- Page 1 WG1300-B0 Evaluation Module User Guide Revision 0.2 Copyright © JORJIN TECHNOLOGIES INC. 2013 http://WWW.JORJIN.COM.TW CONFIDENTIAL...
-
Page 2: Table Of Contents
Doc No: WG1300BE00 EM Board-UG-R02 Index 0. REGULATION INFORMATION ................2 1. INTRODUCTION ....................7 2. WG1300-B0 EM BOARD ..................7 2.1. TOP S ......................7 2.2. BOTTOM S ....................10 2.3. H ..................... 12 ARDWARE ETUP 2.4. S ....................... 13 CHEMATICS 2.5. -
Page 3: Regulation Information
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 2 http://WWW.JORJIN.COM.TW CONFIDENTIAL... - Page 4 RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 3 http://WWW.JORJIN.COM.TW CONFIDENTIAL...
- Page 5 Radiated transmit power must be equal to or lower than that specified in the Equipment Authorization. A separate approval is required for all other antenna type, or higher gain antenna. © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 4 http://WWW.JORJIN.COM.TW CONFIDENTIAL...
- Page 6 RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. Manuel d'information à l'utilisateur final © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 5 http://WWW.JORJIN.COM.TW CONFIDENTIAL...
- Page 7 Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 6 http://WWW.JORJIN.COM.TW CONFIDENTIAL...
-
Page 8: Introduction
1. INTRODUCTION The purpose of this user guide is to help user understanding how to use WG1300-B0 EM (Evaluation Module) board to complete hardware setup for test to evaluate the performances of CC3000 - WG1300-B0 SiP Module. 2. WG1300-B0 EM BOARD In the following sub-sections, it’ll divide into TOP and BOTTOM Side to... - Page 9 It is a jumper for testing VBAT_IN power consumption of WG1300-B0. In operation mode, pins of the jumper is shorted. For power testing, the jumper is removed and ammeter crosses the pins to do the testing.
- Page 10 Descriptions Number Ground I2C Data signal from EEPROM inside SDA_EEPROM CC3000-WG1300-B0 SiP Module. This pin is connected to SDA_CC3000 via a 0-Ohm resister and is not used by end users. I2C Clock signal input from EEPROM inside SCL_EEPROM CC3000-WG1300-B0 SiP Module. This pin is connected to SCL_CC3000 via a 0-Ohm resister and is not used by end users.
-
Page 11: Bottom Side
External Slow Clock input from Host EXT_32KHz device. It can be used for the SiP Module inside which hasn’t slow clock source. VBAT_SW_EN Active-high enable signal from Host device. WL_SPI_IRQ Host Interface SPI Interrupt Request © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 10 http://WWW.JORJIN.COM.TW CONFIDENTIAL... - Page 12 Number Ground VBAT_IN Battery voltage input to Module VBAT_IN Battery voltage input to Module EXT_32KHz External Slow Clock input from Host device. Table 5. BOTTOM-Side J7 of WG1300BE00 EM Board © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 11 http://WWW.JORJIN.COM.TW CONFIDENTIAL...
-
Page 13: Hardware Setup
EM mating connector for hardware connection, the mating EM connector should be lined up and spaced 1.2” apart as Figure 3 below Figure 3. Host PCB Mating Connector Arrangement © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 12 http://WWW.JORJIN.COM.TW CONFIDENTIAL... -
Page 14: Schematics
Connect to Host GPIO. RES1005 VBAT_SW_EN Male 1x2 WL_SPI_IRQ_HOST WL_SPI_CS_HOST WL_SPI_CLK_HOST WL_SPI_DIN_HOST 32KHz_1V8_HOST NL_0R WL_SPI_DOUT_HOST RES1005 SFM-110-02-L-D-A pitch 1.27-2x10 SFM-110-02-L-D-A 10uF pitch 1.27-2x10 CAP2012 Figure 4. Schematics of WG1300BE00 EM Board © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 13 http://WWW.JORJIN.COM.TW CONFIDENTIAL... -
Page 15: Bill Of Material (Bom)
CAP 0402 / 0.1uF / 10V / X7R / ±10% C4, C6 CAP 0603 / 1uF / 16V / X7R / ±10% CAP 0805 / 10uF / 10V / X5R / ±10% Table 6. BOM of WG1300BE00 EM Board © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 14 http://WWW.JORJIN.COM.TW CONFIDENTIAL... -
Page 16: Antenna Characteristics
Doc No: WG1300BE00 EM Board-UG-R02 3. ANTENNA CHARACTERISTICS 3.1. Return Loss & VSWR Figure 5. Antenna return loss & VSWR 3.2. Plane Definition Figure 6. Plane Definition © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 15 http://WWW.JORJIN.COM.TW CONFIDENTIAL... -
Page 17: Radio Pattern
Doc No: WG1300BE00 EM Board-UG-R02 Theta=90° XY-Plane Phi=0° XZ-Plane Phi=90° YZ-Plane 3.3. 3D Radio Pattern Figure 7. 3D Radio Pattern © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 16 http://WWW.JORJIN.COM.TW CONFIDENTIAL... -
Page 18: Radio Pattern
Doc No: WG1300BE00 EM Board-UG-R02 3.4. 2D Radio Pattern Figure 8. 2D Radio Pattern XY-Plane XZ-Plane YZ-Plane Efficiency Peak Avg. Peak Avg. Peak Avg. -2.6 -4.2 -0.9 66.7% Table 7. Gain Table © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 17 http://WWW.JORJIN.COM.TW CONFIDENTIAL... -
Page 19: Layout Guidelines
Increase the ground pour in the first layer. Have a solid ground plane and ground vias under the module for stable system and thermal dissipation. Table 8. Module Layout Guidelines © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 18 http://WWW.JORJIN.COM.TW CONFIDENTIAL... - Page 20 Figure 12 shows layer 1 with the trace to the antenna over the layer 2. Table 9 and Figure 13 describe instances of good layout practices for the antenna and RF trace routing. Figure 11. Trace Design for the PCB layout © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 19 http://WWW.JORJIN.COM.TW CONFIDENTIAL...
- Page 21 PCB product. The proximity of the antenna to the enclosure and the enclosure material must also be considered. Table 9. Antenna and RF Trace Routing Layout Guidelines © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 20 http://WWW.JORJIN.COM.TW CONFIDENTIAL...
- Page 22 Make VBAT traces as wide as possible to ensure reduced inductance and trace resistance. If possible, shield VBAT traces with ground above, below, and beside the traces. © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 21 http://WWW.JORJIN.COM.TW CONFIDENTIAL...
-
Page 23: Application Development
Figure 4. MSP-EXP430FR5730 and WG1300BE00 EM Board The MSP-EXP430FR5739 test platform can be ordered as the link below. http://www.ti.com/tool/msp-exp430fr5739 Specific application examples can refer to the link below http://processors.wiki.ti.com/index.php/CC3000 Wi-Fi for MCU © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 22 http://WWW.JORJIN.COM.TW CONFIDENTIAL... -
Page 24: History Change
Doc No: WG1300BE00 EM Board-UG-R02 6. HISTORY CHANGE Revision Date Description R 0.1 2013/7/22 Release 0.1 R 0.2 2014/May/22 3. Antenna Characteristics 4. Layout Guidelines © Copyright JORJIN TECHNOLOGIES INC. 2014 Page 23 http://WWW.JORJIN.COM.TW CONFIDENTIAL...
