPEG Noise Off / Low / Middle / High Adjust picture MPEG noise Reduction reduction settings. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 40 Menus (Cont.) Sound To access the Sound menu, Press the MENU button, select SOUND and then press OK. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 41 Adjust the setting to fix any lip sync issues. S/PDIF Delay (ms) 0-200 Adjust the setting to fix any lip sync issues when the TV is connected to an external amplifier. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 42: Auto Tuning

    Digital Manual Tuning, Channel Edit, Signal Information, Recorded List and Schedule List. Auto Tuning Press the OK button to enter. Then select your Country, Tuner Type, and then press OK to start scanning. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 43: Dtv Manual Tuning

    Menus (Cont.) DTV Manual Tuning Press the OK button to enter. Press the buttons to select the channel. Press OK to start scanning. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 44: Channel Edit

    YELLOW button again to move the channel. • Press the FAV button to add a channel to your Favourites List; press the FAV button again to remove the channel from the Favourites List. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 45: Signal Information

    RED button to delete a recorded program. • Press the • Press the GREEN to reverse the ordering of recorded programs. • Press EXIT to exit the Recordings List. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 46: Schedule List

    • Or, press the GREEN button again to go back to Schedule List. HbbTV • Turn ON/OFF HbbTV. NOTE: If you do not wish to view FreeviewPlus interactive applications, turn HbbTV. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 47: Lock Menu

    • To access the Lock menu, press the MENU button, select Lock and then press OK. • Input the factory default password “0000” using the number buttons on the remote control. • NOTE: If you forget the password, use the master password “4711”. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 48 Block G and above / Block PG and above / Block M and above / Block MA and above / Block AV and above / Block R and above / Block all www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 49 Menus (Cont.) Time To access the Time menu, press the MENU button, select Time and then press OK. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 50 Set the timer in hours to place the TV in Standby. Time Zone (NSW/ACT) / VIC / Select your time zone. Default is QLD / TAS / WA / SA NSW/ACT. / NT www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 51: Network Settings

    RJ45 Ethernet cable before starting the setup process. • Press the buttons and select “Wired” network type. to highlight “Wired”, next press OK and the bellow screen will • Then press appear. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 52 If the connection is unsuccessful, check the accuracy of the information you have entered and your router settings and try again. • Network Info: View network information • Network Test: Check the Internet connectivity status www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 53 ‘Wi-Fi’ and press OK. Press the OK button on ‘Wifi Auto Search’ and the TV will automatically begin searching for nearby Wi-Fi Access Points (WAP). This may take up to 2 minutes. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 54 • Press the MENU button to go back to the main Network settings page. • Network Info: View network information • Network Test: Check the Internet connectivity status • Wi-Fi Status Displays the name of the Wireless Access Point www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 55 (only available in DTV mode and must be supported by viewing program). Subtitle Languages Multiple Select the primary subtitle languages language (only available in DTV mode and must be supported by viewing program). www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 56 Access the First Time Installation wizard. Software Update Update the TV software via USB (USB)* disk. Software Update Update the TV software via the (OTA) Internet. Reset TV Reset all settings to factory defaults. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 57 Usage Mode Home/Shop Select usage mode. Software Update (USB) • Visit the following web page to check for software updates that keep your TV up-to-date: http://www.tempoaustralia.com/support/sw/Bauhn/9073_ATVS48-0616/ update.html www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 58: Faqs

    Noise or other Electronic equipment near the unit is causing interface. interface Relocate the unit or move the equipment. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 59 Flash memory-based devices and hard disks (Music/Movie players with HDD) on the market; however, it may not be compatible with certain devices, in particular external self-powered hard disks. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 60: Specifications

    With stand: 1097 × 254 × 706 mm (w x d x h) Dimensions Without stand: 1097 × 92 × 642 mm (w x d x h) With stand: 12.16 kg Weight Without stand: 11.92 kg www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 61: Repair And Refurbished Goods Or Parts Notice

    Tempo (Aust) Pty Ltd ABN 70 106 100 252 PO BOX 6056 Frenchs Forest, Sydney, Australia NSW 2086 Tempo Help Desk: 1300 886 649 (Aust) (Operating Hours: Mon-Fri 08:30AM to 06:00PM EST) Email: info@tempo.org www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 62 This page has been left blank intentionally. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...
  • Page 63 This page has been left blank intentionally. www.tempo.org 1300 886 649 Model: ATVS48-0616 Product Code: 52200 06/2016...

  • Page 64: Software Updates

    If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on 1300 886 649 before returning it to the store for a refund. www.tempo.org Model: ATVS48-0616 Product Code: 52200 06/2016...
