Rampage I-TVR-01 Installation Instructions Manual

For technical assistance or to obtain missing parts, please call Customer Relations at 1-800-241-7219.
Important Safety Information
• To be used with Lund® branded products only.
• Periodically check all components for tightness.
• Be sure to wear safety goggles while installing.
• When using power tools, read and understand all operating instructions
Contents
NOTE: Actual product may vary from illustration.
Soft Top Components x1
(Soft Top, Side Windows, Rear Window)
Puddle Polesy x2
End Clamp Backing x2
Small Turn Knobs x2
Tools Required
Phillips screwdriver
Preparation Before Installation
• Remove existing soft or hard top. For OEM (original/factory) soft tops: remove windshield header bar, remove tube frame
hardware from roll bar, side door surrounds and remove the rear window/tailgate bar/tail gate clips.
Installation Instructions
Retractable Soft Top
For proper installation and best possible fit, please read all instructions BEFORE you begin.
End Clamp Main Body x2
Short Middle Knobs x2
Tailgate Bar x1
60mm length knobs x2
Ratchet and extensions
Set Door Surrounds x1
Retractable Trailview
Hardware x1
Self Tapping Screws x30
70mm length knobs x2
Torx Bits
Page 1 of 11
I - Sheet Number I-TVR-01 Rev. A
Tailgate Bar x1
Allen Key x2
Hook and Loop Tape
for door surround x2
Safety Glasses
Allen Wrench
