- Page 1 Service Procedures for the Model SL31,50,75 Dryer Hot Surface Ignitor Gas American Dryer Corporation 88 Currant Road Fall River MA 02720-4781 USA Telephone: (508) 678-9000 / Fax: (508) 678-9447 e-mail: techsupport@amdry.com www.amdry.com Part No. 450279 - 2...
- Page 2 Retain This Manual in a Safe Place for Future Reference This product embodies advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation. Only qualified technicians should service this equipment. OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with the dryer.
-
Page 3: Table Of Contents
Table of Contents IMPORTANT You must disconnect and lockout the electric supply and the gas supply or the steam supply Part Locations and Removal ....4 before any covers or guards are removed from the machine to allow access for cleaning, Lower Front Panel Removal ......... -
Page 4: Part Locations And Removal
Part Locations and Removal LOWER FRONT PANEL REMOVAL: TOP COVER REMOVAL: Remove the lint drawer. Remove the four screws First remove the back guard, the four screws holding located just below the loading door. Tilt the top of top cover. Next pull top cover toward the rear of the the panel out and lift the panel up and away from the dryer and lift up. -
