  • Page 1 J-100 ™ COLLECTION OWNER’S MANUAL: DOMESTIC 6530-592C Rev A...
  • Page 2 Attention New Spa Owner! ® Congratulations on the purchase of your new Jacuzzi spa! The following is a list of automated functions performed by your spa. These functions are listed below in an attempt to alleviate any operational concerns you may...

  • Page 3: Table Of Contents

    J-100 Table of Contents Important Spa Owner Information ..........1 FCC Notice ................... 1 Important Safety Instructions for all Spa Owners ....2 Entrapment Risk ................6 Hyperthermia ................. 7 Important CSA Safety Instructions (Canada Only) ......8 General Electrical Safety Instructions ..........8 Choosing A Location ..............
  • Page 4 J-100 13.0 Water Quality Maintenance ............32 13.1 pH Control..................33 13.2 Sanitizing ..................33 14.0 Error Conditions/Error Messages ..........34 14.1 Panel Displays COL ..............34 14.2 Panel Displays ICE ..............34 14.3 Panel Displays SN1 ..............34 14.4 Panel Displays SN2 ..............

  • Page 5: Important Spa Owner Information

    J-100 Important Spa Owner Information Your Jacuzzi J-100 Collection spa is constructed to the highest standards and is capable of providing many years of trouble-free use. However, because heat retentive materials are utilized to insulate the spa for efficient operation, an uncovered spa surface and wall fittings directly exposed to sunlight and high temperatures for an extended period are subject to permanent damage.

  • Page 6: Important Safety Instructions For All Spa Owners

    J-100 Important Safety Instructions for all Spa Owners READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY! This spa was manufactured to meet the standards and specifications outlined in the “Virginia Graeme Baker Pool and Spa Safety Act” (VGB Safety Act). When installing and using this spa, basic safety precautions...
  • Page 7 J-100 • A grounding wire connector is provided on this unit to connect a minimum No. 8 AWG (8.4 mm²) solid copper conductor between this unit and any metal equipment, metal enclosures of electrical equipment, metal water pipe, or conduit within 5 feet (1.5m) of the unit.
  • Page 8 J-100 WARNING: RISK OF SEVERE INJURY OR DEATH! • Since excessive water temperatures have a high potential for causing fetal damage during the early months of pregnancy, if pregnant or possibly pregnant, consult your physician before using a spa. •...
  • Page 9 J-100 WARNING: In addition to maintenance of filters and water chemistry, proper ventilation is recommended to reduce the risk of contracting a waterborne illness (e.g. an infection, bacteria or virus) and/or respiratory ailments that could be present in the air or water.

  • Page 10: Entrapment Risk

    J-100 Entrapment Risk The Consumer Products Safety Commission/USA has reported that users of pools and spas have become entrapped (stuck) to drain and/or suction fittings causing death, drowning, or serious injury (see diagram below). This spa was manufactured to meet the standards and specifica- tions outlined in the “Virginia Graeme Baker Pool and Spa Safety Act”...

  • Page 11: Hyperthermia

    A Warning Sign is provided in your warranty packet. Please install at a location near your spa, where it is visible to users of the spa. For additional or replacement Warning Signs please contact your local Jacuzzi dealer and reference item number #6530-082.

  • Page 12: Important Csa Safety Instructions (Canada Only)

    No. 6 AWG (10 mm²). 5. SAVE THESE INSTRUCTIONS. General Electrical Safety Instructions Your new Jacuzzi spa is equipped with a “state-of-the-art” equipment system. It contains the most advanced safety and self-protective equipment in the industry. Nonetheless, this spa must be installed properly to ensure dependable usage.

  • Page 13: Choosing A Location

    J-100 Choosing A Location IMPORTANT: Because of the combined weight of the spa, water and users, it is extremely important that the base upon which the spa rests be smooth, flat, level and capable of uniformly supporting this weight, without shifting or settling, for the entire time the spa is in place. If the spa is placed on a surface which does not meet these requirements, damage to the skirt and/or the spa shell may result.

