  • Page 3 Preface Objectives This guide describes the overall device, components, main control card, subcards, and cables of the iTN201, including hardware features, components, and functions of each component, as well as appearance and technical specifications of cables. Versions The following table lists the product versions related to this document.
  • Page 4 Raisecom iTN201 (C)Hardware Description Preface General conventions Convention Description Times New Roman Normal paragraphs are in Times New Roman. Paragraphs in Warning, Caution, Notes, and Tip are in Arial. Arial Names of files, directories, folders, and users are in boldface.
  • Page 5 Raisecom iTN201 (C)Hardware Description Contents Contents 1 Overview ............................1 2 MCCs ............................... 6 3 Power supply and fan......................... 10 4 Cables ............................4-1...

  • Page 6: Overview

    Hardware of the iTN201 includes the chassis, power supply, fan, Main Control Card (MCC), subcards, and cables. The iTN201 uses -48 VDC power, or 220 VAC power, or hybrid AC/DC power. For both AC power and DC power, it supports 1+1 power backup.
  • Page 7 1.2 Appearance 1.2.1 Chassis Dimensions of the iTN201 chassis are 440 mm (Width) × 266 mm (Depth) × 44 mm (Height).The rear appearance is the backplane and there are 6 slots on the front panel. One slot for the MCC ...
  • Page 8 Raisecom iTN201 (C) Hardware Description 1 Overview 1.2.2 MCCs iTN201-4GF Figure 1-2 shows the appearance of the iTN201-4GF. Figure 1-2 Appearance of the iTN201-4GF 1.2.3 Subcards iTN200-SUB-4GE Figure 1-3 shows the appearance of the iTN200-SUB-4GE. Figure 1-3 Appearance of the iTN200-SUB-4GE iTN200-SUB-4GF Figure 1-4 shows the appearance of the iTN200-SUB-4GF.
  • Page 9 1 Overview 1.2.4 Power supply and fan Power supply Figure 1-5 shows the appearance of the iTN201 DC power module. Figure 1-5 Appearance of the iTN201 DC power module Figure 1-6 shows the appearance of the iTN201 AC power module.
  • Page 10 Raisecom iTN201 (C) Hardware Description 1 Overview Table 1-1 Technical specifications of the iTN201 Item Value Dimensions (mm) 440 (Width) × 266 (Depth) × 44 (Height) Power Max. power 55 (full-rate fan + MCCU + 2 subcards) consumption consumption (iTN201-4GF) Max.

  • Page 11: Mccs

    2.1 iTN201-4GF 2.1.1 Functions The iTN201-4GF is a main service access and processing unit of the iTN201. It accesses and processes up to 12 ways of downlink Ethernet services and 4 ways of 1000 Mbit/s uplink Ethernet services. The iTN201-4GF is inserted into the main control card slot only.
  • Page 12 Figure 2-1 shows the appearance of the iTN201-4GF. Figure 2-1 Appearance of the iTN201-4GF 2.1.3 Interfaces There are 12 interfaces on the iTN201-4GF, with interface type and usage as listed in Table 2- Table 2-1 Interfaces on the iTN201-4GF Interface...
  • Page 13 10/100 Mbit/s self-adaptive management electrical interface interface The USFP-GE-R and USFP-GE/AN-R SFP electrical modules are available. 2.1.4 LEDs There are 19 LEDs on the iTN201-4GF, as described in Table 2-2. Table 2-2 LEDs on the iTN201-4GF Status Description Green Power LED ...
  • Page 14 Blinking green: the SFP interface is sending/receiving data.  Off: the SFP interface is disconnected or improperly connected. 2.1.5 Specifications Table 2-3 lists technical specifications of the iTN201-4GF. Table 2-3 Technical specifications of the iTN201-4GF Item Value Dimensions (mm) 259.3 (Width) × 243.4 (Depth) × 19.8 (Height)

