Reset Mode - MULTISPAN MPD-192 Manual

Under Current
Power On:- 5 Sec
Initial Time Delay:- 5 Sec
Under Current:- Enable
3.0A
2.0A
1.0A
5 10 15 20
0
ON
OFF OFF
Under
Power
Current
ON
ITD
Delay

Reset Mode:

1) If Reset Mode Selected is Manual, then the Fault
will Reset Manually by pressing the Reset key on
the instrument.
2) If Reset Mode Selected is Auto, then the Relay will
be reset after Selected Reset time once the healthy
condition achieved.
3) If Reset Mode Selected As ZVR (Zero Value Reset),then
the Relay will be reset after Selected Reset time once
the healthy condition achieved OR Zero Value reached.
Initial Trigger:
1) If Initial trigger mode "I"is selected then Relay will
start working once current is applied.
2) If Initial trigger mode "V" is selected then Relay will
start working once Voltage is applied.
Relay Fault:
1) If Relay fault selected is "off" than Relay will turn
"off" when fault is achieved, otherwise Relay will
remain turn "on".
2) If Relay fault selected is "on" then Relay will turn
"on" when fault is achieved, otherwise Relay will
remain turn "off".
Under Current:- 3.0A
Under Current time:- 5 Sec
Relay Fault:- OFF
Reset Mode:- Auto
Reset Time:- 5 Sec
25 30 35 40
ON
OFF
Under
Current
Reset ITD TRP
Delay
NOTES
Lock Rotor Point
Power On:- 5 Sec
Intial Time Delay:- 5 Sec
Lock Rotor Point:- Enable
Over Current:- Diseble
Case-1
R,B Phase
5A
Y Phase
4A
3A
2A
0
Relay
Power
Time
ON
Case-2
5A
4A
3A
2A
0
Relay
OFF
Power
Time
ON
Specifications are subject to change, since development is a continuous process,
5 10 15 20
ON
OFF
OFF
ITD
TRP
5 10 15 20
ON
OFF
ITD
TRP
So for more updated operating information and Support,
Please contact our Helpline: 9081078683/9081078681 or
Email at service@multispanindia.com
Lock Rotor Point:- 2.0
Over Current Value:- 2.0A
Relay Fault:- OFF
Reset Mode:- Auto
Reset Time:- 5 Sec
R,Y Phase
Lock Rotor Point
B Phase
25 30
TIME
B Phase
R,Y Phase
25 30
TIME
Ver:201101
