DEMO MANUAL DC2836A
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 3 C5, C6, C8
2 1 C7
3 2 C14, C22
4 4 C15, C23, C55, C56
5 2 C17, C25
6 2 C36, C37
7 2 C53, C54
8 1 L1
9 1 L2
10 6 R2, R3, R4, R7, R8, R9
11 1 R19
12 1 R20
13 1 R21
14 1 U1
Additional Demo Board Circuit Components
1 1 C1
2 1 C2
3 1 C3
4 1 C4
5 1 C57
6 0 C16, C24
7 0 C19, C20, C27, C28
8 2 C29, C30
9 1 C31
10 2 C32, C33
11 2 C34, C35
12 4 C38, C39, C40, C41
13 2 C42, C44
14 1 C43
15 3 C50, C51, C52
16 0 D1, D2
17 2 D4, D5
18 3 D6, D7, D8
19 1 FB1
20 1 L3
21 2 Q2, Q3
22 1 Q4
8
PART DESCRIPTION
CAP ., 10µF, X6S, 10V, 10%, 0603
CAP ., 1µF, X7R, 16V, 10%, 0603
CAP ., 0.1µF, X7R, 25V, 10%, 0402
CAP ., 100µF, X5R, 6.3V, 10%, 1206
CAP ., 10µF, X5R, 10V, 10%, 0603
CAP ., 1µF, X5R, 35V, 10%, 0402
CAP ., 4.7µF, X6S, 25V, 10%, 0603
IND., 0.47µH, 21.2A, 3.4mΩ
IND., 1.2µH, 12.2A, 9.4mΩ
RES., 10k, 1%, 1/10W, 0603
RES., 51.1k, 1%, 1/10W, 0603
RES., 107k, 1%, 1/10W, 0603
RES., 80.6k, 1%, 1/10W, 0603
IC, REGULATOR, LQFN-40
CAP ., 1µF, X5R, 50V, 10%, 0603
CAP ., 0.01µF, X7R, 25V, 10%, 0603
CAP ., 100µF, ALUM, 35V
CAP ., 4.7µF, X7R, 10V, 10%, 0805
CAP ., 10µF, X6S, 10V, 10%, 0603
CAP ., OPTION, 7343
CAP ., OPTION, 0603
CAP ., 0.01µF, X5R, 25V, 10%, 0603
CAP ., 0.1µF, X7R, 10V, 20%, 0603
CAP ., 1µF, X5R, 10V, 10%, 0603
CAP ., 0.01µF, X5R, 50V, 10%, 0603
CAP ., 0.1µF, X7R, 50V, 10%, 0402
CAP ., 10µF, X5R, 50V, 10%, 1210
CAP ., 1µF, X5R, 50V, 10%, 0603
CAP ., 4.7µF, X5R, 25V, 10%, 0603
DIODE, OPTION, SOD-323
LED, GREEN, DIFFUSED, 0603
LED, RED, DIFFUSED, 0603
FERRITE BEAD, 100Ω, 1812
IND., 0.47µH, 6.8A, 14mΩ
MOSFET, N-CH, SOT-23-3
MOSFET, N-CH, DPAK
MANUFACTURER/PART NUMBER
MURATA, ZRB18AC81A106KE01L
MURATA, GRM188R71C105KA12D
MURATA, GRM155R71E104KE14
MURATA, GRM31CR60J107KE39L
MURATA, GRM188R61A106KAALD
MURATA, GRM155R6YA105KE11D
MURATA, GRM188C81E475KE11D
COILCRAFT, XGL4030-471MEC
COILCRAFT, XGL4030-122MEC
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW060351K1FKEA
VISHAY, CRCW0603107KFKEA
VISHAY, CRCW060380K6FKEA
ANALOG DEVICES, LT7182SRV#PBF
MURATA, GRM188R61H105KAALD
TDK, C1608X7R1E103K080AA
PANASONIC, EEHZK1V101XP
TDK, C2012X7R1A475K085AC
MURATA, ZRB18AC81A106KE01L
AVX, 06033D103KAT2A
AVX, 0603ZC104MAT2A
MURATA, GRM188R61A105KA61D
AVX, 06035D103KAT2A
MURATA, GCM155R71H104KE02D
TDK, C3225X5R1H106K250AB
TAIYO YUDEN, UMK107ABJ105KAHT
MURATA, GRM188R61E475KE15D
BROADCOM INC., HSMG-C190
BROADCOM INC., HSMH-C190
WURTH ELEKTRONIK, 74279226101
WURTH ELEKTRONIK, 744373240047
VISHAY, 2N7002K-T1-GE3
VISHAY, SUD50N04-8M8P-4GE3
Rev. 0
