AMG Systems AMG2783R-DR Instruction Manual

Eight Channel Video Transmit Unit with Bi-directional Data
with Dual Redundant Operation on a dual fibre ring
AMG
PRIMARY OPTO SYNC SECONDARY OPTO SYNC
TX RX TX R X
O O O O
VIDEO PRESENT VIDEO PRESENT
CH1 O O CH2 CH5 O O CH6
CH3 CH4 CH7 CH8
O O O
CH1 O O RX O O
CH1 RX
DATA PRESENT
DATA PRESENT
-------------------------
8 CH VIDEO TX
+ +
DATA TX/RX
POWER POWER
O O
2783R- DR
AMG2783R-DR is a rackmount eight channel video transmit unit designed to transmit eight video
signals onto a dual fibre optical fibre ring. It also provides a RS485/RS422 bi-directional data channel
to the video receiver. The AMG2783R-DR is designed to plug into an AMG2000 or an AMG2005
subrack which in turn fits into a 19" rack system.
The AMG2783R-DR is designed to operate with an AMG2784-DR 8 channel video and bi-directional
data receive unit or their rackmount equivalents.
