English
Dust/water protection ....................................... IP54
Operating temperature ....................................-10°C +40°C
Weight ....................................................................0,270 kg
APPLICATION
Line laser ADA ARMO 2D / ADA ARMO 2D GREEN is designed to check the
horizontal and vertical position of the surfaces of the elements of building
structures and also to transfer the angle of inclination of the structural part
to similar parts during construction and installation works.
FUNCTIONAL CHARACTERISTICS
• 1 vertical line, 1 horizontal line.
• Receiver mode for outdoor operation.
• Slope mode
• Compensator for fast self-leveling works in the range up to ± 4°.
• The alarm is activated (laser lines are blinking), when the device deviates
from the horizontal plane by ± 4°.
• The possibility to switch on/off laser lines separately.
• When turning off the power, built-in locking system can automatically
lock the compensator to avoid vibration in the transportation.
LASER LINES
1
2
FEATURES
1. Horizontal and Vertical laser window
2. Keypad
3. External power
4. Switch ON handle (compensator lock)
5. Battery compartment
6. Screw lug
7. Magnets
8. Thread 1/4"
9. Horizontal and vertical lines
On/Off button
10. Detector mode On/off button
11. Laser lines indicator
12. Detector mode On/Off indicator
