Summary of Contents for IKEA HOGKLASSIG
- Page 1 HÖGKLASSIG...
- Page 2 ENGLISH Please refer to the chapter IKEA GUARANTEE for contact details of the after sales customer service centre.
- Page 3 ENGLISH...
-
Page 4: Table Of Contents
Technical data Electrical connection Energy efficiency Product description Environmental concerns Daily use IKEA guarantee Flexible induction cooking area Cooking table Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage. - Page 5 ENGLISH Keep children and pets away from the appliance when it • operates or when it cools down. Accessible parts may become hot during use. If the appliance has a child safety device, it should be • activated. Children shall not carry out cleaning and user maintenance •...
-
Page 6: Conditions Of Use
ENGLISH If the glass ceramic surface / glass surface is cracked, switch • off the appliance and unplug it from the mains. In case the appliance is connected to the mains directly using junction box, remove the fuse to disconnect the appliance from power supply. - Page 7 ENGLISH Electrical Connection fuses removed from the holder), earth leakage trips and contactors. Warning! Risk of fire and electric • The electrical installation must have an shock. isolation device which lets you disconnect the appliance from the mains at all poles. •...
- Page 8 ENGLISH • Used oil, that can contain food remnants, • Do not use water spray and steam to can cause fire at a lower temperature clean the appliance. than oil used for the first time. • Clean the appliance with a moist soft •...
-
Page 9: Installation
ENGLISH Installation General information min. 520 mm 590 mm 500 mm 560 ±1 490 ±1 min. min. 28 mm min. 50 mm 55 mm min. 5 mm max. R 5 mm min. 28 mm • If there is no oven beneath the hob, Installation process must follow install a separation panel under the the laws, ordinances, directives... - Page 10 ENGLISH According to IEC regulations use for one- • The earth lead is connected to terminal phase connection: mains cable 3 x 4mm² and must be longer than leads carrying and for two-phase connection: mains electric current. cable 4 x 2.5mm². Please respect specific •...
-
Page 11: Product Description
ENGLISH cooking zone and set the power setting for symbol comes on each zone to the maximum level for a short the display after you switch on time. the hob for the first time, refer to "Troubleshooting". Product description Cooking surface layout Single cooking zone (170 x 265 mm) 2300 W, with Booster 3200 W Single cooking zone (170 x 265 mm) 2300... - Page 12 ENGLISH Control panel layout 1 2 3 4 To switch the appliance on / off. To activate and deactivate Bridge. To activate and deactivate Pause / To activate Booster. Child Lock. To set a power setting: 0 - 9. To activate and deactivate Pre-Set To select Timer functions.
-
Page 13: Daily Use
ENGLISH Residual heat indicator Use residual heat for melting and keeping food warm. Warning! Risk of burns from residual heat! After you switch off the appliance, the cooking zones need some time to cool down. Look at the residual heat indicator Daily use Adjusting the power setting Switching on / off... - Page 14 ENGLISH • Touch for 4 seconds. The symbol comes on. • Switch off the appliance with To deactivate the function: • Switch on the appliance with . Do not set the power settings. Touch for 4 seconds. The symbol comes on. Touch of the Timer to set the time •...
-
Page 15: Flexible Induction Cooking Area
ENGLISH • Each phase has a maximum electricity loading of 3700 W. • The function divides the power between cooking zones connected to the same phase. • The function activates when the total electricity loading of the cooking zones connected to a single phase exceeds 3700 •... - Page 16 ENGLISH two left side power selectors. 100-160mm Correct cookware position: Place the cookware with the bottom diameter larger then 160 mm centrally between two sections. Incorrect cookware position: > 160 mm Multi-Flexi mode 2 + 2 sections This mode is active when you switch on the hob.
- Page 17 ENGLISH cooking zone. The one front section is not connected and operates as a separate cooking zone. You can set the power setting for each zone separately. Use two left side power selectors. Multi-Flexi mode 4 sections To activate the mode press until you see the correct mode indicator.
- Page 18 ENGLISH You can decrease the power setting by moving the cookware in the middle or to the rear position. Use only one pot when you operate the function. Incorrect cookware position: General information: • 160 mm is the minimum bottom diameter of the cookware for this function.
-
Page 19: Cooking Table
ENGLISH Activating the function To activate the function place the cookware in the correct position on the cooking area. Touch . The indicator above the symbol comes on. If you do not place the cookware on the cooking area comes on and after 2 minutes the flexible induction cooking area is set to Deactivating the function... -
Page 20: Cookware Guidance
ENGLISH Heat setting Use to: Time Hints (min) 6 - 7 Gentle fry: escalope, veal cor‐ as nec‐ Turn halfway through. don bleu, cutlets, rissoles, saus‐ essary ages, liver, roux, eggs, pan‐ cakes, doughnuts. 7 - 8 Heavy fry, hash browns, loin 5 - 15 Turn halfway through. -
Page 21: Care And Cleaning
ENGLISH able to monitor the temperature, or will turn When a cooking zone is active, it may hum off automatically if the temperature is too briefly. This is characteristic of all ceramic high. This may result in the damage of the glass cooking zones and does not impair cookware or the hob surface. - Page 22 ENGLISH What to do if... Problem Possible cause Remedy You cannot switch on the ap‐ The hob is not connected to Check if the hob is correctly pliance or operate it. an electrical supply or it is connected to the electrical connected incorrectly.
- Page 23 ENGLISH Problem Possible cause Remedy The flexible induction cook‐ The cookware is in the wrong Place the cookware in the ing area does not heat up the position on the flexible induc‐ correct position on the flexi‐ cookware. tion cooking area. ble induction cooking area.
- Page 24 ENGLISH Problem Possible cause Remedy There is no cookware on the Put cookware on the zone. comes on. zone. The cookware is incorrect. Use the correct cookware. Refer to "Cookware guid‐ ance". The diameter of the bottom Use cookware with correct di‐ of the cookware is too small mensions.
-
Page 25: Technical Data
IKEA store or the After Sales Service. You can installer, the visit from the After find a full list of IKEA appointed contacts at Sales Service technician or dealer the end of this user manual. -
Page 26: Environmental Concerns
IKEA Pty Ltd, ABN 84006270757 or at sales customer service center phone Cebas Pty Ltd, ABN 15 009 156 003 (Both number, online email and opening times. - Page 27 Australia. IKEA Pty Ltd IKEA Service Office What will IKEA do to correct the problem? L1 Clock Tower, 630 Princes Highway IKEA appointed service provider will examine Tempe, NSW 2044 the product and decide, at its sole discretion, Contact - IKEA Customer Service at if it is covered under this guarantee.
- Page 28 IKEA is not liable for any Please describe the problem that you are damage that may occur during transport.
- Page 29 It is your proof of purchase and required for the guarantee to apply. Note that the receipt reports also the IKEA article name and number (8 digit code) for each of the appliances you have purchased.
- Page 32 21552 © Inter IKEA Systems B.V. 2020 AA-2198538-3...
