Edimax AR-7064+ Specifications

ADSL2+ Router Series
ADSL2+ Router Series
Wired / Wireless ADSL2+ Router
Wired / Wireless ADSL2+ Router
Integrated 4 Ports 10/100Mbps Switch
Key Features
• Share your ADSL2+ Internet access on your networks
• ANSI T1.413 Issue 2, ITU-T G.992.1(G.dmt) and G.992.2 (G.lite)
compliant for Annex A, B, U-R2
• Downstream and upstream data rates up to 24Mbps and 2Mbps
• Configuration and management operated via WWW browser with
password protected access, firmware upgrade via Web console
• WAN and LAN side connection statistics
• DMZ and Virtual Server function
• Operating modes include routing, bridge, static IP, PPPoE, PPPoA etc
• Compliant with IEEE 802.3 and IEEE 802.3u 10/100 Mbps
• All Ethernet ports support Auto-Crossover (MDI/MDI-X)
Wireless Features (AR-7064g+ only)
• Support 54Mbps Wireless data rate
• Compatibility with IEEE 802.11g and 802.11b (2.4GHz) standards
• Wireless security with up to 128-bit WEP Encryption
ADSL Features
• Compatible with all leading DSLAMs
• Supports DMT modulation and demodulation
• Support ITU-T G.992.1 G.992.3, G.992.4, G.992.5 Annex A &
T1.413 Issue 2 for Annex A, B, ETSI TS 101 388 / DTS TM-06006
for Annex B
• Supports ITU-T G.992.1 (G.dmt) Annex B – Deutsch Telecom /
U-R2 for Annex B (U-R2)
• G.992.1 (G.dmt) :
Downstream and upstream data rates up to 8Mbps and 1Mbps
• G.992.2 (G.Lite) :
Downstream and upstream data rates up to 1.5Mbps and 512Kbps
• G.992.3 / G.992.4 (ADSL2) :
Downstream and upstream data rates up to 12Mbps and 1Mbps
• G.992.5 (ADSL2+) :
Downstream and upstream data rates up to 24Mbps and 2Mbps
