High Output Optical Talk Set (HOOTS)
HO-850
HO-1300
HOOTS
Multimode
Operations Guide
OWL
Optical Wavelength Laboratories
Date: August 10, 2006
Version 1.3
5 Commonwealth Ave
Woburn, MA 01801
Phone 781-665-1400
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com
Advertisement
Related Manuals for OWL HOOTS HO-850
Summary of Contents for OWL HOOTS HO-850
- Page 1 HOOTS High Output Optical Talk Set Multimode Operations Guide Optical Wavelength Laboratories Operations Guide Date: August 10, 2006 High Output Optical Talk Set (HOOTS) HO-850 Version 1.3 HO-1300 5 Commonwealth Ave Woburn, MA 01801 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com...
- Page 2 HOOTS Optical Talk Set General Description HOOTS stands for High Output Optical Talk Set. There are two configurations of the HOOTS: 850nm (HO- 850) or 1300nm (HO-1300). The transmitter in the HOOTS also serves as a calibrated -20.0 dBm multimode light source.
- Page 3 HOOTS Optical Talk Set Operation You will need a pair of fibers terminated into a to headset connector at both ends of the link in order to use the HOOTS. Connect to the transmit and receive fibers to the talk set connectors (as shown in the figure at right). The other end must have its fibers connected opposite to the other, i.e.
- Page 4 HOOTS Optical Talk Set Key Specifications Receiver Dynamic Range -20 to -40 dBm Source Power -20 dBm into multimode Initial Accuracy +/- .10dB @ 25 C NIST traceable 850nm (HO-850) or 1300nm (HO-1300) calibrated wavelengths Center Wavelength 850nm +/- 20nm (HO-850) 1300nm +50/-10nm (HO-1300) Spectral Width 35nm @ 850nm (HO-850)
