CUFF PLACEMENT

• Place cuff at the same level as
your heart, about 1-2 centimeters
above the elbow joint.
• Position the tube in the middle of
your arm, in line with your middle
finger.
• The cuff should be snug but
comfortable.
BODY PLACEMENT FOR
MEASUREMENT
• Seated – Place arm, palm-up,
on flat surface. Feet flat on
floor. Cuff level with heart.
Press START/STOP to turn the
monitor on. After the display
shows "00", blood pressure
measurement will begin
automatically. To turn off the
monitor when measurement
is complete, press START
again or wait 1 minute for
automatic shutoff.

GETTING STARTED

• Setting Date and Time

The device displays time and date on the LCD. They can be set according to the
following method:
1. Hold the SET button for 5 seconds until digits on the screen start flashing.
2. Press the SET button to switch between month, date, hour and minute.
3. Press the MEM (Memory) button to advance the display selected by one digit
at a time.
4. When the unit is powered off, the clock will continue to display on the LCD screen.

• Setting Alarm Clock

1. Hold the SET button for 5 seconds until digits on the screen start flashing.
2. Press the SET button to advance the screen from the Date, Time,
and Talking Feature.
3. The Screen will have a small bell located in the upper left hand corner
of the screen.
4. Press the MEM (Memory) button to change the Alarm Clock from OFF to ON.
5. Once ON, press the SET button to switch to the time located above "ON"
on the LCD Screen
6. Press the MEM (Memory) button to change the hour digit.
7. Once the hour is set, press the SET button to move to the minute digits.
8. Press the MEM (Memory) button to change the digits.
9. Once the alarm is set and turned on, a small bell icon will appear in the top
left hand corner of the screen when the unit is powered off.
See the enclosed Manual for further details and instructions.
The cuff plugs in on the LEFT side of the machine. The port on the RIGHT is for use
with an A/C adapter (included).

IMPORTANT!

You can stop the inflation or deflation of the cuff at any time by
pressing the START button.
Please read the Manual for this monitor prior to using. If you have any
questions or are experiencing difficulties, please call the Medline Service
Center at 1-800-MEDLINE (1-800-633-5463). RL17CN1

TIPS FOR TAKING YOUR BLOOD PRESSURE

The right size cuff should not feel
1.
too loose or tight. Place cuff on
arm with the tubing lined up with
your middle finger.
2. Secure the cuff snugly with hook
& loop closures, allowing room for
no more than two fingers.
3. Sit quietly for five minutes before
testing. Support the back
and let feet rest on floor, keeping
legs uncrossed.
4. Keep the arm and body still
and avoid talking during the
measurement process.
5. Keep the arm being tested at
heart level and let the other arm
relax in a comfortable position.
