OPERA
Radiant
Convector
We value your feedback!
Your input helps to create even better
products and experiences.
Share the warmth and leave a review.
convectair.com/sharethewarmth
INSTALLATION AND USER'S GUIDE
To be read and kept by the user.
A BRAND OF GLEN DIMPLEX AMERICAS
7735
7736
7737
7216650000R00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CONVECTAIR OPERA 7735 and is the answer not in the manual?

Questions and answers

Related Manuals for Glen Dimplex CONVECTAIR OPERA 7735

Summary of Contents for Glen Dimplex CONVECTAIR OPERA 7735

  • Page 1 We value your feedback! Your input helps to create even better products and experiences. Share the warmth and leave a review. convectair.com/sharethewarmth INSTALLATION AND USER’S GUIDE To be read and kept by the user. A BRAND OF GLEN DIMPLEX AMERICAS 7216650000R00...

  • Page 2: Table Of Contents

    Foreword Dear owner, Congratulations on the purchase of your new CONVECTAIR electric heater. To obtain the best results and the ultimate in performance and comfort, please take a moment to read the installation, operation and maintenance instructions detailed in this manual. WARNING : Your heater is equipped with a precise electronic thermostat.

  • Page 3: Safety

    Safety WARNING Certains parts of this product can get very hot and cause burns. Special care should be taken in the presence of children and vulnerable people. This device may be used by children 8 years of age and over and by people with reduced physical, sensory or mental capabilities or lacking experience or knowledge, if they are adequately supervised or if instructions on the safe use of the device have been given and if the associated risks have been understood.
  • Page 4 Do not insert any object in the device. The device must not be installed under a power socket. 10 Minimum installation distances to the floor, walls, furniture, etc., must be respected. (Figure A). If the device is installed in a bathroom or powder room (Figure B), it must be installed outside of volume 2 at a minimum distance of 0.5 m from the bathtub and/ or shower and must be fitted with a class A differential circuit breaker.

  • Page 5: Quick Start

    Quick Start “Open window” Behavioral Heating Programs Heating function indicator indicator - predefined (P1/P2/P3) On/Off light - user-defined (P4/P5/P6) indicator light Selection of Desired manual Automatic Heating temperature operation modes operation key On/Off key setting keys Be sure to remove the protective film from the display. ACTIONS PRESS DISPLAY...

  • Page 6: Specifications

    Specifications Model Voltage Watts Width Height Depth Weight Opera 12 33 1/2" 11 1/8" 3 7/8" 10.6 lb 7735-C07-FS 240/208 750/565 850 mm 284 mm 99 mm 4.8 kg 41 3/4" 11 1/8" 3 7/8" 13 lb 7735-C10-FS 240/208 1000/750 1060 mm 284 mm 99 mm...

  • Page 7: Installation And Mounting

    Installation and Mounting The installation must comply with applicable national and local standards, and CONVECTAIR recommends that it be done by a certified electrician. This manual was prepared at the time of manufacture of the device and in accordance with the standards applicable at the time. The company reserves the right to modify at any time the Installation and User Guide to account for standards and their evolution.
  • Page 8 To install your device 15 cm (6 in.) from the floor (height recommended by CONVECTAIR), follow the instructions below: 1- Release the back panel by pinching and pulling the insertable tabs on the back of the device (Figure C). 2- Place the center of the back panel’s lower marking holes (No. 2 Figure C) at measurement C (see tables, Figures C - D - E - F - G) from the floor, and draw a mark.
  • Page 9 DEVICES OPERA 46 FIGURES Power (W) 1000 1500 2000 Measurements Center distance 24.8 9-3/4 24.8 9-3/4 24.8 9-3/4 3-3/4 3-3/4 3-3/4 46.8 18-3/8 46.8 18-3/8 46.8 18-3/8 24.2 9-1/2 29.4 11-1/2 47.4 18-5/8 3-3/4 3-3/4 3-3/4 Figure D Entraxe Center distance Encombrement de l’appareil Size of heater...
  • Page 10 DEVICE OPERA 17 OPERA 12 FIGURE Power (W) 1000 1500 2000 1000 Measurements Center distance 17.7 6-7/8 31.9 12-1/2 53.4 22.8 42.8 16-7/8 23.0 26.4 10-3/8 26.2 10-2/8 31.0 12-2/8 31.5 15-3/8 25.8 10-1/8 25.8 10-1/8 25.8 10-1/8 2-2/8 2-4/8 21.3 8-3/8 21.3 8-3/8 21.3...

