USERS GUIDE
VLX Series
VLX-TC1-CF ● VLX-TCW2H-C ● VLX-TCW2V-C
1GbE Visual Lossless Low Latency AV over IP
VLX-TC1-CF
VLX-TCW2V-C
VLX-TCW2H-C
www.auroramm.com
Manual Number: 191122 | Firmware Rev: 3.20.0 or Higher