  • Page 14: Outdoor Location

    J-100 Outdoor Location In selecting the ideal outdoor location for your spa, we suggest that you take into consideration: • The proximity to changing area and shelter (especially in colder weather). • The pathway to and from your spa (this should be free of debris so that dirt and leaves are not easily tracked into the spa).

  • Page 15: General Electrical Safety Instructions

    Proper grounding is extremely important. Jacuzzi spas are equipped with a current collector system. A pressure wire connector is provided on the surface of the control box, located outside the equipment door (Figure...

  • Page 16: Power Requirements

    J-100 Power Requirements Jacuzzi spas are designed to provide optimum performance and flexibility of use when connected to the maximum electrical service listed below. Minor circuit board modifications can be performed to allow your new spa to accept an electrical service other than the factory operation setting.

  • Page 17: Electrical Wiring Instructions

    J-100 Electrical Wiring Instructions IMPORTANT NOTICE: The electrical wiring of this spa must meet the requirements of the National Electrical Code/USA (NEC) and any applicable state or local codes. The electrical circuit must be installed by a qualified electrician and approved by a local building/electrical inspection authority.
  • Page 18 J-100 8. Connect wires, color to color, on terminal blocks TB1 and TB3 (Figure C, page 15). TIGHTEN SECURELY! All wires must be hooked up securely or damage could result. 9. Install control box door and screws and reinstall the cabinet side panels.

  • Page 19: Spa Fill Up Procedure

    Congratulations! You are now all set to get your new spa ready to use. Simply follow the step-by-step procedure in Section 8.0, before long, you will be enjoying your first glorious experience in your Jacuzzi J-100 Collection spa. Spa Fill Up Procedure For best results, read each step in its entirety before proceeding with that step.
  • Page 20 Turn on jets pump(s) to ensure proper mixing when adding start-up chemicals in step 5. 5. Add Start-Up Chemicals Add the spa water chemicals as recommended by your authorized Jacuzzi dealer. See Section 13.0 “Water Quality Maintenance” (page 31) for general guidance. WARNING: RISK OF POISONING OR DEATH.
  • Page 21 J-100 7. Set Spa To Heat To warm spa water to a comfortable temperature, follow these steps: • The LED display on the control panel displays the actual temperature of the spa water. Press either the COOLER ( ) or WARMER ( ) button once to display the “set”...
  • Page 22 J-100 Decontamination Procedure (Steps 9-16) Steps 9-16 below are only required when sanitizer levels are unstable after performing steps 1-6 above. Disregard steps 9-15 below if sanitizer levels remain stable after performing steps 1-6 above (refer to the inside cover of the manual).
  • Page 23 Water that is too soft can be corrosive to metal components. 13. Consult your authorized Jacuzzi dealer for chemical recommendations, then add chemicals to hot tub water to achieve a constant sanitizer reading within the levels recommended on the inside cover of this manual.

  • Page 24: Control Functions

    J-100 Control Functions Control Panel A. LED Display: Can display current water temperature (default display), water tem- perature set point, selected filtration/heat- ing mode, and error messages. B. Heat Indicator: Lit when heater is on. C. Jets 1 Button: Turns jets pump #1 on and off. Press once for low speed;...

  • Page 25: General Spa Features And Controls

    J-100 General Spa Features and Controls J-145 model illustrated - Jet locations and features vary by model. 1. Control Panel 10. Cup Holders (10 ea.) 2. Air Controls (3 ea.) 11. Filter skimmer with one un- 3. Headrest Pillows (4 ea.) derlying filter cartridge (Filter 4.

  • Page 26: Operating Instructions

    J-100 10.0 Operating Instructions The spa control system has automatic functions that operate upon start-up and normal operation to protect the system. Upon power up, the readout displays the following information: 1. Control panel displays current software release then; 2. Control panel displays “888” and all indicator LEDs are lit, permit- ting visual inspection of all display segments and indicator lights for proper operation.

  • Page 27: Activate Jet Pumps

    J-100 10.2 Activate Jet Pumps The control panel JETS 1 button activates jets pump 1. The first press activates low speed, the second press activates high speed, and the third press shuts jets pump 1 off. The JETS 2 button activates jets pump 2.

