Connect to the Printer

The printer connection settings and software installation are performed using a computer.
However, if you selected Wireless LAN connection -> Yes -> No in steps 4 to 5 on p.10 or steps 1 to 2 on p.11, configure the wireless LAN settings only
using the printer. Proceed to "Configure Wireless LAN Settings on the Printer" on p.13.
1
Enter the following URL in the web
browser of your computer to access the
website.
2
Click Set Up.
Perform the remaining operations by
following the instructions on the screen.
• A screen for selecting the printer connection method may be displayed in the middle of configuring the settings.
If this happens, select the method you selected in step 4 on p. 10 or step 1 on p. 11 and then click Next and continue with the rest of the settings.
Note
5
When the following screen appears, you
can use the printer. Next, click Next to
proceed to installing the software.
• If you are using a Windows PC, you can also start this from the CD-ROM.
• When using Windows 10, Windows 8.1 or Windows 8, follow the procedure below
Note
for start up the setup file after inserting the setup CD.
Click
Select This PC or Computer on the left side of the opened window.
Double-click the
If the contents of the CD-ROM appear, double-click MSETUP4.EXE.
• If you have started from the CD-ROM, proceed to step 4.
3
Click Download to download the setup
files.
If a warning screen about downloading
appears, select Do not block, Allow, etc.
to proceed with the operation.
Wired LAN connection
This is the method for connecting the printer to the network using a LAN cable.
Wireless LAN connection
This is the method for connecting the printer to the network without using a cable.
USB connection
This is the method for connecting the printer to a computer using a USB cable.
Only 1 printer can be connected.
For the USB cable connection, first select the connection method and then follow the instructions on the
screen.
6
When the following screen appears,
select the software to install and click
Next.
Configure the remaining settings by
following the instructions on the screen.
This completes the connection with the
computer.
12
or File Explorer on the taskbar.
CD-ROM icon on the right side of the window.
4
Run the file you downloaded and click
Start Setup.
Configure the settings by following the
instructions on the screen.
