Daewoo DWC-UD1212 Service Manual page 9

Drum washing machine

Advertisement

No.
PARTS NAME
NO DISPONIBLE
E01 BASE U
3610393200
E02 SUPPORTER LEG
NO DISPONIBLE
3615303600
E03 FIXTURE LEG
3612006400
LEG ADJUST AS
E04 SPECIAL BOLT
3616029000
LEG ADJUST AS
E05 FOOT
3612100600
LEG ADJUST AS
E06 REACTOR
52G043J003 DWD-100DR, 4A
E07 DAMPER FRICTION 361A700150
E08 DAMPER FRICTION 361A700110
E09 DAMPER PIN
361A700200
E10 EMI FILTER(K19B)
3611908770
CODE
SPECIFICATIONS
PP, DWD-T120R
PO+, 3.0T
PEDIR
ABS, DWD-100DR
PEDIR
10 X 1.25, 51MM
PEDIR
BUTYL, DWD-100DR
110N AKS ST=170-260 DL=197.5 LOW NOISE
70N AKS ST=170-260 DL=197.5 LOW NOISE
AKS D=14.5
DWLF-K19(B110),X0.47U.Y1000P.VAR471K.NON FUSE
18
Q'TY
REMARK
1
4
LEG ADJUST AS:
4
3617703600
E03+E04+E05
4
4
1
2
2
4
1
