Gree rio RIO12HP115V1A Owner's Manual

High-wall ductless air conditioning & heating system
Hide thumbs Also See for rio RIO12HP115V1A:

Advertisement

Quick Links

HIGH-WALL DUCTLESS
AIR CONDITIONING &
HEATING SYSTEM
OWNER'S MANUAL
Models:
RIO09HP115V1A
RIO12HP115V1A
RIO09HP230V1
B
RIO12HP230V1
B
RIO18HP230V1A
RIO24HP230V1A

Advertisement

loading
Need help?

Need help?

Do you have a question about the rio RIO12HP115V1A and is the answer not in the manual?

Questions and answers

Related Manuals for Gree rio RIO12HP115V1A

Summary of Contents for Gree rio RIO12HP115V1A

  • Page 1 HIGH-WALL DUCTLESS AIR CONDITIONING & HEATING SYSTEM OWNER'S MANUAL Models: RIO09HP115V1A RIO12HP115V1A RIO09HP230V1 RIO12HP230V1 RIO18HP230V1A RIO24HP230V1A...

  • Page 2: Table Of Contents

    You can feel confident in your selection because the same pride in craftsmanship and engineering knowledge that goes into millions of other Gree installed products worldwide has gone into your unit. Please read this owner’s manual carefully before operation and retain it for future reference.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS Please read the following before operation. Recognize safety information. This is the safety-alert symbol. When you see this symbol on the unit and in instructions or manuals, be alert to the potential for personal injury. Understand these signal words: DANGER, WARNING, and CAUTION. These words are used with the safety-alert symbol.
  • Page 4 SAFETY PRECAUTIONS Please read the following before operation. WARNING • Disconnect electrical power to the rio system before performing any maintenance or cleaning. • Do not attempt to repair the rio system yourself. Incorrect repairs may cause electric shock or fire. Contact a qualified service technician for all service requirements. •...

  • Page 5: Part Names

    PART NAMES Indoor unit Part Name 1. Remote Controller 2. Front Panel 3. Air Filter 4. Horizontal Louver 5. Wall Hole Sleeve 6. Insulation 7. Refrigerant Pipes 8. Drain Hose Outdoor unit...

  • Page 6: Operation Of Wireless Remote Controller

    OPERATION OF WIRELESS REMOTE CONTROLLER REMOTE CONTROLLER OPERATIONS The rio universal wireless remote controller is sleek, versatile and allows you to change room temperatures and functions on unit from the palm of your hand. The large LCD display and buttons make it easy-to-understand and easy-to-use. The remote controller may be used for several rio units.
  • Page 7 OPERATION OF WIRELESS REMOTE CONTROLLER Signal Transmitter ON/OFF Button MODE Button FAN Button...
  • Page 8 OPERATION OF WIRELESS REMOTE CONTROLLER REMOTE CONTROLLER FUNCTIONS LIGHT Button • Press the LIGHT button to turn On or Off the display on the indoor unit front panel. When the indoor unit first powers on, the front panel display will default to ON.
  • Page 9 OPERATION OF WIRELESS REMOTE CONTROLLER – Button + Button X-FAN Button LIGHT Button TURBO Button...
  • Page 10 OPERATION OF WIRELESS REMOTE CONTROLLER TIMER Button • Press the TIMER button to activate TIMER mode and the HOUR ON/OFF icon will begin blinking. Pressing + or - button changes time setting from 0.5 to 24 hours. Press TIMER button to confirm settings. TEMP Button •...
  • Page 11 OPERATION OF WIRELESS REMOTE CONTROLLER VERTICAL SWING LOUVER Button TIMER ON/OFF Button TEMP Button SLEEP Button...
  • Page 12 OPERATION OF WIRELESS REMOTE CONTROLLER The wireless remote controller is the interface between the user and the rio system. Commands are entered by the user to control the system. Any command that has been entered with the remote controller will remain in memory until it is changed by the user or the batteries are replaced.
  • Page 13 OPERATION OF WIRELESS REMOTE CONTROLLER MODE BUTTON : AUTO Use the “MODE” button to select one of the available modes. The selected mode will be displayed on the remote controller : COOL and the appropriate light will illuminate on the display panel. : DRY AUTO –...
  • Page 14 OPERATION OF WIRELESS REMOTE CONTROLLER VERTICAL SWING LOUVERS • Press the Vertical Swing Louver button to select five different vertical (up & down) air discharge directions including Continuous Sweep. The Vertical Swing Louver icon will be displayed. Press this button to set swing angle, which circularly changes as below: Swing Louver Display Indicates louver swings back and forth in the five...
  • Page 15 OPERATION OF WIRELESS REMOTE CONTROLLER TURBO MODE The desired setpoint, either in heating or cooling, can be achieved faster if TURBO mode is used. After selecting the “HEAT” or “COOL” mode button, push the “TURBO” button. The TURBO icon will be displayed on the remote controller and the unit will run at ultra high speed fan.
  • Page 16 OPERATION OF WIRELESS REMOTE CONTROLLER CHANGING BATTERIES AND ADDITIONAL NOTES To change batteries, slide cover off battery compartment on back of remote controller. Remove and safely discard old batteries. Insert two new AAA 1.5V dry batteries, using correct polarity. Reattach back cover. NOTE: •...

