GIGAIPC QBiX-Plus-KBLA7100-A1 Quick Start Manual

Please visit h�p://www.gigaipc.com to find QBiX-Plus warranty informa�on from the drop down list.
h�p://www.gigaipc.com

Dimension

180.00
80.00 50.00
* WiFi/ 3G Antenna connectors are op�onal part.
GIGAIPC Co., LTD.
B1-A, No.205, Sec. 3, Beixin Rd., Xindian Dist., New Taipei City 23143, Taiwan (R.O.C) h�p://www.gigaipc.com
© 2018 GIGAIPC Co., Ltd. All rights reserved. The marks men�oned herein are trademarks or registered trademarks of GIGAIPC Co., Ltd. or its affiliantes. All
other product names men�oned herein are trademarks or registered trademarks or their respec�ve owners.
The terms HDMI and HDMI High-Defini�on Mul�media Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LCC in the
United States and other couintries.
h�p://www.gigaipc.com h�p://www.gigaipc.com
117.00
Made in China
QBiX-Plus-KBLA7100-A1
Industrial system with Intel® Core™ i3-7100U Processor
Front
Rear
Headphone &
Microphone
2
1
Trigger Pin
1 1
11
1 Trigger 11 Ground
round round round

Package Contents

QBiX Plus-KBLA7100-A1 Bare-bone
- NOT Include any of the following: M.2 (2280), 3G module, SIM card, SO-DIMM memory
- WiFi antenna and 1 x 3G antenna (op�onal)
*QBix-Plus-KBLA7100-A1 Full-System (Include memory and storage) order by customer's
request.
1 x VESA Mount Bracket & 6 x Screws
1 x 65W Adapter & Power Cord, * Power input: DC 19V, 3.42A
Op�onal Kit
- Internal Antenna 90mm : 25CA0-090003-A5S
- Internal Antenna 120mm : 25CA0-120002-A5S
- Internal Antenna 120mm : 25CA0-120003-A5S
- WiFi module : 25FC7-3165N0-10R
- Antenna_WiFI x 2 : 25CA0-111000-A5S
- Antenna_3G x 1 : 25CA0-111001-A5S
Right
3G antenna connector (Op�onal Parts)
WiFi antenna connector (Op�onal Parts)
B
D
A
TPM
C
TRIGGER GPIO
D) 2 x DDR4 SO-DIMM sockets
GPIO TPM
6 4
11 7 1 1
1 GPO1
round
7 GPO4
14
11
14 Ground
