www.raisecom.com
ISCOM HT803G-WS2 (T)
User Manual
(Rel_01)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISCOM HT803G-WS2 and is the answer not in the manual?

Questions and answers

Related Manuals for Raisecom ISCOM HT803G-WS2

Summary of Contents for Raisecom ISCOM HT803G-WS2

  • Page 1 ISCOM HT803G-WS2 (T) User Manual (Rel_01)
  • Page 2 Read this document carefully before installing and using the ISCOM HT803G-WS2. Otherwise, severe bodily injury or device damage may be caused. Raisecom Technology Co., Ltd. (hereinafter referred to as Raisecom) will not be liable for any losses caused by violation of any safety issues.
  • Page 3 If any abnormality occurs, such as smoking, abnormal sound, and peculiar smell, stop using the device immediately, power it off, pull out all cables from it, and contact Raisecom technical support personnel.  Do not let any object (such as metal) enter the device through heat dissipation holes.
  • Page 4 Legal notice The copyright of this document is owned by Raisecom. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without written consent from Raisecom Technology Co., Ltd.
  • Page 5 Typical optical wavelength 1310 nm/1490 nm Tx optical power 0.5–5 dBm Rx optical power -28 to -8 dBm Packing list Table 3-3 lists packing list of the ISCOM HT803G-WS2. Table 3-3 Packing list Device/Component Quantity ISCOM HT803G-WS2 Power adapter Ethernet cable...
  • Page 6 LEDs...
  • Page 7 Connection and usage Interfaces and buttons The figure shown above is diagrammatic only. The actual appearance is subject to the device provided by the SP.
  • Page 8 Record of Damage and Signature Repair Signature of Date of Repair Damage Repair Customer Reason Measure Address: East-11, Raisecom Building, 10 Xi Bei Wang East Road, Haidian District, Beijing, China Post Code: 100094 Tel: +86-10-82883305 www.raisecom.com Raisecom Technology Co., Ltd.
  • Page 9 Address:_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Thank you very much for purchasing Raisecom products. For the sake of being responsible for you, and guaranteeing premium after-sale service, please carefully read and fill up this sheet.
  • Page 10 Installation modes The ISCOM HT803G-WS2 can be installed on a stable workbench or a wall. Installing the ISCOM HT803G-WS2 on the workbench is informal because unpredictable events (such as collision or object falling) may prevent the ISCOM HT803G-WS2 from working properly or even damage it.
  • Page 11 Powering on device Step 1 After the ISCOM HT803G-WS2 is properly installed, insert the power adapter plugs and connect them to the device and socket respectively. Step 2 Press the ON/OFF button. If the Power LED is green, it indicates that the ISCOM HT803G-WS2 is powered on properly.
  • Page 12 Step 4 Open a browser. Enter the IP address (on the label) for accessing the ISCOM HT803G-WS2 at the LAN side, and press Enter. The Web login interface appears. Step 5 Enter the correct user name and password (on the label) to access the ISCOM HT803G-WS2.
  • Page 13 Please check whether the ON/OFF button is pressed.  Please check whether the power adapter is the standard one equipped for the ISCOM HT803G-WS2.  Please ensure that the power adapter and the power interface/power outlet are connected firmly. Alternatively, try to remove the power adapter plug, and then re-insert it.
  • Page 14 "?" or "!" symbol is displayed under the Network adapters option. If yes, uninstall the device driver and re- install the driver. Or you can insert the NIC into another slot. If the problem is not solved, replace the NIC. Raisecom Technology Co., Ltd.
  • Page 15 RoHS Compliance Declarations The raw materials of the product mentioned above are compliant with RoHS 2.0 regulations, also known as Directive 2011/65/EU of the European Parliament and of the Council of 1 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
  • Page 16 For any assistance, please contact our local office or company headquarters. Website: http://www.raisecom.com Tel: 8610-82883305 Fax: 8610-82883056 Email: export@raisecom.com Address: Raisecom Building, No. 11, East Area, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing, P.R.China Postal code: 100094...
