Setting the network

• This product supports DHCP (Dynamic Host Configuration Protocol) only. Before connecting the router to the Wi-Fi
kit, check whether the DHCP server option function of your wired/wireless router is activated.
NOTE
• Select a channel for wired/wireless router. The channel should be currently not in use.
• For the authentication/encryption protocols for wireless/wired access points, WPA/TKIP and WPA2/AES are
recommended. New Wi-Fi authentication specifications and non-standard Wi-Fi authentication protocols are not
supported.
• The quality of wireless network connection can be affected by surrounding wireless circumstance.
• If an internet service provider permanently registered the user's PC or MAC address (Identification number) of the
modem, the Wi-Fi kit may not be connected to the internet. Please contact the internet service provider and inquire
about the internet connection process to connect a device (e.g. air conditioner) to the internet.
• If the internet service provider requires ID or password to be connected to the internet, the Wi-Fi kit may not be
connected to the internet. In this case, you need to enter ID or password every time you connect the internet.
• Internet may not be available due to the firewall. Please contact the internet service provider and request the
solution.
• Since some wired/wireless router can send abnormal DNS (Domain Name Server) even though internet is
connected, the Wi-Fi kit may not be connected to internet. In this case, contact the suppliers of wired/wireless
router or internet service provider.
• If you followed what the internet service provider directed but cannot be still connected to the internet, contact
Quietside/Samsung Tech support 888-699-6067.
• If the wired/wireless router is connected to the Wi-Fi kit but the router is not connected to the internet, the lamp of
Wi-Fi kit( ) blinks.

Specification of wired/wireless router for Samsung Smart Air conditioner

Please refer to the user manual for installation of your wired/wireless router.
Wi-Fi kit supports Wi-Fi 2.4 GHz only.
The product supports the IEEE802.11 b/g/n (2.4 GHz), Soft-AP communication protocol.
(Samsung recommends IEEE802.11n.)
If the wired/wireless router is not Wi-Fi certified product, it may not be connected to the Wi-Fi kit.
The certified wired/wireless router has Wi-Fi CERTIFIED logo on the product package or in the user manual.
