Rampage 985 Series Getting Started

Replacement top with zip out rear panels for 86-94 suzuki samurai

Download this manual

RAMPAGE

Getting started:

IMPORTANT: You should first try to pick a warm day above 70 degrees to install the top. Remove it from the box and lay it out in the

sun on a soft surface to allow it to soften up and be more flexible during installation.

Included:

Replacement top panels

Strap set

5 x Snaps

Installation

Step 1

Step 2

Drape the top over the rear bow and be sure to tuck the

bow up into the rear corners as far as possible.

Step 3

Rear Bow

2 x 10-24 screw

2 x 10-24 nut

Hook & loop strips

Snap

Windshield

Straps behind bow

View from inside vehicle

985xx Replacement Top with Zip

Tools required:

3/32" drill bit

7/32" drill bit

Drill body

Lay the main skin out on the vehicle and insert the plastic strip into

the channel over the front windshield. Now snap the front two snaps.

Open the hook and loop flap on the sides over the front doors

Make sure that the straps sewn into the rear of the

top are behind the rear bow.

Out Rear panels for:

86-94 Suzuki Samurai

Philips screw driver

Page 1

Page 1 985xx Replacement Top with Zip Out Rear panels for: RAMPAGE 86-94 Suzuki Samurai Getting started: IMPORTANT: You should first try to pick a warm day above 70 degrees to install the top. Remove it from the box and lay it out in the sun on a soft surface to allow it to soften up and be more flexible during installation.
Page 2 Step 4 Install the tension strap through the loop on the strap sewn into the top. Pull tight and secure with hook and loop. NOTE: If the straps are damaged or missing from your vehicle use the included hardware to Snap to bow replace it.
Page 3 Warranty Information Rampage products, Inc. warrants to the original purchaser of any top it manufactures, that the top will be free of defects in material or workmanship for a period of 1 year from date of purchase. Such obligations under this warranty shall be limited to the repair or replacement, at Rampage products discretion, of any assembly or parts which, upon examination by Rampage products, Inc.
