Rampage 8825 Manual

87-95 Jeep Wrangler YJ
97-06 Jeep Wrangler TJ
1 Driver/Left Nerf Bar
1 Passenger/Right Nerf Bar
4 Mounting Brackets
Passenger Nerfbar
PROCEDURE:
1. REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS
CAREFULLY. FACTORY INSTALLED OR AFTERMARKET "ROCK RAILS," SIDE STEPS OR
RUNNING BOARDS MUST BE REMOVED.
2. Start installation toward the front of the driver side of the vehicle. Remove the factory body mount bolt.
Select (1) Frame Mounting Bracket. Insert the factory body mount bolt through the appropriate slot, the
rubber bushing and back into the vehicle. NOTE: Do not remove the rubber bushing. The Mounting
Bracket will install over the rubber bushing. IMPORTANT: The Brackets are equipped with (2) mounting
slots. Determine correct model year for proper installation:
a. 1987 - 1995 Vehicles: Use the inner slot. Do not tighten hardware at this time.
b. 1997 - 2006 Vehicles: Use the outer slot closer to the bend in the Bracket. Do not tighten
hardware at this time.
3. Repeat Step 2 for rear Mounting Bracket installation.
4. Carefully unwrap and position the driver Sidebar onto the Brackets. NOTE: Longer leg on Sidebar will
bolt to the front Mounting Bracket. Attach the Sidebar to the Mounting Brackets using the included (2)
1/2" x 2" Hex Bolts, (2) 1/2" Lock Washers and (2) 1/2" Flat Washers (Figure 4). Do not tighten at this
time.
5. Level and adjust the Side Bar and Brackets and tighten all hardware.
6. Repeat Steps 2 - 5 for Passenger Sidebar installation.
7. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
To protect your investment, wax this product after installing. Regular waxing is recommended to add a protective layer
over the finish. Do not use any type of polish or wax that may contain abrasives that could damage the finish.
For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish. Mild soap may be
used also to clean the Sidebar.
For gloss black finishes: Mild soap may be used to clean the Sidebar.
3" Round Nerf Bar
4 1/2" x 2" Hex Bolts
4 1/2" Lock Washers
4 1/2" x 1-1/4" OD x 3/32" Flat Washers
4) Frame Mounting Brackets
Front
Driver Nerfbar
Page 1 of 2
IS-8825
11/19/12 Rev1 (DP
)
