Functions
Operating conditions
Shutdown during reduced and holiday mode
This function ensures that the system is shut down after the change from
standard to reduced or holiday mode, to ensure that the reduced set room
temperature is achieved.
Operating details (multi-boiler control unit)
Flow
Set temperature 0ºC

Set room temperature

Set room temperature subject to operating condition
In the "Set value" menu, the set room temperature can be selected for
operating states of standard, reduced and holiday mode (see page 16).
Assumed return temperature
The current return temperature is determined (estimated) by the control unit.
This estimate is based on the current outside temperature and the cool down
characteristics of the building. To achieve this, a building type (construction
substance and thermal insulation) must be entered. Subject to the type of
construction, you may enter the building type as "Light", "Medium" or
"Heavy".
Set value (multi-boiler control unit)
Building type
22
(cont.)
Because of the set values, the set flow
30ºC
temperature is 0 ºC.
Depending on the type of construction enter the
building type as light, medium or heavy.
Light
(without return temperature sensor)
