- Page 1 1000 Installation Guide Rev 3.0 COOL INTERNET TELECONTROL SOLUTION...
-
Page 2: Table Of Contents
By Phone line or GSM ................15 Access to the eWON Technical Support ..............16 Appendix A: Ethernet cabling..................17 Direct PC connection.................17 Hub connection ..................19 RJ45 connector ..................19 eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 2... -
Page 3: Hardware Description And Product Identification
1000 Installation Guide Hardware description and product identification Assembly description PHONE LINE PG7 DIGITAL INPUTS POWER SUPPLY PG11 PG11 Figure 1 : eWON general description eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 3... -
Page 4: Product Identification
1000 Installation Guide Product identification The eWON unit is labeled on its front face as shown above. The label looks as follows: Figure 2 : eWON serial number label The eWON Serial Number (SN) is an important traceability tool both for the user and for the manufacturer. -
Page 5: Mechanical Dimensions
Figure 3 : eWON mechanical dimensions Location, environmental conditions The eWON unit has an IP65 protection grade. It is therefore suited for industry wall mounting. Though the equipment meets CE emission and immunity requirements for EMC, it should not be exposed to excessive electromagnetic fields. - Page 6 1000 Installation Guide The recommended free space on the wall for the eWON should be at least: 250-mm wide x 225-mm high x 200-mm deep (terminal block excluded). Grounding : It is essential to make sure the eWON® is correctly grounded through a low impedance connection.
-
Page 7: Digital Inputs - Counters Inputs
Common Ground Common Ground Common Ground Common Ground Common Ground Row C Common +24 VDC Common +24 VDC Common +24 VDC Common +24 VDC eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 7... -
Page 8: Figure 4 : Input Range
The logic level is undefined when the input is ranging between 5 and 10Vdc. Note: Maximum 200mA can be supplied by the 24VDC power supply. eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 8... -
Page 9: Power Supply
Ground EARTH Phase 2 Table 3 : power supply pin assignment Power Supply characteristics : Specification Value Operating voltage 230VAC Frequency 40-60 Hz eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 9... -
Page 10: Phone Line
Table 4 : power supply characteristics Fuse specifications: Specification Value Type Slow – i²t=TBD Operating voltage/ current 230VAC/ 2.2A Table 5 : fuse specifications Phone Line Location eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 10... -
Page 11: 1.09 Ethernet
Table 7 : modem characteristics 1.09 Ethernet Location Please refer to appendix A for further information on the Ethernet RJ45 connector. 1.10 GSM Antenna Location: eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 11... -
Page 12: Table 8 : Gsm Antenna Characteristics
1000 Installation Guide Connector type: Type: Standard female SMA connector. Antenna characteristics: Specification Value Manufacturers Table 8 : GSM antenna characteristics eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 12... -
Page 13: 1.11 Install Your Sim Card
(see picture) and insert the SIM card, as shown on the picture. Back of the components plane Figure 5: SIM card placeholder SIM card SIM card placeholder placeholder extractor eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 13... -
Page 14: Set The Ewon Tcp/Ip Address
To find the TCP/IP address of an eWON, just put it on your Ethernet network (it must be located in the same switch area) and launch eWONCfg.exe. eWONCfg will scan automatically all the devices connected to the network and identify all eWON providing their TCP/IP address and serial number. -
Page 15: Make A Connection With The Ewon
13. You should see the eWON welcome web page. Important : The eWON device, like a PC gets a different TCP/IP address for each of its network interfaces. If your eWON includes a modem, it has two different IP eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa... -
Page 16: Access To The Ewon Technical Support
Another important thing to understand is the client allocated IP address (§5.2.3). Indeed, as when you connect your PC to your Internet Service Provider (ISP), the eWON assigns an IP address to the PPP interface of your PC. This address has to be configured at an address outside your computer's network IP address range. -
Page 17: Appendix A: Ethernet Cabling
The cable type depends on the device connecting the eWON1000. It can be, in most case, a Personal Computer running windows or a company hub. Direct PC connection If the eWON is connected to a computer without the use of a hub, the cable has to be crossed: Crossed cable When cabling over long distance, you have to take care of the twisted pairs. - Page 18 1000 Installation Guide Pins 4, 5, 7 and 8 do not have to be connected. The following picture shows the twisted pair connections: eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 18...
-
Page 19: Hub Connection
1000 Installation Guide Hub connection If the eWON is connected to a hub, it has to be connected like any other device, with a straight cable. Again, the wiring is as shown on the following picture, and care should... -
Page 20: Ewon3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©Act'l Sa Docref: Ew1000Inuk30.Doc Page
Figure 4 : input range ....................8 Figure 5: SIM card placeholder..................13 Figure 6 : eWON IP address configuration with eWONCfg ........14 Figure 7 : Dial-up Networking location ...............15 eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 20... - Page 21 Table 5 : fuse specifications ..................10 Table 6 : Modem pin assignment................11 Table 7 : modem characteristics ................11 Table 8 : GSM antenna characteristics ..............12 eWON3 1000® – Installation Guide – Rev. 3.0 – 7/24/2002 ©ACT’L sa Docref: EW1000INUK30.doc Page : 21...
