- Page 1 Installation Manual SIMATIC NET Rugged Ethernet Switches RUGGEDCOM RS1600 Edition 01/2021 https://www.siemens.com...
- Page 2 Preface Introduction Installing Device SIMATIC NET Device Management Rugged Ethernet Switches RUGGEDCOM RS1600 Communication Ports Technical Specifications Installation Manual Certification 01/2021 C79000-G8976-1013-03...
- Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 4: Table Of Contents
Accessing Documentation ....................... v Registered Trademarks ......................v Warranty ..........................v Training ..........................vi Customer Support ........................vi Contacting Siemens ....................... vii Introduction ........................... 1 Feature Highlights ....................1 Description ......................2 Decommissioning and Disposal ................4 Cabling Recommendations ..................4 1.4.1... - Page 5 European Union (EU) ..................27 6.1.3 FCC ........................28 6.1.4 FDA/CDRH ......................29 6.1.5 ISED ........................29 6.1.6 ISO ........................29 6.1.7 ACMA ........................29 6.1.8 RoHS ........................30 EMC and Environmental Type Tests ..............30 RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
-
Page 6: Preface
Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. -
Page 7: Training
Siemens Sales representative. Customer Support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: Online Visit http://www.siemens.com/automation/support-request... -
Page 8: Contacting Siemens
Preface Contacting Siemens • Ask questions or share knowledge with fellow Siemens customers and the support community Contacting Siemens Address Siemens AG Industry Sector 300 Applewood Crescent Concord, Ontario Canada, L4K 5C7 Telephone Toll-free: 1 888 264 0006 Tel: +1 905 856 5288... - Page 9 Preface Contacting Siemens viii RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
-
Page 10: Introduction
(EMI) and heavy electrical surges typical of environments found in electric utility substations, industrial plant floors or in curb side traffic control cabinets. The RUGGEDCOM RS1600 provides IEEE 1613 Class 2 error-free communications performance under EMI stress. -
Page 11: Description
Terminal blocks for reliable maintenance free connections • CSA/UL 60950 safety approved to 85 °C (185 °F) Description The RUGGEDCOM RS1600 features various ports, controls and indicator LEDs on the front and rear panels for configuring and troubleshooting the device. RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03... - Page 12 "Connecting to the Device (Page 17)". Communication Ports Receive and transmit data. For more information about the various ports available for the RUGGEDCOM RS1600, refer to "Communication Ports (Page 19)". RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
-
Page 13: Decommissioning And Disposal
Siemens also does not recommend using copper Ethernet ports to interface with devices in the field across distances that could produce high levels of ground potential rise (i.e. greater than 2500 V), during line-to-ground fault conditions. -
Page 14: 1.4.1 Supported Fiber Optic Cables
1000Base-SX 10GBase-SR OM1 (62.5/125) — 1300 2000 — — OM2 (50/125) — 1300 2000 — — OM3 (50/125) 1500 — 1300 2000 — — OM4 (50/125) 3500 — 1300 2000 — — Laser optimized. RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03... - Page 15 Introduction 1.4.1 Supported Fiber Optic Cables RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
-
Page 16: Installing Device
Mounting the Device The RUGGEDCOM RS1600 is designed for maximum mounting and display flexibility. It can be equipped with connectors that allow it to be installed in a 48 cm (19 in) rack, 35 mm (1.4 in) DIN rail, or directly on a panel. -
Page 17: 2.1.1 Mounting The Device To A Rack
"Dimension Drawings (Page 23)". 2.1.1 Mounting the Device to a Rack For rack mount installations, the RUGGEDCOM RS1600 can be equipped with rack mount adapters pre-installed. Note The chassis features multiple mounting holes, allowing the rack mount adapters to be installed up to 25 mm (1 in) from the face of the device. -
Page 18: 2.1.2 Mounting The Device On A Din Rail
2.1.2 Mounting the Device on a DIN Rail For DIN rail installations, the RUGGEDCOM RS1600 can be equipped with panel/DIN rail adapters pre-installed on each side of the chassis. The adapters allow the device to be slid onto a standard 35 mm (1.4 in) DIN rail. -
Page 19: Connecting Power
Install the supplied screws to secure the adapters to the panel. Connecting Power The RUGGEDCOM RS1600 supports single or dual redundant high AC, high DC and/or low DC power supplies. The use of two power modules is recommended to provide redundancy and load balancing. -
Page 20: Connecting Ac Power
This cable connects transient suppression circuitry to chassis ground and must be removed in order to avoid damage to transient suppression circuitry during testing. RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03... -
Page 21: 2.2.2 Connecting Dc Power
This cable connects transient suppression circuitry to chassis ground and must be removed in order to avoid damage to transient suppression circuitry during testing. RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03... -
Page 22: Wiring Examples