  • Page 15: Power Supply And Fan

    3.1 AC power module RPA0601 3.1.1 Functions The RPA0601 is the AC power module of the iTN201-4GF. It can be inserted into the power slot of the device. It has the following functions: Provide 100–240 VAC power, and support dual power backup.
  • Page 16 65.6 (Width) × 243.4 (Depth) × 41.2 (Height) Weight (kg) Output power (W) Rated input voltage (V) 110/220 Input voltage range (V) 100–240 Rated output voltage (V) Max. output current (A) Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.
  • Page 17 3.2 DC power module RPD0601 3.2.1 Functions The RPD0601 is the DC power module of the iTN201-4GF. It can be inserted into the power slot of the device. It has the following functions: Provide -48 VDC power, and support dual power backup.
  • Page 18 65.6 (Width) × 243.4 (Depth) × 41.2 (Height) Weight (kg) Output power (W) Rated input voltage (V) Output voltage range (V) -36 to -72 Rated output voltage (V) Max. output current (A) Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.
  • Page 19 3 Power supply and fan 3.3 AC power module RPA1101 3.3.1 Functions The RPA1101 is the AC power module of the iTN201-2XG. It can slot be used for the iTN201-4GF. It has the following functions: Provide 100–240 VAC power, and support dual power backup.
  • Page 20 Max. output current (A) 8.33 3.4 Fan module FANS306 3.4.1 Functions The FANS306 is the fan module of the iTN201. It is inserted into the FAN slot only. It has the following functions: Support fan monitoring and automatic adjustment of fan speed. ...
  • Page 21 Table 3-11 lists technical specifications of the fan module FANS306. Table 3-11 Technical specifications of the fan module FANS306 Item Value Dimensions (mm) 41.9 (Width) × 230.1 (Depth) × 41.1 (Height) Weight (kg) Power consumption (W) Raisecom Proprietary and Confidential Copyright © Raisecom Technology Co., Ltd.

  • Page 22: Cables

    Before installing and operating the iTN201, check accessories contained in the packing box based on the shipping list. The followings are cables required for the iTN201. Some cables are not delivered with the iTN201. If required, prepare them based on the cable specifications.
  • Page 23 Ethernet electrical interface and other devices  SNMP interface and the NMS  The Ethernet interface on the iTN201 is self-adaptive to straight-through cable mode and crossover cable mode. 4.2.2 Appearance Figure 4-2 shows the Ethernet cable. Figure 4-2 Ethernet cable Address Raisecom Building, No.
  • Page 24 EIA/TIA568B standard. Figure 4-3 shows the wiring of the straight-through cable. Figure 4-3 Wiring of the straight-through cable Address Raisecom Building, No. 11, East Area, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing, P.R.China Postal code: 100094 Tel: +86-10-82883305 Fax: 8610-82883056 http://www.raisecom.com...
  • Page 25 PIN7, and PIN5 to PIN8, as shown in Figure 4-5. Figure 4-5 Wiring of the 1000 Mbit/s crossover cable Raisecom provides straight-through cables and 100 Mbit/s crossover cable which are different in name only. The straight-through cable is named as CBL-ETH-RJ45/RJ45-D while the crossover cable is named as CBL-ETH-RJ45/RJ45-X-D Table 4-3 lists technical specifications of the Ethernet cable.
  • Page 26 4.3 Configuration cable 4.3.1 Introduction The configuration cable is used to connect the Console interface on the iTN201 to the PC that runs terminal emulation program. You can configure the iTN201 through command lines. Before accessing the iTN201 through the USB interface, install the driver on the PC for converting the USB interface to the UART interface.
  • Page 27 4.4 DC power cable 4.4.1 Introduction The DC power cable transmits -48 VDC power to the RPD0601 cable terminal block of the iTN201, and supplies power for the whole device. 4.4.2 Appearance A DC power cable is composed of DC connectors and coaxial cable, as shown in Figure 4-7.
  • Page 28 IEC60320-C13 receptacle Type Copper core multi-strand power supply cable 18AWG Length 1.5 m Address Raisecom Building, No. 11, East Area, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing, P.R.China Postal code: 100094 Tel: +86-10-82883305 Fax: 8610-82883056 http://www.raisecom.com Email: export@raisecom.com...
  • Page 29 4.6 Grounding cable Connecting the grounding cable properly is an important guarantee to lightning protection, anti- electric shock, and anti-interference. The iTN201 must be connected to the grounding cable correctly during installation, which helps to avoid personal injury and equipment damage.
  • Page 30 Cross-sectional area of 17–15 AWG (1.2–1.5 mm the conducting wire The iTN201 is delivered with OT terminals only. You need to prepare or make grounding  cables on site if needed. The length of the grounding cable cannot be longer than 30 m and the grounding cable should ...