  • Page 11: Electrical Connection

    Electrical Connection CONVECTAIR recommends that the devices be installed by a certified electrician, in accordance with applicable national and local codes. The appliance must be connected to a previously installed wall mounted rectangular junction box. Its size must be appropriate for the connecting cable(s) and the 2-3/4"...

  • Page 12: Operation

    Operation 6.1 SWITCHING ON AND OFF PRESS ACTIONS DISPLAY Switching on. The green indicator lights up and the screen displays Switching off. The orange indicator lights up and the screen displays This indicator shows that your device is heating up. When the desired temperature has stabilized, it lights up and turns off based on heating needs.
  • Page 13 6.3 ECONOMY MODE (“ECO”) du Lundi au Vendredi PRESS ACTIONS DISPLAY 17h à 23h 5h à 9h Press successively to access the “ECO” mode. The screen displays: 0h 2 4 10 12 14 16 18 20 22 24 Mode Indicateur de du Lundi au Vendredi Briefly and simultaneously press to visualize the “ECO”...
  • Page 14 6.5 AUTOMATIC OPERATION PRESS ACTIONS DISPLAY Press for 3 seconds to save your preferred settings. Press briefly for automatic operation based on your heating plan (programming of Comfort and Eco temperature ranges) and your setting preferences (preferred set point temperature, Window function, etc.). NOTE By default, the stored setting is: Preferred set temperature 19°C, Open window function enabled.
  • Page 15 6.7 ABSENCE DETECTION / ENABLING Mode PRESS ACTIONS DISPLAY The function is automatically enabled in automatic mode. It can be disabled (see the following table). AUTO Mode NOTE In the event of a prolonged absence, the device progressively lowers the set point temperature. When it detects a presence, it reacts and returns to the operating mode defined by the user.
  • Page 16 6.7 ABSENCE DETECTION / ENABLING OPTION 1 – PRIORITIZES COMFORT DETECTION PILOT WIRE ORDER RESULT Gradual COMFORT transition in ECO (90 min) absence ECO mode Immediate absence movement COMFORT transition in Comfort movement ECO mode OPTION 2 – PRIORITIZES COMFORT DETECTION PILOT WIRE ORDER RESULT Gradual COMFORT...
  • Page 17 AUTO Mode 6.8 OPEN WINDOW DETECTION FUNCTION PRESS ACTIONS DISPLAY Enable the function. Press and hold until the window icon is displayed on the screen. The window icon and the green indicator flash when the device turns off following a detection event. AUTO Following an interruption, press again to...
  • Page 18 Mode 17h à 23h 5h à 9h Indicateur de du Lundi au Vendredi consommation 0h 2 4 10 12 14 16 18 20 22 24 12h à 14h 17h à 23h 5h à 9h 6.9 PARENTAL LOCK WITH CODE AUTO AUTO Indicateur de du Lundi au Vendredi...
  • Page 19 6.10 CONSUMPTION SCALE INFORMATION DISPLAY This indicator provides information about the effect of your settings on your Consumption consumption. scale Indicator Green = Economical Red = Less economical NOTE For economical operation, it is recommended not to exceed a temperature of 19°C on average over the entire dwelling.
  • Page 20 6.11 SETTING OF AUXILIARY FUNCTIONS (CONTINUED) PRESS ACTIONS DISPLAY SETTINGS SCREEN 2 ENABLE / DISABLE THE BUZZER Select one of these buzzer options. | = Enabled O = Disabled NOTE The buzzer remains active for the heating On/Off key. Allows you to switch to the next settings screen. SETTINGS SCREEN 3 CELSIUS / FAHRENHEIT SELECTION Select one of these options.
  • Page 21 Mode 6.12 DETAILS OF THE 6 ORDERS GIVEN VIA THE PILOT WIRE Mode ORDERS ACTION DISPLAY Mode Heating Heating is instantly turned off. AUTO AUTO Mode AUTO Mode Lowering of the temperature by 3.5°C relative to the Comfort Indicateur de consommation position or at your choice.
  • Page 22 Indicateur de consommation 6.13 INTERNAL PROGRAMMING (CONTINUED) Indicateur de consommation A- SETTING THE TIME Indicateur de PRESS ACTIONS DISPLAY consommation Mode Simultaneously press for 3 seconds to access the programming menu. Indicateur de consommation Mode Mode Select one of these options. ON = Continue Mode OFF = Exit the setting...
  • Page 23 Indicateur de Mode consommation AUTO AUTO 6.13  INTERNAL PROGRAMMING (CONTINUED) B - SETTING THE DAY AUTO AUTO PRESS ACTIONS DISPLAY AUTO AUTO Indicateur de NOTE consommation Start with the previous section A - SETTING THE TIME to access the AUTO AUTO programming menu.
  • Page 24 6.13 INTERNAL PROGRAMMING (CONTINUED) du Lundi au Vendredi 17h à 2 5h à 9h PROGRAMMING SET UP du Lundi au Vendredi PRESS ACTIONS DISPLAY 17h à 5h à 9h 0h 2 4 10 12 14 16 18 2 du Lundi au Vendredi NOTE 0h 2 4 10 12 14 16 18...
  • Page 25 6.13 INTERNAL PROGRAMMING (CONTINUED) PROGRAMMING SET UP Monday to Friday PREDEFINED PROGRAMS (P1 / P2 / P3) 17h - 23h 5h - 9h PREDEFINED PROG. CHOICE MEANING 0h 2 4 10 12 14 16 18 20 22 24 Monday to Friday Monday to Friday The P1 program enables you to use the Comfort set 17h - 23h...
  • Page 26 6.13 INTERNAL PROGRAMMING (CONTINUED) PROGRAMMING SET UP PRESS ACTIONS DISPLAY NOTE This mode enables the automatic operation of your heater at either the COMFORT set point or the ECO set point. Simultaneously press for 3 seconds to access the programming menu. Select one of these options.
  • Page 27 6.13 INTERNAL PROGRAMMING (CONTINUED) PROGRAMMING SET UP SEQUENCE OF ACTIONS RESULT Example of “P4” programming You want to set the Time range COMFORT set point No. 3 from 6 p.m. temperature for to 10 p.m. is 3 different time ranges: confirmed. You will return to the mornings from 6 a.m.

