- Page 1 SL3131 Parts Manual Phase 8 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447 e-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450276 - 3...
-
Page 2: For Your Safety
DATE OF PURCHASE ________________________________________________ RESELLER’S NAME ________________________________________________________________________________ Serial Number(s) ____________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil. Important SL3131 MODEL NO. _________________... - Page 3 Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts from the factory, you can FAX your order to ADC at +1 (508) 678-9447 or telephone your order directly to the ADC Parts Department at +1 (508) 678-9000.
-
Page 4: Parts Diagram
Illus. No. Part No. Qty. Description 319427 Upper Back Guard (Gas and Electric) 319426 Lower Back Guard (Gas and Electric) 319435 Upper Back Guard (Steam) (For models mfd. as of December 7, 2005) 319542 Upper Back Guard (Steam) (For models mfd. prior to December 7, 2005) 319436 Back Guard Lower (Steam) (For models mfd. -
Page 5: Parts List
Illus. No. Part No. Qty. Description 150445 1/4-20 x 3/4” Bolt 153072 Spring Washer 318891 Backup Washer 153048 Friction Pad (Gas and Electric) 102373 Friction Pad (Steam) 818183 Front Right Wheel Assembly (parts breakdown on page 11) 818184 Front Left Wheel Assembly (parts breakdown on page 11) 819288 Lint Screen Assembly (Painted) 819315... - Page 6 Parts Diagram American Dryer Corporation 450276-3...
- Page 7 Illus. No. Part No. Qty. Description 819450 Lint Box / Blower Assembly Complete 120V (For models mfd. as of September 1, 2006) 819193 Lint Box / Blower Assembly Complete 120V (For models mfd. prior to September 1, 2006) 819233 Lint Box / Blower Assembly Complete 200-240V (For models mfd.
- Page 8 Parts Diagram American Dryer Corporation 450276-3...
- Page 9 Illus. No. Part No. 819314 819313 183112 183144 128944 128907 884254 141318 140880 140905 128910 183145 130500 185096 142953 819579 165066 183112 119995 819712 819251 819267 132029 131352 131357 131321 131325 131324 450276-3 Qty. Description Burner Assembly Burner Chamber Thermostat, Gas High-Limit Inshot Burner Tube, Hot Surface Ignition Gas Valve 120 VAC 60 Hz Gas Valve 120 VAC 50 Hz...
- Page 10 Illus. No. Part No. 143025 136987 165120 143236 143251 318422 143581 143208 143099 Qty. Description Nylon Hose Adaptor Pressure Switch Water Valve 3/8” Brass Cross 3/8” Plug S.A.F.E. Bracket Spray Nozzle 3/8” Brass Connector 3/8” OD Copper Tubing American Dryer Corporation 450276-3...
- Page 11 Illus. No. Part No. 150510 153007 154267 153002 154013 154284 318233 318232 318532 318531 153564 153018 180050 450276-3 Qty. Description 1/4-20 x 3/4” Hex Head Machine Bolt 1/4” Lock Washer M10 x 25mm Shoulder Screw 5/16” Lock Washer M8 Hex Nut Tumbler Wheel Spacer Rear Right Roller Wheel Bracket Rear Left Roller Wheel Bracket ...
- Page 12 ADC Part No. 450276 3 - 05/22/07 - 0...
