ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1
KTS794T-CS11-1
2
KTS794T-CS04-1
3
17C40A0712001YX
4
17C40A0716001YX
Attention:
Make sure that each bolt needed for all steps matches
the corresponding figure to ensure proper assembly.
Step 1:
Fasten the seat assembly (#1) to the base assembly
(#2) by using bolts (#3). Keep the bolts loose.
See Figure 1.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the chair is completely
assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO.when contacting the service center.
V-4
INTENDED FOR RESIDENTIAL USE ONLY.
KTS794T
PART
Q'TY
1
SEAT ASSEMBLY
1
BASE ASSEMBLY
2
BOLT M6*35
2
BOLT M6*45
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DO NOT RETURN TO THE STORE!
STOP
PAGE 1 OF 2
PART
MATERIAL CODE
NO.
5
1808010345701
6
17KAA0101----Y4
7
61K794TX00001BA
8
61K794TY00001BA
FIGURE 1
2
#3 BOLT M6*35
COURTYARD CREATIONS INC.
PART
PLASTIC CAP
HEX.KEY WRENCH 4MM
BACK CUSHION
SEAT CUSHION
1
3
35
Q'TY
2
1
1
1
5
