Welch Allyn BRAUN ThermoScan PRO 6000 Quick Reference Manual

ThermoScan
Quick Reference Guide
9 010 5 4
Operation and technique
1
1a 1b
2
3
4
5
6
7
PRO 6000
®
Remove thermometer from cradle by gripping
thermometer at base and pivoting up.
Thermometer will turn on automatically. Probe cover
icon will ash on display indicating a new probe cover
is needed.
Attach a new probe cover by pushing
probe tip straight into box, then pulling
thermometer out.
Wait for the ready indication. Ring around
MEASURE button turns green, thermometer
will beep once and three lines on display
indicate thermometer is ready.
Place probe snugly in ear canal and direct toward
opposite temple. Keep thermometer probe steady in
the ear canal. Correct probe placement is essential for
accurate measurements.
Press and release MEASURE button.
The thermometer will beep once, running dashes will
appear on the display then the green ExacTemp light
will ash, indicating consistent probe position.
Temperature measurement. A long beep and
steady green ExacTemp light will signal the end of
the measuring process. The temperature will show
on the display.
Remove used probe cover by pressing
Probe Cover Ejector button .
To achieve accurate measurements, use a new,
clean probe cover for each measurement.
To take another measurement, place a new, clean
probe cover on the thermometer.
Additional functions
*
Memory
C / F Mem
Press the MEMORY button to reveal the last completed
temperature.
*
Temperature conversion
C / F Mem Press and release C/ F button to view the measurement in the
alternate temperature scale temporarily. Press button again to
return to default temperature scale.
Default temperature scale can be set with the C/F switch located
inside the battery compartment.
*
Manual timer
Press and hold
A beep is heard at the initiation of the timer.
First segment will ash until rst 15 seconds are complete and then beep.
(Repeats for 3 remaining segments.) At 60 seconds a long beep will sound.
The thermometer will exit timer mode 5 seconds after last segment.
You can exit timer anytime by pressing
*
Security and charging
To UNLOCK, thermometer must be returned to charging station
or compatible vital signs device.
UNLOCK
remaining time available (if under 60 minutes) before thermometer is
locked.
When time runs out LOCK icon
Charge light indicator
Illuminates indicating rechargeable battery is charging.
Indicator changes from amber to green when battery is fully
charged.
®
Welch Allyn Technical Support (www.welchallyn.com/support)
visit locations (www.welchallyn.com/about/company/locations.htm)
button for one second to activate timer.
button again.
icon displays when Security mode is active and counts
remains on display.
