Rampage 26631 Installation Instructions Manual

18-19 Jeep Wrangler
JL Unlimited
For proper installation and best possible fit, please read all instructions BEFORE you begin.
For technical assistance or to obtain missing parts, please call Customer Relations at
Important Safety Information
• CAUTION - Before driving, ensure that the steps are properly secured to vehicle.
• Periodically check all components for tightness.
Contents
8mm x 35mm
Bolt (6)
Tools Required
Installation
1
Remove any Factory or aftermarket steps or rock rails present on the vehicle.
2
Start installation on the driver/left side of the
vehicle.
Locate the (3) pairs of factory mounting holes
along the pinch weld. See Figure 1.
The mounting brackets on the Rail Side Steps
attach to the holes in the pinch weld and the
small factory threaded hole directly behind the
pinch weld. See Figures 2 - 4
Figure 2
FRONT
Pinch Weld Holes
Installation Instructions
Rail Side Step
Left Step
8mm Lock 8mm Flat
Washer(6) Washer(6)
Socket
Wrench
Figure 3
Threaded Hole
Front
NOTE: Actual product may vary from illustration.
6mm x 25mm
Bolt (12)
Socket (Set) 18mm Wrench
Figure 1
Threaded Hole
CENTER
Pinch Weld Holes
Front
Page 1 of 3
1-800-328-2409
Right Step
6mm Nylock
6mm Flat
Washer(24)
Safety glasses
Figure 4
REAR
Pinch Weld Holes
IS-26631_RevA
Nut (12)
Threaded Hole
Front
