Introduction

Package contents

1. MicroSVR computer
2. 12V DC power supply
3. AC cord. Standard North-American plug
4. HDMI to DVI adapter
5. 3.5mm to RCA cable for S/PDIF
6. Mini Serial to DB9 RS-232 cable adapter
7. 4 drive handles (inside the MicroSVR).
8. 16 ** screws to mount the hard drive to their handle.
9. 2/3 WiFi antennas (When supplied with WiFi option)
To use MicroSVR, you will need:
• A display with DVI, HDMI or DisplayPort input + DVI, HDMI or DisplayPort cable
USB keyboard and mouse
•

Hardware specifications

Chipset
RAM
Storage
Display
Audio
Wireless
(optional)
Serial
Power
Operating temperature
Power Consumption
Dimensions
1 Local resellers may supply MicroSVR with other AC cord types.
CPU 3rd gen Intel Core CPU i7-3517UE / i7-3555LE
Intel 7 Series System Controller Hub QM77
2x ECC-DDR3 1333 SO-DIMM sockets (up to 16 GB)
4 x Internal bay for 2.5" SATA 3 HDD, RAID
mSATA slot
eSATA port
HDMI / DVI + DisplayPort in dual head configuration
S/PDIF in/out 7.1 channels
Stereo line-out and stereo line-in
802.11 b/g/n 3 antennas
BT 3.0
LAN 2x 1000BaseT RJ45
USB 2x USB 3.0 5 Gbps
2x USB 2.0 480 Mbps
(Optional) 4x USB 2.0 in front
RS232 full UART (mini connector, cable sold separately)
Unregulated 8V to 16V DC
0 – 50 0 C
8 ~ 35W (Depend on system configuration and load)
6 x 16 x 26cm
