LCD/LED 2766W PV
USER MANUAL
+ GERMEN
+ ENGLISH
+ FRENCH
+ SPANISH
+ ITALIAN
+ RUSSIAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the terra LED 2766W PV and is the answer not in the manual?

Questions and answers

Related Manuals for Wortmann terra LED 2766W PV

Summary of Contents for Wortmann terra LED 2766W PV

  • Page 1 LCD/LED 2766W PV USER MANUAL + GERMEN + ENGLISH + FRENCH + SPANISH + ITALIAN + RUSSIAN...
  • Page 2 Operation Instructions Thank you for purchasing this monitor, a high-resolution multi-scan color monitor. Please read this guide thoroughly before installation. This monitor has been tested and found compliant with the CE mark. These limits are designed to provide proper protection against harmful interference to a residential installation. This monitor generates, uses, and can radiate radio frequency energy.

  • Page 3: Table Of Contents

    Content Safety Precautions ......................1 First Setup ........................... 2 Quick Installation ......................... 3 Illustration for turning the high adjustable stand base ............4 Front View of the Product ....................5 Rear View of the Product ..................... 6 Using On Screen Display (OSD) Functions ................. 7 Supporting Timing Modes ....................

  • Page 4: Safety Precautions

     Pay attention to all cables connected to the monitor against stumble hazards. According to WEEE regulation, this monitor can't be handled as normal trash in Europe when it is out of usage. Please refer to the recycle information from our website to handle it. www.wortmann.de...

  • Page 5: First Setup

    First Setup Congratulation for purchasing this monitor of high performance! This monitor comes with the following accessories: AC Power cord ● DisplayPort cable  Audio cable ● Quick start guide  Warranty card ...

  • Page 6: Quick Installation

    Quick Installation 1. Connect Video cable (DisplayPort cable) Make sure both monitor and computer are powered OFF. Connect the DisplayPort cable from DisplayPort output of computer to the DisplayPort input of the monitor. Or connect HDMI cable *Optional Connect the HDMI cable from HDMI output of computer to the HDMI input of the monitor.

  • Page 7: Illustration For Turning The High Adjustable Stand Base

    Illustration for turning the high adjustable stand base -5~20° (1) Tilt Angle Tilt UP: 20° Tilt DOWN: -5° (2) Lift Range 130mm 130mm (3) Swivel Angle Left: 140° 140° 140° Right: 140° 90° (4) Pivot Angle Right: 90° 90° Note In order to avoid scratched footstand.

  • Page 8: Front View Of The Product

    Front View of the Product ❶ ❷ Power ON/OFF (press the button) ◄ OSD Menu On/Off ► Confirm Select ❶ ▲ Scroll Up/ Increase ▼ Scroll Down/ Decrease LED Indicator ❷...

  • Page 9: Rear View Of The Product

    Rear View of the Product ❻ ❼ ❸ ❹ ❺ ❶ ❷ DisplayPort input ❶ DVI input ❷ HDMI input ❸ Audio input ❹ Earphone output Note: Adjustment of the volume control to other settings than the center ❺ position may increase the ear-/ headphones output voltage and therefore the sound pressure level.

  • Page 10: Using On Screen Display (Osd) Functions

    Using On Screen Display (OSD) Functions Power ON/OFF (press the button) When in OSD menu, press more than 3 seconds to switch display power Display main menu ◄ Exit from OSD menu Manual adjust mode select for DVI, HDMI, DisplayPort mode ►...
  • Page 11 Picture: To manually adjust the Brightness, Contrast, Sharpness, Over Drive, DCR and ECO of screen image. Brightness: To adjust the luminance of the video.  ▲: increase brightness, ▼: decrease brightness. Contrast: To adjust the foreground white level of screen image. ...
  • Page 12 OSD Settings: To set up OSD H. Position, OSD V. Position, OSD Background and OSD Time Out. OSD H. Position: To horizontally adjust the OSD position.  ▲: move OSD to the right, ▼: move OSD to the left. OSD V. Position: To vertically adjust the OSD position. ...

  • Page 13: Supporting Timing Modes

    Supporting Timing Modes 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA...

  • Page 14: Technical Information

    Technical Information Technical Specification LCD Panel 68.6 cm (27") Power Management VESA DPMS compatible Off Mode, < 0.5 W Displayable Resolution WQHD 2560 x 1440 max. Vertical Frequency 60Hz max. Pixel Dimension 0.2331 x 0.2331 mm LCD Display Color 16.7M Active Display Area 596.74 mm x 335.66 mm Temperature...

  • Page 15: Care And Maintenance

    Care and Maintenance Care  Avoid exposing your monitor directly to sunlight or other heat source. Place your monitor away from the sun to reduce glare.  Put your monitor in a well ventilated area.  Do not place any heavy things on top of your monitor. ...
  • Page 16 Pour plus d'information sur le recyclage, veuillez contacter votre centre de recyclage agréé. Votre attitude quand au recyclage améliorera l'avenir de la planète et créera un environnement de vie de qualité pour les générations futures. Wortmann AG Bredenhop 20 D-32609 Hüllhorst Tel.
  • Page 17 License and to the absence of any warranty; and give any other recipients of the Program a copy of this WORTMANN AG License along with the Program.
  • Page 18 with a work based on the Program) on a volume of a storage or distribution medium does not 10. If you wish to incorporate parts of the Program into other free programs whose distribution bring the other work under the scope of this License. conditions are different, write to the author to ask for permission.

This manual is also suitable for:

Terra 3030083
