For optimum side-mounting, check out our optional PODIUM Mounting
Brackets at Fanatec.com. (M6 bolts and washers required.)
Insert the T-nuts into the T-slots found on the sides of the wheel base for
hard-mounting from the sides.
You can position the T-nuts in any configuration to suit the position of the
holes on your hard-mounting structure.
10 mm
X
NOTE:
Use only good
quality bolts when
M6
hard-mounting.
Bolt specifications:
M6x(10+X) mm
10 mm
X
M6
5
