- Page 1 2005CD Installation Guide IG 001 / Rev. 1.9 This installation guide describes the hardware of the eWON 2005CD and explains how to get started with support.ewon.biz...
-
Page 2: Table Of Contents
1.3.5. Programmable Industrial Router functions ............... 5 1.4. Typical applications ........................6 1.5. Part Numbers and internal options .................... 6 2. eWON technical documentation ..................7 3. Housing & markings ......................8 3.1. Housing interfaces ........................8 3.2. Markings ............................ 9 3.3. - Page 3 A.9 - PSTN/ISDN Phone line connector ..................33 A.10 - Antenna ..........................34 A.11 - Antenna for HSUPA EW2620B [Since S/N 1537-0108-xx included] ........35 Revision ..........................36 Revision History ..........................36 Page 3 / 36 eWON 2005CD | IG 001...
-
Page 4: Product Description
The eWON2005CD™ can optionally embed a modem (PSTN, ISDN, GPRS-EDGE or HSUPA). The eWON range supports the TCP/IP and PPP protocols. This brings you all the benefits of an universally recognized standard network. It also allows you to use popular software tools like Internet Explorer, FTP client, SNMP Manager, Mail Recipient …... -
Page 5: Functions Of The Ewon2005Cd
FINS TCP to FINS Host link • ISOTCP to PPI (optionally MPI) • VCOM / ASCII • 1.3.5. Programmable Industrial Router functions Automatic routing of protocols • Programmable routing from I/O and Tag names (BASIC) • Page 5 / 36 eWON 2005CD | IG 001... -
Page 6: Typical Applications
Remote programming • Interface for Application Service Providers (ASP) • 1.5. Part Numbers and internal options Part Number structure of the eWON product range: EWaabzm aa = Type of hardware platform 26 = eWON2005CD™ b = Power Supply 2 = Low voltage 12-24DC... -
Page 7: Ewon Technical Documentation
How to do a PING function with Basic • eWON serial number structure • eWON modem type • • All those manuals are available for download in PDF format on the eWON website: http://support.ewon.biz. Page 7 / 36 eWON 2005CD | IG 001... -
Page 8: Housing & Markings
Housing & markings 3. Housing & markings 3.1. Housing interfaces (*) For HSUPA modem with part number EW2620A only, the SIM card drawer is located on eWON top side. See Embedded HSUPA modem Page 8 / 36 eWON 2005CD | IG 001... -
Page 9: Markings
Housing & markings 3.2. Markings The identification label of the eWON is placed at the left hand side of the housing. The label is composed of the following fields: The eWON Serial Number (SN) is an important traceability tool both for the user and for the manufacturer. -
Page 10: Safety, Environmental & Regulatory Information
Rules. Operating is subject to the following two conditions: 1. This device may not cause harmful interference 2. This device must accept any interference received* (*including interference that may cause undesired operation) Page 10 / 36 eWON 2005CD | IG 001... -
Page 11: Certifications
At least 20 cm (7.88”) separation distance between the antenna and the user’s body must be • maintained at all times. The eWON and its antenna must not be collocated or operating in conjunction with any other • transmitter or antenna. -
Page 12: Mechanical Outline
The eWON must be fastened on a 35mm DIN rail compliant with EN50022. To put the unit in place, insert the upper slider into the upper part of the rail, with the eWON™ tiled around 20°. Then push and rotate the eWON™ downward to put the unit right. -
Page 13: Mounting & Environmental Conditions
0-80% non-condensing 3.7. Preparing the installation The recommended free space in the cabinet for the eWON should be at least: 80-mm wide x 200-mm high x 160-mm deep (terminal block excluded). A piece of rigid DIN-rail profile (flat 35mm wide) of suitable length should be firmly fastened, horizontally, in the middle of the area. -
Page 14: Specification For External Power Supply Selection
Equipment Supplied by Class 2 or Level 3 Power Supply. 3.8.1. Auto-fuse An auto fuse placed just after the power input protects the eWON devices against short circuits. This component returns by itself to its normal state when the short circuit has disappeared and after the component has been cooling down. -
Page 15: Front Panel Control Led's
Chapter 4 Front panel control LED's 4. Front panel control LED's Front panel LED's description Page 15 / 36 eWON 2005CD | IG 001... -
Page 16: Specifications Of Communication & I/Os Interfaces
See PSTN/ISDN Phone Line Leased Line mode 5.3. Embedded ISDN Modem (optional) Specification PSTN 56k ISDN specification ISDN BRI S0.I.430 Type 1B+D Max baud rate 64 Kb Certification - - - Page 16 / 36 eWON 2005CD | IG 001... -
Page 17: Embedded Gprs-Edge Quad-Band Modem (Optional)
2 Tightening torque for SMA antenna connector: MAX 0.5N.m (manual tightening should be used as a reference) Antenna. 3 Tightening torque for SMA antenna connector: MAX 0.5N.m (manual tightening should be used as a reference) Antenna. Page 17 / 36 eWON 2005CD | IG 001... -
Page 18: Embedded Umts Modem (Optional)
R&TTE, CE, FCC Certificate number - - - Antenna connector (*) Type SMA-F (*) Tightening torque for SMA antenna connector: MAX 0.5N.m (manual tightening should be used as a reference) Antenna. Page 18 / 36 eWON 2005CD | IG 001... -
Page 19: Sim-Card Installation
• GPRS quad band Modem • UMTS Modem • UMTS/HSUPA Modem with part number EW2620B For HSUPA modem with part number EW26206B only, the SIM-card drawer is located on the top of the eWON. Page 19 / 36 eWON 2005CD | IG 001... -
