- Page 1 XOMAX XM-RSU25X Serie & XM-CDB621 Installation Manual ENGLISH...
- Page 2 Please save this manual in case you will need to clarify further possible questions regarding installation and usage of our product. We recommend you to let the technician install the unit in your vehicle. You can find the detailed manual for your XOMAX product on our homepage: www.xomax.de/download XOMAX...
-
Page 3: Table Of Contents
4 Connect the unit ......10 5 Fixture of the unit .......10 Deinstallation instructions 1 Prepair the instruments ....11 2 Unloose the fixation sheet ....11 3 Use the extraction keys ....12 4 Unloose the unit ......12 5 Remove the unit ......13 XOMAX... -
Page 4: Safety Instructions And Precautions
If it's too cold or too hot inside of the you detect any kind of technical vehicle, do not turn the unit on until problems. the inside temperature of the cabin descends. Leave all the repair operations to professional technicians. XOMAX... -
Page 5: Cleaning Of The Unit
This unit contains a semiconductor laser system and is classified as a "CLASS 1 LASER PRODUCT". Transportation bolts Be sure the two shipping screws on the top of the car radio have been removed before turning on the system. XOMAX... -
Page 6: Installation
4 speakers. Do not sure that the vehicle has the 12 Volt combine this unit with devices that are on-board power supply. designed and construed for connection with 2 speakers. » The minus (-) should be connected XOMAX... - Page 7 » Do not ever connect the negative speaker cables with the vehicle body. » To ensure a flawless performance of the unit the intergration angle should amount to +/- 30. XOMAX...
-
Page 8: Installation Instructions
Therefore it might cause from product to product some irrelevant discrepancies, especially regarding some depictions (e.g. installation accessories) You can find the detailed manual for your XOMAX product on our homepage: www.xomax.de/download 4. unit 1. -
Page 9: Fixture Of The Fixation Sheet
Please remove first the installation frame inside the cell (slot). frame (if it's included in delivery) from the unit. Please use for that the extrac- tion keys ( see page 29 ). Possibly the faceplate should be removed as well. XOMAX... -
Page 10: Connect The Unit
This procedure refers to the step 2 and may be possibly skipped as well. As earlier required ( see page 27 ), the dual-ended bolt of the unit should be pulled through one of the holes in XOMAX... -
Page 11: Deinstallation Instructions
2 Unloose the fixation sheet due to the lack of space the unit initially was not fixated to the fixation metal First of all please unloose the fixation sheet. nut on the rear side of the unit by spanner (wrench). XOMAX... -
Page 12: Use The Extraction Keys
4 Unloose the unit When and as long as inserted, the extraction keys press the holding side-cogs outwards so that the unit is released from the installation frame and can be carefully pulled out. XOMAX... -
Page 13: Remove The Unit
6 Remove the installation accessories Finally remove all the installation accessories such as fixation metal sheet and installation frame. XOMAX... -
Page 14: Connection Schedule - Cinch Multicore
Topic: Connection schedule – Cinch multicore Connection schedule – Cinch multicore radio-aerial passiv loud speakers front left e.g. front right ampliefer rear right optional rear left XOMAX... -
Page 15: Connection Schedule - Iso Plug
Topic: Connection schedule – ISO plug Connection schedule – ISO plug phantom power radio-aerial active permanent current ignition rear right front right front left rear left XOMAX... -
Page 16: Iso Plug Configuration
If connection may lead to grievous errors. these problems appear the connections A4 and A7 should be interchanged. XOMAX... - Page 17 Common solutions Common solutions The following advices are generally valid and refer to diverse Xomax models with the similar characteristics. Please note that some articles may refer not to your model exactly and contain the describtion of features and functions that your model does not support.
- Page 18 ISO cable. turned off all the stored stations and users settings Please interchange the cables for ignition plus and for will be lost. steady plus. Caution: If these wires have fuses the latter should be interch- anged as well. XOMAX...
- Page 19 The proper disposal of these products contributes to environment protection. To find the nearest collection point or recycling yard please consult your municipal administration. Made for STEL Multimedia GmbH Paewesiner Weg 20 13581 Berlin GERMANY XOMAX...
