CAR AUDIO
CAR MP3 PLAYER WITH RAIDO USB/SD/MMC MANUAL
1. Power on / off / MUTE
2. Sound effect change
3.Pause/play/Change radio channel /Search automatically/Storage button
4.MP3 Previous Document/ FM Previous station
5. MP3 Next Document/ FM Next station
6. MODE
7.Clock
8. MP3 Previous song/FM Radio search backward/ Ring off
11. MP3 Next song/FM Radio search forward/Answer the call
12. LCD
13. Volume increase
14.Remote Control receive window
16. Volume decrease
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Xomax XM-RT284
Summary of Contents for Xomax XM-RT284
- Page 1 CAR AUDIO CAR MP3 PLAYER WITH RAIDO USB/SD/MMC MANUAL 1. Power on / off / MUTE 2. Sound effect change 3.Pause/play/Change radio channel /Search automatically/Storage button 4.MP3 Previous Document/ FM Previous station 5. MP3 Next Document/ FM Next station 6. MODE 7.Clock 8.
- Page 2 2. Basic Operation This product is touch screen, short press any button can be power on. 1. Power on / off / Mute (1) After turning on the power begin working, press any button to power on. Short press (1) is Mute function, long press (1) is power off.
- Page 3 9. Aux in (15) In radio/SD/USB mode, short press button (6) to go to AUX in mode, you can play external music by inserting in this Aux in hole. 10.SD/MMC slot (10) Insert SD/MMC card into slot, it will read the music of the SD/MMC card. 11.USB slot (9) Insert U disk into USB Slot.
- Page 4 4. INSTALLATION/UNMOUNTING Before installation check the power supply of the vehicle, the condition of the device and if all functions work properly on the device. Always use the supplied accessories for the mounting, using of different parts may result faulty operation. Make sure when you mount the device that if can not cause any injury in case of braking.
- Page 5 5. Wiring Diagram...
- Page 6 6. Trouble shooting Fault Reasons Solutions LCD doesn’t display Yellow wire is not connected with Assure yellow wire battery + connected with battery + Fuse of red wire is open Replace fuse No sound No power supply Connect the power wire. Speaker wire is open circuit Connect speaker wire.