  • Page 17: System Functions

    SYSTEM FUNCTIONS TIME GUARD The rio System is equipped with many system safeties to provide safe, reliable operation and comfort. The Time Guard function prevents rapid cycling of the compressor. The system has a protective 3-minute time delay to restart the compressor after it has turned off. INTELLIGENT DEFROST The rio Intelligent Defrost function increases room comfort and saves energy by eliminating unnecessary defrost cycles.

  • Page 18: Cleaning And Caring For Your Unit

    CARE AND CLEANING WARNING CAUTION WARNING CAUTION • Turn off power and disconnect unit from power source before cleaning. Failure to do so could cause electric shock. • Never spray water on either indoor or outdoor unit. This could cause damage or unit failure. •...
  • Page 19 CARE AND CLEANING CLEANING THE PRIMARY AIR FILTER Cleaning is recommended every three months. NOTE: If the indoor unit is exposed to excessive dust, cleaning may be necessary more often. Use caution when removing the filter to avoid sharp metal extensions. 1.

  • Page 20: Troubleshooting

    TROUBLESHOOTING WARNING CAUTION WARNING WARNING Do not attempt any repairs on the unit yourself. Incorrect repair can cause shock or fire. Always call a qualified service professional. Using these troubleshooting suggestions can save time when you contact the qualified service professional. PROBLEM CAUSE/SOLUTION System does not restart.
  • Page 21 TROUBLESHOOTING TROUBLESHOOTING PROBLEM CAUSE/SOLUTION Wireless remote controller Cause: There are a number of possible reasons. lost or does not work. Solution: Check the following: • The batteries might be low. Change the batteries. • The remote controller must be within 25 ft. (7.6 m) with no obstructions of the indoor unit.
  • Page 22 SYSTEM OPERATION COOLING OPERATION How it works: In cooling mode, your rio indoor unit will absorb heat from the room, then the rio outdoor unit will discharge the heat to the outdoors. The rio cooling capacity decreases as the outdoor temperature increases. This causes the rio to work harder and longer to hold the selected room temperature.

  • Page 23: System Operations/Energy Saving Tips

    ENERGY SAVING TIPS 1. Relaxing room temperature at night is OK: During the nighttime hours you don't require the same level of conscious cooling or heating. Try using Sleep Mode to gradually relax room temperature and allow the unit to run less and save energy. 2.
  • Page 24 LIMITED WARRANTY GREE distributor (hereinafter “Company”) warrants this product against failure due to defect in materials or workmanship under normal use and maintenance as follows. All warranty periods begin on the date of original installation. If the date cannot be verified, the warranty period begins one hundred twenty (120) days from date of manufacture.