Connect the ground terminal on the power source to the chassis ground terminal on the device. 2.2.3 Wiring Examples The following illustrate how to connect power to single and dual power supplies. RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03... - Page 23 ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. POWER SUPPLY 1 POWER SUPPLY 2 Figure 2.6 Single AC Power Supply Figure 2.7 Single DC Power Supply Figure 2.8 Dual AC Power Supply Figure 2.9 Dual DC Power Supply RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
-
Page 24: Connecting The Failsafe Alarm Relay
Control of the failsafe relay output is configurable through RUGGEDCOM RS1600 . One common application for this relay is to signal an alarm if a power failure occurs. For more information, refer to the RUGGEDCOM RS1600 User Guide for the RUGGEDCOM RS1600. - Page 25 Installing Device 2.3 Connecting the Failsafe Alarm Relay RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
-
Page 26: Device Management
Clear To Send Reserved (Do Not Connect) Communication Ports Connect any of the available Ethernet ports on the device to a management switch and access the RUGGEDCOM RS1600 console and Web interfaces via the device's IP RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03... -
Page 27: Resetting The Device
19)". Resetting the Device The RUGGEDCOM RS1600 can be reset (rebooted) using the RESET button. The RESET button is recessed and can only be reached using a pin or small screwdriver. To reset the device, quickly press and release the RESET button with a pin. -
Page 28: Communication Ports
RS1600 . For more information on how to access the factory data file, refer to the RUGGEDCOM RS1600 User Guide for the RUGGEDCOM RS1600. Each communication port type has a specific place in the RUGGEDCOM RS1600 chassis. Ports 1 to 12... -
Page 29: Fiber Optic Ethernet Ports
Tx Connector Tx Connector Rx Connector Rx Connector Figure 4.4 LC Port Figure 4.3 MTRJ Port For specifications on the available fiber optic Ethernet ports, refer to "Fiber Optic Ethernet Port Specifications (Page 22)". RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03... -
Page 30: Technical Specifications
30 VAC 0.3 A 30 VDC 80 VDC 0.3 A Copper Ethernet Port Specifications The following details the specifications for copper Ethernet ports that can be ordered with the RUGGEDCOM RS1600. Maximum Speed ConnectorDuplex Cable Type Wiring Standard Isolation Distance... -
Page 31: Fiber Optic Ethernet Port Specifications
Typical distance. Dependent on the number of connectors and splices. RMS 1 minute. Fiber Optic Ethernet Port Specifications The following details the specifications for fiber optic Ethernet ports that can be ordered with the RUGGEDCOM RS1600. 10Base-FL/100Base-SX Ethernet Optic Tx (dBm) Power Connector Tx λ... -
Page 32: Dimension Drawings
Technical Specifications 5.7 Dimension Drawings Dimension Drawings Note All dimensions are in millimeters, unless otherwise stated. 438.2 Figure 5.1 Overall Dimensions RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03... - Page 33 Technical Specifications 5.7 Dimension Drawings 464.6 479.4 Figure 5.2 Rack Mount Dimensions RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
- Page 34 Technical Specifications 5.7 Dimension Drawings 486.4 476.3 Figure 5.3 Panel and DIN Rail Mount Dimensions RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
- Page 35 Technical Specifications 5.7 Dimension Drawings RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
-
Page 36: Certification
Information Technology Equipment - Safety - Part 1: General Requirements The device is marked with a CSA symbol that indicates compliance with both Canadian and U.S. requirements. A copy of the CSA Certificate of Compliance is available via Siemens Industry Online Support at https://support.industry.siemens.com/cs/ww/en/view/109476557. 6.1.2... -
Page 37: 6.1.3 Fcc
Products with Respect to the Restriction of Hazardous Substances The device is marked with a CE marking and can be used throughout the European community. A copy of the CE Declaration of Conformity is available from Siemens AG. For contact information, refer to "Contacting Siemens (Page vii)". -
Page 38: Fda/Cdrh
Title 21 Code of Federal Regulations (CFR) – Chapter I – Sub-chapter J – Radiological Health 6.1.5 ISED This device is declared by Siemens AG to meet the requirements of the following ISED (Innovation Science and Economic Development Canada) standard: • CAN ICES-3 (A)/NMB-3 (A) 6.1.6... -
Page 39: Rohs
Certification 6.1.8 RoHS 6.1.8 RoHS This device is declared by Siemens AG to meet the requirements of the following RoHS (Restriction of Hazardous Substances) directives for the restricted use of certain hazardous substances in electrical and electronic equipment: • China RoHS 2... - Page 40 2.5 kV Common and Differential Mode @ 1MHz HV Impulse Signal Ports 5 kV (Failsafe Relay) DC Power Ports 5 kV AC Power Ports 5 kV Dielectric Signal Ports 2 kVAC (Failsafe Relay) Strength DC Power Ports 1.5 kVDC RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
- Page 41 Humidity (Damp Test Db 95% (non-condensing), Heat, Cyclic) 55 °C (131 °F), 6 cycles IEC 60255-21-1 Vibration Level 2 (2 g @ 10-150 Hz) IEC 60255-21-2 Shock Level 2 (30 g @ 11 ms) RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
- Page 42 Further Information Siemens RUGGEDCOM https://www.siemens.com/ruggedcom Industry Online Support (service and support) https://support.industry.siemens.com Industry Mall https://mall.industry.siemens.com Siemens AG Digital Industry Process Automation Postfach 48 48 90026 NÜRNBERG GERMANY...