  • Page 28: Troubleshooting

    Troubleshooting VERIFICATION PRESS ACTION THE DEVICE IS NOT HEATING. Make sure the Power up the device. digital screen is active. Successively press to reach the comfort position. Make sure the installation circuit breakers are If the digital screen has still not turned on pushed in and press to power up.
  • Page 29 HARMONIZATION OF DISPLAYS (THERMOSTAT / THERMOMETER) NOTE This operation is optional. There may be a difference between the readings displayed on the device and on your thermometer. It is possible to harmonize both displays. Procedure: • This setting can only be performed if your device is set between 17 and 23°C.

  • Page 30: Automatic Thermal Safety

    Automatic Thermal Safety This device is equipped with an automatic thermal safety feature. During abnormal operation (for example, blocked air inlet or outlet), the device automatically stops. Once the abnormal operation is corrected, and as soon as the device has cool sufficiently, it will automatically restart.

  • Page 31: Identification Of Your Device

    Identification of Your Device IMPORTANT: PRODUCT INFORMATION APPEARS ON THE RATING LABEL. The rating label is placed at the back, on the bottom right (control side) of your device, and is used for identification purposes. It consists of: - The complete reference number of the device (A), to be specified in case of repair. - The wattage, voltage and frequency of the device (B).
  • Page 32 Share the warmth and leave a review. convectair.com/sharethewarmth 1 800 463-6478 | www.convectair.ca In keeping with our policy of continuous product improvement, we reserve the right to make changes without notice. A BRAND OF GLEN DIMPLEX AMERICAS © 2021 Glen Dimplex Americas...