  • Page 28: Automatic Filtration Cycles

    J-100 11.0 Automatic Filtration Cycles The control system activates a programmable “Standard” or “Economy” filtration cycle to remove debris from your spa. These cycles use the low speed jets pump 1 and filter cartridge to quickly clear “skim” the water of debris and minimize their “bathtub ring”...
  • Page 29 J-100 With two pump models, an automatic one-minute “blow-out” function also activates pump 2 for a period of one minute to flush all lines. Then, after one minute, pump 2 turns off and pump 1 continues to operate for the duration of the cycle.

  • Page 30: Spa Maintenance

    12.0 Spa Maintenance Proper and regular maintenance of your spa will help it retain its beauty and performance. Your authorized Jacuzzi dealer can supply you with all the information, supplies, and accessory products you will need to accomplish this. DANGER: RISK OF SEVERE INJURY OR DROWNING BY ENTRAPMENT! •...

  • Page 31: Draining And Refilling

    Jacuzzi dealer. The average life expectancy of each filter is approximately two years with proper care and water quality maintenance.

  • Page 32: Pillow Care

    J-100 CAUTION! READ THIS BEFORE DRAINING: To prevent damage to the spa’s components, turn off power to the spa at the circuit breaker before draining it. Do not turn the power back on until your spa has been refilled. CAUTION: There are certain precautions to keep in mind when draining your spa.

  • Page 33: Vinyl Cover Care And Maintenance

    This could cause severe sudsing when the spa is refilled. 12.5 Vinyl Cover Care and Maintenance Your Jacuzzi cover has a vinyl encasement. This vinyl encasement is attractive and durable. Monthly cleaning and conditioning is strongly recommended to maintain and increase the longevity of your cover.

  • Page 34: Winterizing

    J-100 12.7 Winterizing Your Jacuzzi spa is designed to automatically protect itself against freezing when operating properly. During periods of severe freezing temperatures, you should check periodically to be certain that the electrical supply to the spa has not been interrupted. In extreme, bitter cold weather less than 32°F (0°C), choose the F3 “Standard”...

  • Page 35: Restarting Your Spa In Cold Weather

    This situation will block water flow preventing the spa from operating properly and possibly damaging the equipment. We recommend you consult your authorized Jacuzzi dealer for guidance before attempting to re-start your spa under these conditions.

  • Page 36: Sanitizing

    Some are necessary to compensate for out-of-balance water, some aid in cosmetic water treatment and others simply alter the feel or smell of the water. Your authorized Jacuzzi dealer can advise you on the use of these additives. When adding spa shock (chlorine or non-chlorine) or pH balancing chemicals activate the jets pump(s) and leave the spa cover open for a minimum of 20 minutes.

  • Page 37: Panel Displays Ice

    CAUSING SEVERE INJURY, BURNS, OR WELTS. Water temperature is above acceptable limits. DO NOT ENTER SPA! Water temperature has reached 112°F (44°C) and the low speed jets pump 1 has activated to circulate water through heater. Contact your authorized Jacuzzi dealer or qualified service technician.

  • Page 38: Panel Displays

    15.0 Troubleshooting Procedures In the event your Jacuzzi spa is not working the way it should, please first review all the installation and operating instructions in this manual and check the message on the panel display. If you are still not satisfied it is working properly, please follow the appropriate troubleshooting instructions below.

  • Page 39: Poor Jet Action

    Nonetheless, we are always striving to improve the quality and features of our products. Your input as a Jacuzzi spa owner is a cherished part of this process. If you have any comments or suggestions, or if you wish to be informed on any new products for your spa, please write to us.

  • Page 40: Circuit Board Diagrams

    J-100 16.0 Circuit Board Diagrams 16.1 North American J-135 and J-145 Models This wiring diagram is used for the 240V 60 Hz North American spa models.

  • Page 41: Export 50 Hz J-135 And J-145 Models

    J-100 16.2 Export 50 Hz J-135 and J-145 Models This wiring diagram is used for the 230V 50 Hz Export spa models.
