- Page 1 LCD/LED 2311W PV USER MANUAL + GERMAN + ENGLISH + FRENCH + SPANISH + ITALIAN + RUSSIAN + P O L I S H + C Z E C H...
- Page 2 Operation Instructions Thank you for purchasing this monitor, a high-resolution multi-scan color monitor. Please read this guide thoroughly before installation. This monitor has been tested and found compliant with the CE mark. These limits are designed to provide proper protection against harmful interference to a residential installation.
-
Page 3: Table Of Contents
Content Safety Precautions ....................... 1 First Setup ........................... 2 Quick Installation ......................... 3 Illustration for turning the high adjustable stand base ............4 Front View of the Product ....................5 Rear View of the Product ..................... 6 Using On Screen Display (OSD) Functions ................. 7 Supporting Timing Modes .................... -
Page 4: Safety Precautions
Pay attention to all cables connected to the monitor against stumble hazards. According to WEEE regulation, this monitor can't be handled as normal trash in Europe when it is out of usage. Please refer to the recycle information from our website to handle it. www.wortmann.de... -
Page 5: First Setup
First Setup Congratulation for purchasing this monitor of high performance! This monitor comes with the following accessories: AC Power cord ● HDMI cable Warranty card ● Quick start guide Screwdriver ... -
Page 6: Quick Installation
Quick Installation 1. Connect Video cable (HDMI cable) Make sure both monitor and computer are powered OFF. Connect the HDMI cable from HDMI output of computer to the HDMI input of the monitor. Or connect VGA cable *Optional Connect the VGA cable from VGA output of computer to the VGA input of the monitor. 2. -
Page 7: Illustration For Turning The High Adjustable Stand Base
Illustration for turning the high adjustable stand base (1) Tilt Angle Tilt UP: 20° Tilt DOWN: -5° (2) Lift Range 130mm (3) Swivel Angle Left: 45° Right: 45° (4) Pivot Angle Right: 90°... -
Page 8: Front View Of The Product
Front View of the Product ❶ ❷ ❸ ❹ ❺ ❻ ❶ OSD Menu On/Off ❷ Scroll Down/ Decrease ❸ Scroll Up/ Increase ❹ Confirm Select ❺ Power ON/OFF ❻ LED Indicator... -
Page 9: Rear View Of The Product
Rear View of the Product ❶ ❷ ❸ ❹ ❶ HDMI input ❷ VGA input ❸ Cable Management ❹ Power input... -
Page 10: Using On Screen Display (Osd) Functions
Using On Screen Display (OSD) Functions Display main menu Exit from OSD menu Select the desired item when in OSD menu ▲ When not in OSD menu, directly enters the Anti Blue Light menu Select the desired item when in OSD menu ▼... - Page 11 Contrast/Brightness: To manually adjust the Contrast, Brightness, DCR, ECO and Over Drive of screen image. Contrast: To adjust the foreground white level of screen image. ▲: increase contrast, ▼: decrease contrast. Brightness: To adjust the luminance of the video. ...
- Page 12 Information: To display the information, regarding the current input signal coming from the graphic card in your computer. Note: See your graphic card user guide for more information about changing the resolution and refresh rate. Manual Image Adjust: To manually adjust the H. / V. Position, Horizontal Size, Fine tune, Sharpness and Video Mode Adjustment.
-
Page 13: Supporting Timing Modes
Supporting Timing Modes 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA 800 x 600 @ 75Hz 832 x 624 @ 75Hz... -
Page 14: Technical Information
Technical Information Technical Specification LCD Panel 58.4 cm (23″) VESA DPMS compatible Power Management Off Mode, ≤ 0.3 W FHD 1920 x 1080 max. Displayable Resolution Vertical Frequency 60Hz max. Pixel Dimension 0.2652 x 0.2652 mm LCD Display Color 16.7M Active Display Area 509.18 mm x 286.42 mm Operating: 0°C ~ + 40°C... -
Page 15: Care And Maintenance