Page 20: Configurable Serial Port
(typ 680 Ohms) and termination (typ 120 Ohms) resistors. This configuration applies only to RS485/RS422 lines conforming to good practices. WARNING The switch 2 is reserved and must stay OFF. Page 20 / 36 eWON 2005CD | IG 001... -
Page 21: Mpi Port
5Vdc. A one logic (ON) state is detected when the input level is above 10Vdc. WARNING The logic level is undefined when the input is ranging between 5 and 10VDC. Page 21 / 36 eWON 2005CD | IG 001... -
Page 22: Digital Output
This digital output is activated by an open drain MOSFET transistor driven by an optocoupler. The maximum current flow into this transistor has a characteristic above the value specified in the eWON, in order to cope with the switching power losses. The transistor used is in an open drain type with pre drive. -
Page 23: Ip Parameters Configuration
WARNING Normally you cannot communicate with a device of which you don’t know the IP parameters. Therefore, there is a special tool (called “eBuddy”) you can download from the eWON Internet site http://www.ewon.biz. Start this application once you have connected your eWON to the network. The application will scan the whole network and will identify all eWONs that are connected, including their IP parameters (Address and subnet mask) and their serial number. -
Page 24: Resets
IP parameters configuration 6.1. Resets WARNING You should not reset your eWON unless you have been told to do so by someone of our technical support. The concerned files (differs depending on reset type) are totally lost and unrecoverable after being formatted. - Page 25 You absolutely have to wait until the full auto test procedure is completed without interrupting it. If the auto test is interrupted, the flash memory of the eWON will contain random data likely to make it unstable. In such a case you have to redo the full reset procedure from scratch and wait until it is totally completed.
-
Page 26: Appendix A - Pin-Outs & Connections
The Ethernet LAN is a four ports auto-sense Ethernet switch (10/100 Mb). Auto-sense means that you can use both direct and crossed cables. Color & Description Activity No LINK GREEN Fixed LINK GREEN Blinking Activity (RX or TX) Page 26 / 36 eWON 2005CD | IG 001... -
Page 27: Ethernet Wan
Pin-outs & connections A.2.2 - Ethernet WAN The eWON can be accessed by a 10/100BaseTX Ethernet connection. This connection can be made with two different cables (straight or crossed). These cables have 8 copper conductors and are known as UTP Class 5 with RJ45 terminations at both ends. -
Page 28: Direct Connection
Pin-outs & connections A.3 - Direct connection If the eWON is connected directly to a PC, then use the crossover cable: Crossover Cable As the LAN interface is “auto sense”, you can use a crossover or straight Ethernet cable, but generally, a direct connection is done with a crossed cable. -
Page 29: Connection Over Hub/Switch/Router
Appendix A - Pin-outs & connections A.4 - Connection over Hub/Switch/Router If the eWON is connected to a Hub/Switch, it has to be connected like any other device, with a straight cable. Straight Cable Again, the wiring is as shown on the following picture, and care should be taken to keep the RX and TX signals on twisted pairs A.5 - RJ-45 Connector... -
Page 30: Inputs/Outputs
Output digital signal connected to the drain of the MOSFET transistor DO-VDC Common of the external predrive Power Supply Between +12 & +24 VDC DI_GND Ground of the input “Isolated” Input digital signal Page 30 / 36 eWON 2005CD | IG 001... -
Page 31: Serial Port
A.7 - Serial Port Mating female connector (not included): Type: Female DB9 with 4/40 blocking screws Pin-out Serial port (according to mode): RS232 RS485 RS422 RX + TX + RX - TX - Page 31 / 36 eWON 2005CD | IG 001... -
Page 32: Mpi Port
Appendix A - Pin-outs & connections A.8 - MPI Port Mating male connector (not included): Type: Male DB9 with 4/40 blocking screws MPI port pin-out (DB9 female): B (+) A (-) Page 32 / 36 eWON 2005CD | IG 001... -
Page 33: Pstn/Isdn Phone Line Connector
TX + RX + RING RX - TX - The ISDN modem in the appliance shall be connected to the telephone line via an ISDN adapter with adequate insulation from TNV3. Page 33 / 36 eWON 2005CD | IG 001... -
Page 34: Antenna
50 Ohms Devices conformity has been assessed with the reference antenna : Kinsun 6602G01081. eWON reference for the antenna is EW40923 or EW40922 for the antenna with a 2 meters length extension cable. The use of different antenna may affect the compliance of the product. -
Page 35: Antenna For Hsupa Ew2620B [Since S/N 1537-0108-Xx Included]
SMA-F Tightening MAX 0.5N.m (manual tightening should be Torque used as a reference) Antenna specifications: For eWON with UMTS/HSUPA modem (EW2620B), the antenna specification is as follows: Specification Value Type Penta band 850/900/1700/1900/2100MHz Impedance 50 Ohms For products with Penta-band HSUPA modem, the conformity assessment has been performed with the reference antenna : Taoglas TG.09.0113. -
Page 36: Revision
Note concerning the warranty and the rights of ownership: The information contained in this document is subject to modification without notice. Check http://support.ewon.biz for the latest documents releases. The vendor and the authors of this manual are not liable for the errors it may contain, nor for their eventual consequences.
