- Page 1 Advanced Display Systems H170 LCD Monitor User Manual www.edge10.com The display comes with a three years on site warranty. To activate your warranty please register your display at www.edge10.com/support...
-
Page 2: Table Of Contents
Contents 1. Instructions for Federal Communications Commission Compliance……..2 2. CE Statement………………………………………………………………….4 Safety 3. Introduction…………………………………………………………………...6 eneral Specifications onitor Characteristics ccessories recautions 4. Installation……………………………………………………………………..7 erminal Connection re-installation Check 5. Operation……………………………………………………………………...8 Keypad Operating SD Menu SD Icon Overview 6. Specification &Technical Data……………………………………………...13 7. Energy-saving Modes…………………………………………………………14 8. -
Page 3: Instructions For Federal Communications Commission Compliance
1.0 Instructions for Federal Communications Commission (FCC) Compliance This d evice has passed the tests stipulated by Article 15 of FCC Compliance and conforms the limitations and provisions for Class-B digital equipment. The restrictions are mulated to prevent the harmful interference with radio frequencies produced by or used household appliances. -
Page 4: Safety
This is to state that this 17” LCD monitor complies with the following compulsory regulations: Safety This ap pliance complies with LVD-73/23/EEC Low Voltage Direction (EN60950-1:2001) requirements: • Electrical s hock protection • Energy risk protection • Fire hazard protection •... - Page 5 Be careful to avoid placing any stress on the LCD screen during handling.
-
Page 6: Introduction
Please turn off power before cleaning this monitor. Use a soft cloth with clean water and lightly wipe the LCD screen surface. This monitor operates at a high voltage and is potentially hazardous. Only qualified technicians are permitted to assemble or disassemble the device or access internal components. -
Page 7: Installation
Please check the label on the nameplate on the back cover first. Input voltage between 100V and 240V should be used with this monitor. Also please make sure this monitor and your main system (computer) is powered off before attaching any connectors. -
Page 8: Operation
5.0 Operation Keypad Operating The LCD monitor has been preset at the factory with the Timing shown in Appendix to create optimal picture. Users are also able to adjust the picture to the desired brightness and sharpness by following the instructions. -
Page 9: Osd Menu
OSD function allows the user to easily adjust the display to the desired quality. Structure of OSD Operating Procedure 1.Power on the LCD monitor. 2.Press “ ” or “ “ to pop up OSD menu. 3.Press “ ” to select main menu item. - Page 10 The Adjustment of Monitor’s Screen Display There are two ways to adjust the monitor’s screen, i.e. auto adjustment and manual adjustment. Auto adjustment Power ON the LCD monitor and computer. 2. Select “AUTO SETUP” of OSD screens by pressing the“ ” button to “AUTO SETUP”.
-
Page 11: Osd Icon Overview
6.0 OSD Icon Overview Sub Menu Main Menu Function Name Adjusts the level of brightness and darkness BRIGHTNESS Adjusts the RGB color pattern set of the CONTRAST contrast Tune off OSD window EXIT Adjusts the number of pixels from source CLOCK video Adjusts the phase relative to video H-sync... - Page 12 1. If this warning appears, please check the connector. If it is bent or damaged, the signal cable may be affected. 2. If the monitor is in “sleep” mode to save power, please move the mouse or press any key to “wake” it and return to working mode.
-
Page 13: Specification &Technical Data
Weight (G.W.) *** The above specifications may differ depending on the actual LCD panel utilized and are subject to change without prior notice. H170 Analog RGB 0.7Vp-p /75 ohm, TTL Sync,Digital RGB TMDS(optional) 1152x870,1280x960, 1280x1024 Brightness, contrast, H./V. position, phase adjust, clock adjust, language,... -
Page 14: Energy-Saving Modes
* Off Mode The monitor enters the Off mode after both the line signal and field signal are cut off. At this time, power consumption is less than 2W, the screen will turn dark, and the power indicator turns amber . In case there is any input from the keyboard or mouse, the monitor will re-enter the on mode immediately. -
Page 15: Faq (Frequently Asked Question)
Display Mode 640 x 480 720 x 350 720 x 400 800 x 600 VESA 1024 x 768 1280 x 960 1280 x 1024 640 x 480 832 x 624 Macintosh 1152 x 864 1152 x 870 640 x 400 PC-9800 1152 x 900 1280*1024... - Page 16 Check if the computer is in sleep mode or not. Question: What should I do if green LED lights are on but there is no picture? Check if the output frequency of computer is outside the monitor’s range. Refer to the material above on timing mode .
- Page 17 www.edge10.com...
