    Contents Contents Thank you for choosing Bristan, the UK’s leading taps and showers expert. We have designed this product with your enjoyment in mind. To ensure that it works to its full potential, it needs to be fitted correctly. These fitting instructions have been created to give you all of the information you need and, if you need any further help, please do not hesitate to give us a call on 0844 701 6273.
  • Page 3: Important Safety Information

    Important Safety Information • Please read these instructions thoroughly and retain for future use. • All products manufactured and supplied by Bristan are safe provided they are installed, used correctly and receive regular maintenance in accordance with these instructions • If you are in any doubt about your ability to install this product safely you must...
  • Page 4: Installation Requirements

    Installation Requirements Installation Requirements Installation Requirements Installation Requirements IMPORTANT IMPORTANT IMPORTANT IMPORTANT - - - - PLEASE READ PLEASE READ PLEASE READ PLEASE READ This/these fitting/fittings needs/need to be This/these fitting/fittings needs/need to be This/these fitting/fittings needs/need to be This/these fitting/fittings needs/need to be installed in accordance with the following installed in accordance with the following installed in accordance with the following...
  • Page 5 BIDETS WITH OVER BIDETS WITH OVER- - - - RIM SUPPLY ARRANGEMENTS BIDETS WITH OVER BIDETS WITH OVER RIM SUPPLY ARRANGEMENTS RIM SUPPLY ARRANGEMENTS RIM SUPPLY ARRANGEMENTS Bidets installed in domestic locations of the Combination tap: - Diagram 1 Diagram 1 Diagram 1 Diagram 1 over –...
  • Page 6 Bidets of this type may: Be supplied with cold and / or hot water Type AA, AB, AD or AUK1 air gap with or without blended water cistern through type AA, AB, AD or AUK1 backflow or Type DC backflow prevention prevention arrangement or type DC device device Zone of backflow risk...
  • Page 7: Installation

    The method of supplying water to an Diagram 5 Diagram 5 Diagram 5 Diagram 5 The bidet must be located below the spillover lever of the ascending spray and / or hose and Cold water lowest sanitary fitting and Diagram 5 spray bidet is illustrated in Diagram storage below any hot water storage...
  • Page 8: Eco Basin Mixer (No Waste)

    Eco Basin Mixer (No Waste) Eco Basin Mixer (No Waste) Eco Basin Mixer (No Waste) Eco Basin Mixer (No Waste) Identify all components are present prior to starting installation. Install mixer to the basin, ensuring the washer (8) is fitted between the mixer body and the basin.
  • Page 9: Tall Basin Mixer

    Tall Basin Mixer Tall Basin Mixer Tall Basin Mixer Tall Basin Mixer Identify all components are present prior to starting installation. Screw the plinth (9) onto the bottom of the mixer extension (8). Screw the fixing rods (13) into the bottom of the mixer body (7). Slide the flexible connecting pipes (15) up through the mixer extension (8) Note: The flexible connecting pipes may need to be threaded through...
  • Page 10: Bidet Mixer

    Bidet Mixer Bidet Mixer Bidet Mixer Bidet Mixer Identify all components are present prior to starting installation. Install mixer to the bidet, ensuring the washer (8) is fitted between the mixer body (7) and the bidet. Screw the fixing rods (11) into the bottom of the mixer body (7) Slide the ‘C’...
  • Page 11: Hole Bath Filler

    1 Hole Bath Filler 1 Hole Bath Filler 1 Hole Bath Filler 1 Hole Bath Filler Identify all components are present prior to starting installation. Install mixer to the bath, ensuring the washer (7) is fitted between the mixer body (6) and the bath.
  • Page 12: Bath Filler

    Bath filler Bath filler Bath filler Bath filler Identify all components are present prior to starting installation. Install the mixer body (6) to the bath, ensuring the washers (7) are fitted between the mixer body (6) and the bath. Slide the washers (8) onto the threaded tails and tighten the backnuts (9).
  • Page 13: Maintenance

    3. Remove the valve by unscrewing it from holding dirt, which normal cloths leave the body using a suitable spanner. behind. Order through your Bristan stockist (order code: ECLOTH). If cartridge remove shroud and unscrew cartridge retaining nut using a suitable...
  • Page 14: Troubleshooting

    6. Troubleshooting 6. Troubleshooting 6. Troubleshooting 6. Troubleshooting Symptom Symptom Cause Cause Remedy Remedy Symptom Symptom Cause Cause Remedy Remedy No flow or poor flow Partially closed stop or service Open stop or service valve. rate. valve in water supply pipework to the tap.
  • Page 15: Guarantee

    All subject to proof of purchase. *Labour provided by an approved Bristan engineer. Guarantee only applies to products with a manufacturing fault. A deferred payment will be necessary in order to secure any visits by our engineers which will be charged if the problem is found not not to be a manufacturing fault.
